Summary of Contents for Bosch 2 Series
- Page 1 *8001320432* 8001320432 (050317) Installation instructions...
- Page 4 Gas Nz Qn (kW) Bp G20/20 mbar 1,00 0,095 G20/25 mbar 1,00 0,095 G25/20 mbar 1,00 0,111 G25.1/25 mbar 1,02 0,111 G25.3/25 mbar 1,00 0,111 G30/29 mbar 1,00 G30/37 mbar 1,00 G30/50 mbar 1,00 G31/37 mbar 1,00 G20/20 mbar 1,75 0,167 G20/25 mbar 1,75 0,167 G25/20 mbar 1,75 0,194 G25.1/25 mbar 1,75 0,194 G25.3/25 mbar 1,80...
- Page 5 Gas Nz Qn (kW) Bp G20/20 mbar 3,50 0,334 G20/25 mbar 3,50 0,334 G25/20 mbar 3,50 0,388 G25.1/25 mbar 3,50 0,388 G25.3/25 mbar 3,50 0,379 G30/29 mbar 3,30 G30/37 mbar 3,30 G30/50 mbar 3,30 G31/37 mbar 3,30 Before installing the appliance, check that the ¡ local conditions of the supplier are compatible with the appliance settings specified on the rating Safe installation plate (type of gas and pressure, power, voltage).
- Page 6 Note: You can install an overpressure safety device WARNING ‒ Risk of burns! that limits or cuts off the gas supply if the regulator The accessible parts may become hot during opera- of the gas cylinder or liquid gas tank fails. tion. If there is no built-in oven underneath the hob and Spare parts for gas connection the underside of the hob is accessible, follow these If the country's regulations allow, you can obtain the...
- Page 7 Standard output burner High output burner Mini-wok multi-crown burner Mini-wok multi-crown burner Adjusting the taps Set the control elements to the minimum power level and pull them out. Remove the plinth for the control elements. To access the bypass screw, use the tip of the screwdriver to push down on the flexible rubber holder.
