- Page 1 PLA TFO RM Instruction Manual Version 1.0 Original Instructions Read the operator’s manual carefully and make sure that you understand the instructions before you use the product.
-
Page 3: Table Of Contents
1. Platform V Over view 1. 1 Introduction 1.2 Box Contents 1.3 Parts and Functions 1.4 Symbols and Decals 1.5 Sunseeker Visual Positioning 1.6 Specifications 2.Safety Instructions 2. 1 General Safety Instructions 2.2 Safety Instructions for Installation 2.3 Safety Instructions for Daily Operation 2.4 Safety Instructions for Maintenance... -
Page 4: Platform V Over View
1. Platform V Over view 1.2 Box Contents 1.1 Introduction Platform V Robotic Mower The Platform V series includes a robotic lawnmower and a charging station. The robotic mower is equipped with an advanced vision system, allowing seamless boundary detection, contact-less obstacle avoidance, multi-zone operation and precise charging. -
Page 5: Parts And Functions
1.3 Parts and Functions A - Collision Bumper: In the absence of visual positioning, the collision bumper can guarantee the normal functioning of the machine. B - Charging Electrodes: The machine's charging electrodes connect to those of the charging station in Top view order to recharge the machine's battery. - Page 6 Use a detachable power supply as Symbols on charger defined on the rating label next to the symbol. Read the user instructions. CE conformity mark. T3.15A Replace with fuse in accordance Sound power level, determined by with rating. European outdoor noise directive. Replace with fuse in accordance It is not permitted to dispose this with rating.
-
Page 7: Sunseeker Visual Positioning
1.5 Sunseeker All-Scenario Positioning Combined with VSLAM technology and Sunseeker Times setting AIR (Artificial Intelligence Recognition), the robot can perform positioning and navigation tasks in all scenarios, including complex environments, always ensuring high- quality lawn maintenance. Bluetooth Sunseeker's combination of advanced hardware and software (intelligent algorithms) significantly improves the mower’s environment recognition, positioning... -
Page 8: Specifications
1.6 Specifications SUNSEEKER MODEL V18-500 RMV500M20V V18-800 RMV800M20V TECHNICAL SPECIFICATION Boundary wire Wireless / boundary free Wireless / boundary free Camera Stereo Stereo Suitable for area up to sqm 500 sqm 800 sqm Cutting height min/max in mm 20-60 20-60... -
Page 9: Safety And Regulations
2. Safety and Regulations f ) Periodically inspect the area where the machine is to be used and remove all stones, sticks, wires, bones, and 2. 1 General Safety Instructions other foreign objects. g) Periodically visually inspect to see that the blades, WARNING Read all safety warnings, instructions, blade bolts and cutter assembly are not worn illustrations and specifications provided with this... -
Page 10: Safety Instructions For Installation
g) Activate device lock/Set into “ LOCK“ to the f ) Do not expose a BATTERY pack or tool to fire or machine excessive temperature. Exposure to fire or temperature - before clearing a blockage; above 130 °C may cause explosion. - before checking, cleaning or working on the machine. -
Page 11: Safety Instructions For Maintenance
2.4 Safety Instruction for Maintenance 1. Set the product to OFF when you do maintenance on the product. 2. Do not use a high-pressure washer to clean the product. Do not use solvents to clean the product. 3. Disconnect the plug to the charging station before you clean or do maintenance of the charging station. -
Page 12: Install The Charging Station
3.2 Install the Charging Station Step 1: Find a good location: A. Please install the charging station on an open area with a flat ground. B. The height of the grass in front of the charging station needs to be less than 4 inch (10cm) to ensure that the mower can exit and return to the station successfully. - Page 13 This rule applies to all magnetic tags. W indicates the width of the passage. No obstables should be within this passage. >30cm R=1.5m =30±5cm W>0.5L <5m Neighbor 30cm h<3cm 3.3. 2 Magnetic Strips Installation A. Scenario: When the lawn boundary is challenging to discern visually (for example, there is no border or boundary between yours and surrounding lawns).
-
Page 14: Charge And Activate The Mower
3.4 Charge and Activate the Mower 3.5 App Connection Place the mower into the charging station with the A. Make sure the machine is on the charging station and charging electrodes connecting properly. The flashing being charged properly. green light on the charging station indicates charging in B. -
Page 15: Daily Operation
4. Daily Operation Start working/Turn on: Press START button and then OK. Back to station/Turn off : Press START button and then OK. 4.1 Display and Control on the Mower Stop mower operation: Press STOP Display Restart the mower : First, power off the machine. -
Page 16: Robotic Mower App
4.2 Robotic Mower app START HOME START HOME Homepage you can view the work area, verify the status of the mower, monitor work progress (including percentage and actual area completed), and remotely control the mower to start, pause, or return to the charging station. Additionally, the Settings and Notification page can be START HOME... -
Page 17: App Settings
Latest news and updates from the Sunseeker team. 4.3 App Settings Device notifications The mower will send you device notifications in the You can browse and adjust the Platform V app-related following situations: work status update (such as settings on this page. mowing completed), blade replacement, unexpected behaviors, abnormal position, etc. -
Page 18: Iot
QR codes during the charging process, making the mower more intelligent. NOTES: Your Platform V is able to avoid objects after bumping into them. However, it is still recommended to remove excess clutter before mowing. 15 15... -
Page 19: Maintenance
5. Maintenance 1-2 months if it is used frequently. For a safe cutting system, replace all blades along with their screws at the Experience superior mowing results and extend the same time. lifespan of your mower with Maintenance. Regular WARNING inspection and upkeep by an adult every week is essential to ensure optimal performance. -
Page 20: Transportation
5.3 Transportation Ensure the safety of the mower during long-distance transportation by utilizing the original packaging. Prior to lifting, moving, or transporting the product, make sure to switch it off. Handle with care and avoid violent force, such as throwing and heavy pressure. Never pick up or carry the mower while the motor is running. - Page 21 1. Turn off the mower. - Use only the original battery pack or that of the 2. Place the lawnmower upside-down on same model as specified by SUNSEEKER. Each a spotless, soft surface. mower contains one battery pack. - Depending on the specific mower model, the rated capacity of the battery is 2500 mAh or 5000 - Do not use non-rechargeable batteries.
-
Page 22: Power Supply
In the event that the extension WARNING cable is faulty, kindly swap it out for the 10-meter cable that SUNSEEKER has approved. Unplug the power supply from the power socket if a thunderstorm is predicted. Cut off all wires and - NEVER touch an extension cable or damaged cables that are attached to the charging station. -
Page 23: Faq & Troubleshooting
Represent? Installation and settings Although the machine can cut in the rain, it is not • What is the narrowest width allowed for platform V’s recommended. Wet ground can cause mud to stick to path in the garden? the wheels and result in poor cutting quality as wet grass It must be greater than 1 m. -
Page 24: Software Updates
Ensure all screws are tightly secured before cleaning Provide you with support and troubleshooting regarding the machine. Platform V. The legal basis is that the processing is Use a regular water hose for cleaning; avoid using a necessary for the performance of the contract that you high-pressure water gun to prevent potential damage. -
Page 25: Troubleshooting
Use of location data • Reasons for the machine going out of bounds: Some of our services only work if we can determine the (1) The machine's wheels are covered with a large location of your mower (e.g. weather display). When you amount of mud or grass, which may reduce traction or share your mower location with us, the data is stored as even cause a loss of traction. -
Page 26: Trademark And Legal Statement
Trouble shooting Display Illustrate Action (1) Please verify within the app whether the lawnmower is within its designated working area (2) If it is indeed outside working area, guide it back to Mower outside working area the working area (3)If the boundary line is unclear, lay down magnetic strips so that the mower stays in the boundary. - Page 27 Trouble shooting Display Illustrate Action (1) The charging station must be positioned on relatively level ground. It must not be positioned on an uneven Charging dock return failure surface. (2) Manually put mower in the charging base. After the mower is fully charged, Press START then OK. (1) Turn mower off;...
-
Page 28: Impor Tant Information
For any inquiries, assistance, or support regarding your Sunseeker gardening tools, please feel free to reach out 3.Damage caused by improper installation, incorrect use, to us using the following contact details: or operation not in accordance with official instructions or manuals. - Page 29 EC DECLARATION SHANGHAI SUNSEEKER ROBOTIC TECHNOLOGY CO., LTD 3rd floor , 226 Gaoji Ra., SiJing Town, SongJiang District, Shanghai, China Declares and assumes liability that the product: Description Robotic Lawnmower Model NO.: RMV500M20V, RMV500N20V, RMV600M20V, RMV600N20V, RMV800M20V, RMV800M 20VU,RMV800N20V,RMV800N20VU,RMV900M20V,RMV900M20VU,RMV900N20V,RMV900N20VU, RMV1000M20V,RMV1000M20VU,RMV1000N20V,RMV1000N20VU, RMV1200M20V ,RMV1200M20VU ,RMV1200N20V,RMV1200N20VU with battery chargerCGF251, CGF253 and charging station CB07A.
- Page 30 27 27...
