This user guide is applicable to the following references Product Version (Visible on Product references the product label) LoRaWAN ACW/LW8-THAQ Sigfox ACW/SF8-THAQ Version history of this document Affected software Version Date Description Author version 23/11/2020 Creating the document V0.0.1 Descriptive correction frame downlink 10/12/2020 V0.0.1...
Trademarks and copyrights ATIM radiocommunications®, ACW ATIM Cloud Wireless®, ARM Advanced Radio Modem® are registered trademarks of ATIM Sarl in France. Other trademarks mentioned herein are the property of their respective owners.
Environmental recommendations a. Environment Observe the storage and operating temperature ranges of the products. Failure to do so could disrupt operation and even damage the equipment. This equipment is not designed for an outdoor environment! Follow the precautions and instructions listed below to ensure your safety and the safety of your environment and to prevent damage to your device.
Technical characteristics a. Product Size 80 x 80 x 35 mm Antenna Built-in (1/4 wave) -20°C to +55°C (Operating) Temperature -40°C to +70°C (storage) Fixation Wall Package Home automation Feeding 1 x 3.6V / 7.2 Ah battery pack Weight 100 g Frequency 863 –...
Page 8
VOC sensor Beach 0 to 500 Resolution IMPORTANT NOTE The VOC index represents the overall concentration of all VOCs (volatile organic compounds) and not a specific concentration of a given compound. The index is defined on a scale from 0 to 500 (0 for a near-zero VOC concentration and 500 for a very high VOC concentration).
Case a. Traffic congestion <- Mounting > holes b. Fixation The ACW-THAQ is attached to a wall by two screws that fit into the two mounting holes on the back of the case. The lid vents must be on the right, in the same direction as the photo opposite.
c. Installation For optimal results, it is recommended to install the box without environmental obstructions and to place it at a height of about 1m50. For information, the antenna is integrated into the box. It should be mounted on a vertical stand, or attached to a wall.
How it works The 2020 new generation ACW (Atim Cloud Wireless®) products are all based on the same internal software (Firmware) and bring exciting new features such as selecting and visualizing their mode of operation. To find out the state of the product, simply run a magnet briefly (<2 sec) against the QRCODE label, which causes the LED indicator...
b. Product Commissioning Unless otherwise requested, ACW products are delivered with connected batteries and put into "deep sleep" mode. To place the product in its operating mode, hold a magnet against the QRCODE label for 6 seconds. During these six seconds, the product's LED should flash WHITE and then...
pairing phase 24 hours later. Thus, if the product is placed in an area not yet covered by a network, the product will join it when connectivity is possible. There is no need to intervene on the product for it to join the network. •...
WARNING Once the manipulations are complete, press the button twice again simultaneously so that it returns to its main function. A white flash indicates that the manipulation was successful. h. Passivation of batteries All new generation ACW products incorporate a battery depassivation feature, preventing battery oxidation during prolonged deep sleep phases.
Activation/deactivation as well as configuration of start and end times can be done via the ACW Configurator desktop application or via Downlink. ACW Configurator a. Compatible configurator versions For a THAQ with the following application software Use the ACW Configurator version version Sigfox: V1.0.6 V5.2.6 or higher...
b. Configuring the ACW-THAQ Emission period and samples in the frame The transmission period corresponds to the time interval between each sending of a measurement frame. The minimum emission period is 1min. The maximum emission period depends on the number of samples in the frame. It is equal to the number of hours corresponding to the number of samples per frame.
NOTE The sampling period is set at a maximum of 1 hour for reasons of overall autonomy of the product. Since the product needs 48 consecutive measurements without a power cut at the CO2 sensor, in order to be able to perform a CO2 self-calibration, the longer the 48 measurements, the shorter the service life of the product.
Page 18
1. LoRAWAN Class A : The modulation of the product is done in LoRa and uses the LoRAWAN Class A protocol. This mode requires a LoRAWAN (Private Gateway) private network, or an operated network in order to view the data sent by the product. 2.
Product Clock Each time the configurator is connected, the product's clock is updated (based on the computer's clock) and displayed . In addition, a second offset can be applied if needed. Product versions Upon connection with the product, the configurator retrieves all the software versions of the product (product software and radio module software) as well as the network identifier Sensor Configuration Temperature and humidity...
Air quality (VOCs and CO2) Two sensors are present for air quality measurement: one for the measurement of CO2 concentration, the second for the measurement of VOCs (Volatile Organic Compounds). For each one, you will find the following configuration items: Sensor Activation/Deactivation.
It is also possible to see in real time the value measured by each of the sensors. In addition, for the CO2 sensor, it is possible to configure the altitude at which the sensor will be installed to improve the accuracy of the CO2 measurement, as well as to activate/deactivate the air quality indication via the LED on the front.
Advanced Configuration A final tab provides access to the advanced configuration setting of the product. For the "Period" field, it is advisable to leave the default value. Otherwise, there is a checkbox to enable or not the night mode (checkbox = night mode activated). For the moment the time slot for activating this mode is only configurable by Downlink, the configuration from the application will be possible very soon.
Page 23
c. Factory Setup Radio Frame Settings Radio Broadcast Period: 30 minutes Number of Samples: 1 History Depth: 1 General Settings Period of sending the life story: 1 time per day Timestamp: Disabled Radio parameters: LoRaWAN Class A (for a LoRAWAN product) / Sigfox (for a Sigfox product) Night Mode: Off Sensor parameters Temperature and humidity sensor...
Page 24
d. ACW Update When connected to the product via Bluetooth Low Energy, it is possible to update the various software that makes it To do this, you have to go to the Tools ->Updater menu (CTRL+U) ATIM_ACW-THAQ_UG_EN_V1.10...
UPLINK Frame Format a. Description Uplink Frame Byte 1 Byte 2 . . . Byte n Frame header Frame-specific data There are three types of frames: • Classic frame; New generation : Very similar to the old frames, the difference is that you can activate the timestamp.
The different types of frames Frame Type Data size Description of the frame 0x00 Reserved 0x01 4 bytes A framework of life. 0x02 0 bytes Request for downlink for network testing. 0x03 Reserved 0x04 Reserved 0x05 1 byte Test frame with counter. 0x06 Variable (Cfg box) Response to a configuration frame.
Page 27
Byte 2 Header Way Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Reserved = 0 Track number Type of Measurement Type of possible action Type of Measuremen Units Data size Data type Descriptions Temperature in hundredths of a degree Celsius •...
Measurement alert frame Byte 1 - Leading Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Timestamp Measured Reserved generation frame Alert frame (= 0x0d) (Off = 0, On = If the Timestamp is enabled, 4 bytes with the value of the Timestamp will be preceded by the header (byte 1). For each of the channels in alert, a header is inserted and is constituted as follows: Byte 2 Header Way Bit7...
Fabric of life The life frame is sent at regular intervals depending on the configuration applied (default 4 days) and contains the battery levels of the empty (the product is not doing anything) and charging (the product is emitting a radio frame). Byte 1 - Header Bit7 Bit6...
General Error and Alarm Frame Byte 1 - Header Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 Next Timestamp Weft Reserved = Generation Error frame = 0x0e Measure = 0 If the Timestamp is enabled, 4 bytes with the value of the Timestamp will be preceded by the header (byte 1). For each of the error messages, a header is inserted and is constituted as follows: Byte 2 - Header Error Message Bit7...
Page 31
0x8E ERR_ARM_INIT_FAIL Radio module initialization failed 0x8F ERR_ARM_BUSY The module is already busy (possibly not initialized) 0x90 ERR_ARM_BRIDGE_ENABLE The module is in bridge mode, impossible to send data by radio 0x91 ERR_RADIO_QUEUE_FULL The radio line is full 0x92 ERR_CFG_BOX_INIT_FAIL Error initializing the black box 0x93 ERR_KEEP_ALIVE_PERIOD Poor structure of life frame period...
b. Examples of frames Measuring frame With the timestamp of disabled, no history and a sample count of 1 (Temperature and humidity only): Byte 0xA0 0x08 0x09 (new generation (channel 0, measurement 0x08 0x85 (channel 0, type of 0x17 0xDE measurement frame, no type: temperature) measurement: hygrometry)
Now with a sample count of 2: Byte 2 and 3 0x08 0x09 0xA1 (channel 0, (channel 0, (new generation 0x003C measurement 0x01 0x2C 0x08 0xA4 type of 0x22 0x13 0x17 0xDE measurement frame, no (period of issue) type: measurement: history, 2 samples) temperature) hygrometry)
Downlink This feature is available on ACW-THAQ if you meet the following requirements: Application Software Radio Firmware Version Sigfox V0.0.1 V5.9.3.2 Version LoRaWAN V0.0.1 V5.1.1 The operation of the Downlink is explained in document ATIM_ACW-DLConfig_UG_FR_v1.4, relating to the version V1.2.0 of the ATIM Downlink Protocol (see this document for all parameters and commands common to all products). The parameters specific to ACW-THAQ are as follows: a.
b. Sensor activation Byte 1 Byte 2 Parameter code Parameter value 0x15 0b0000X0YZ For byte 2, the value of the x, y, and z bits indicates whether a sensor is enabled or not. When one of these bits is set to 1, the sensor is activated; When it is at zero, the sensor is disabled. The Z field allows you to enable/disable the temperature-humidity sensor.
c. Setting thresholds Byte Parameter code 0xD6 (temperature threshold) High threshold Low threshold Duratio 0xD7 (humidity 0x09 0x00 Hysteresis thresho value value threshold) 0xDA (VOC threshold) 0XDE (CO2 threshold) High threshold value field: value (in hundredths of a °C or %RH) triggering the high threshold (Little Endian encoding) Low threshold value field : The value (in hundredths of a second °C or %RH) triggering the low threshold (Little Endian encoding) Hysteresis field: margin of uncertainty of thresholds (in hundredths °C or %RH - Little Endian encoding)
Coefficient Parameter Code (Byte 1) Byte 2 Byte 3 0x59 (temperature coefficient) Value The multiplication coefficient is represented by the "Value" field in the table above. The coefficient value must be sent in Little Endian encoding and can be between 0 and 10000 (this value is divided by 1000 by the product). EXAMPLE For a coefficient of 0.1, the value to be sent will be 100 = 0x6400.
g. Setting LED Indicator Thresholds Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Parameter code Parameter value Parameter value Parameter value Parameter value 0x9F 0xaa 0xbb 0xcc 0x00 The value of byte 2 represents the boundary between the GREEN and YELLOW flashing.
Page 39
i. Reserved codes for future developments Byte 1 Byte 2 Parameter code Parameter value 0x10 0x08 0x11 0x00 WARNING Do not change these values. ATIM_ACW-THAQ_UG_EN_V1.10...
