OUTDOOR UNIT
SERVICE MANUAL
Models
NTXSMT09A111AA
NTXSMT12A111AA
NTXSMT09A111AA
Revision A:
• Some descriptions have been modified.
OBHT821 is void.
HFC
utilized
R410A
Indoor unit service manual
NTXWMT•A111AA Series (OBHT820)
CONTENTS
1. TECHNICAL CHANGES ···································· 3
2. PART NAMES AND FUNCTIONS ····················· 4
3. SPECIFICATION ················································ 5
4. OUTLINES AND DIMENSIONS ························· 8
5. WIRING DIAGRAM ············································ 9
6. REFRIGERANT SYSTEM DIAGRAM ············· 10
7. DATA ·································································11
8. ACTUATOR CONTROL ··································· 18
9. SERVICE FUNCTIONS ···································· 19
10. TROUBLESHOOTING ····································· 20
11. DISASSEMBLY INSTRUCTIONS ···················· 39
PARTS CATALOG (OBBT821)
No. OBHT821
REVISED EDITION-A
