Nubia Flip 5G Manual

Getting to Know Your Phone

Your phone supports 2.4 GHz/5 GHz/6 GHz Wi-Fi.

Setting Up Your Phone

The nano-SIM card(s) can be installed or removed while the phone is turned on.

To avoid damage to the phone, do not use any other kind of SIM cards, or any non-standard nano-SIM card cut from a SIM card. You can get a standard nano-SIM card from your service provider.

1. Insert the tip of the tray eject tool into the hole on the card tray.

   NOTE:
   Please use the tray eject tool included in the box. Otherwise the card tray may not be ejected.

   Never replace the included tray eject tool with sharp objects. Ensure that the tray eject tool is perpendicular to the hole. Otherwise, the phone may be damaged.
2. Pull out the card tray. You can place the nano-SIM cards on the card slots, as shown. Carefully slide the tray back into place.

   NOTE:
   The two card slots support 5G/4G/3G/2G networks.

Charging the Phone

Your phone's battery should have enough power for the phone to turn on, find a signal, and make a few calls. You should fully charge the battery as soon as possible.

Use only ZTE-approved chargers and USB Type-C cables. The use of unapproved accessories could damage your phone or cause the battery to explode.

Do not remove the back cover. The battery is not removable. Removal may cause fire or explosion.

1. Connect the adapter to the charging jack.

2. Connect the charger to a standard AC power outlet.
3. Disconnect the charger when the battery is fully charged.

NOTE:
If the battery is extremely low, you may be unable to power on the phone even when it is being charged. In this case, try again after charging the phone for at least 20 minutes. Contact the customer service if you still cannot power on the phone after prolonged charging.

Powering On/Off Your Phone

Make sure the battery is charged before powering on.

• Press and hold the Power key to turn on your phone.
• To power off, press and hold the Power key until the power off/restart menu appears, and then touch > .

NOTE:
If the screen freezes or takes too long to respond, try pressing and holding the Power key for over 10 seconds to restart the phone.

Waking Up Your Phone

Your phone automatically goes into sleep mode when it is not in use for some time. The display is turned off to save power and the keys are locked to prevent accidental operations.
You can wake up your phone by turning on the display and unlocking the keys.

1. Press the Power key to turn the screen on.
2. Swipe up on the interior screen.

NOTE:
If you have set a face verification, a fingerprint, an unlock pattern, a PIN or a password for your phone, you'll need to use your face or fingerprint, draw the pattern, or enter the PIN/password to unlock your screen.

Precautions for Using the Foldable Phone

This product is a foldable phone with a flexible interior screen. Please pay attention to the following:

• When folding the phone, do not place objects such as cards, coins, or keys on the interior screen, as this may cause damage to the screen.
• Do not remove the interior screen protector as this will damage the screen and void the warranty. In addition, do not apply other screen protectors or stickers.
• Do not press the interior screen or the camera area on the screen with any hard or sharp objects (such as pens or keys) or apply excessive pressure. This may cause damage to the screen.
• Do not fold the phone towards the back side. Your phone will be damaged.
• Fold the phone before putting it in a bag or storing it, as the hard or sharp objects may scratch or damage the interior screen.
• There are slight creases in the bending area of the interior screen. There may be a slight sound when folding or unfolding the phone. These are normal characteristics of the phone.

Product Safety Information

	Don't make or receive phone calls while driving. Never text while driving.
	Keep your phone at least 5 mm away from your body while making calls.
	Small parts may cause choking.
	Your phone can produce a loud sound.
	To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your phone near your ear while the loudspeaker is in use.
	Avoid contact with anything magnetic.
	Keep away from pacemakers and other electronic medical devices.
	Turn off when asked to in hospitals and medical facilities.
	Turn off when told to on aircraft and at airports.
	Turn off when near explosive materials or liquids.
	Don't use at gas stations.
	Your phone may produce a bright or flashing light.
	Don't dispose of your phone in fire.
	Avoid extreme temperatures.
	Avoid contact with liquids. Keep your phone dry.
	Do not attempt to disassemble your phone.
	Only use approved accessories.
	For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible.
	Don't rely on your phone as a primary device for emergency communications.

Specific Absorption Rate (SAR)

Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organization ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health.
The guidelines use a unit of measurement known as Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest SAR value for this device when tested at the head was 1.242 W/kg*, and when tested at the body was 1.314 W/kg* with 5 mm distance. As mobile devices offer a range of functions, they can be used in other positions, such as on the body as described in the user manual**.
As SAR is measured utilizing the device's highest transmitting power, the actual SAR of this device while operating is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum power required to communicate with the network.
* The tests are carried out in accordance with EN 50360, EN 50566, EN 50663, EN 62209-1, EN 62209-2, EN IEC 62311 and EN IEC 62479.
** Please see body worn operation in the user manual.

Specification

Battery Caution

• There is a risk of explosion if battery is replaced by an incorrect type.
• Dispose of used batteries according to the instructions.
• Do not dispose of a battery into fire or a hot oven, or mechanically crush or cut a battery. Doing so can result in an explosion.
• Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of flammable liquid or gas.
• A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas.

USB Port
The USB interface version of this product is USB 2.0.

Proper Use
As described in this guide, your device can be used only in right location. If possible, please do not touch the antenna area on your device.
Do not expose your device to extreme temperatures lower than -10°C and higher than +40°C.
