- Page 1 MT400 Environment Monitoring Series Operation and Installation Manual...
- Page 2 B1-MT400 [Manufacturer]: Wuhan Huchuang Union Technology Co., Ltd. [Production Address]: No.1 Workshop, 1F, Building B10, Wuhan Hi-Tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-Tech Development Zone, Wuhan, Hubei, China [After-Sales Service Unit]: Wuhan Huchuang Union Technology Co., Ltd.
-
Page 3: Table Of Contents
B1-MT400 Contents 1 Overview .................................3 1.1 Operation Instructions of Manual .........................3 1.2 Overview ..............................3 1.3 Environmental Requirements ........................3 1.4 Environmental Protection Instructions ......................4 2 Structure Features and Equipment Parameters ......................4 2.1 Structure Features ............................4 2.2 Equipment Parameters ..........................5 3 Basic Operation Instructions ............................6 3.1 Parts List ...............................6... -
Page 4: Overview
1.1.4 The contents of the Manual are subject to change without prior notice. 1.2 Overview MT400 is powered through the power adapter. The 1000mAh lithium battery built in the device can only provide the power supply to the device for a short time when being disconnected from the adapter, so the device cannot work under the condition of disconnection from the adapter for a long time;... -
Page 5: Environmental Protection Instructions
No metal objects around the equipment (Keep it away from metal wall). 1.4 Environmental Protection Instructions 1.4.1 MT400 device contains reusable materials, and some components can be recycled after being cleaned and sterilized. 1.4.2 During recycling and handling MT400 device, it is recommended that the company's technical personnel dismantle it and recycle it according to different waste groups;... -
Page 6: Equipment Parameters
The device can be powered ON normally only when the toggle switch is turned to ON position; 433MHz antenna interface: Connected with 433 MHz external antenna; Charging port: Connected with a 5V/2A power adapter. 2.2 Equipment Parameters Table 2 MT400 Performance Parameters Item Parameter Overall dimensions 162mm*92mm*50mm (L*W*H) -
Page 7: Basic Operation Instructions
± 10ug/m Formaldehyde test range 0~2mg/m Formaldehyde test accuracy ± 0.1mg/m Power supply mode DC 5V 2A Operating temperature of 0℃ ~ +50℃ equipment Basic Operation Instructions 3.1 Parts List Table 4 MT400 Parts List Name Specification/ Quantity Power adapter DC5V/2A... -
Page 8: Precautions Before Installation
Before installation, please check the Parts List to ensure that the parts are complete; Check whether the product is damaged. The transmission distance of MT400 should be limited and not exceed 3 rooms indoor. 3.3 Installation Method 3.3.1 Laid Flat Choose a fairly empty space, and keep it laid flat on the desktop (the default installation method). -
Page 9: Wall-Mounting
3.3.2 Wall-Mounting Select a relatively open smooth wall, paste 4 pieces of MT400 special magic tapes on the wall, and then paste another 4 pieces of MT400 special magic tapes on the baseplate of MT400, and then stick magic tapes together. -
Page 10: Main Interface Instructions
B1-MT400 3.5 Main Interface Instructions Key 1: UP key Key 2: DOWN key Key 3: "INFO" key: Press this key to enter "System information interface" to view the relevant information on the equipment; Key 4: "MENU" key: Press this key to enter "Setting interface"... -
Page 11: System Information
B1-MT400 The power supply status of the adapter is shown as follows: "OK" indicates that the power supply of the adapter is normal; "ERR" indicates that the power supply of the adapter is abnormal, and there is an audible and optical alarm (sound: The buzzer beeps; light: the icon blinks);... -
Page 12: Parameter Setting
B1-MT400 below: Display Instructions: "Model" in Row 1 Equipment model; "SN" in Row 2 Unique serial number of equipment; Row 6 and 7: Version Software/ hardware version of equipment; Operation Instructions of Buttons: Key 1: The system returns to the main interface when the key is pressed;... -
Page 13: 1.Set Date Time
B1-MT400 3.7.2 "1.SET DATE TIME" Note: This option is used for setting the current operating date and time of the equipment; Select "1.SET DATE TIME" on the setting menu, and then press the "OK" button (Key 3) to enter the setting interface. As shown in the following figure: Parameter Description: “YY/MM/DD”... -
Page 14: 2.Set Temp
B1-MT400 3.7.3 "2.SET TEMP" Note: This option is used for temperature calibration; Select "2.SET TEMP" on the setting menu, and then press the "OK" button (Key 3) to enter the setting interface. As shown in the following figure: Operation Instructions of Buttons: Key 1- "+"... -
Page 15: 4.Set O2
B1-MT400 Operation Instructions of Buttons: Key 1- "+" key: Press this button to add the calibration value; Key 2- "-" key: Press this button to reduce the calibration value; Key 3- "OK" key: When you press the button, the device will perform calibration and the system will automatically save parameters and return to the setting interface;... -
Page 16: 5.Set Voc
B1-MT400 Key 3- "OK" key: When you press the button, the device will perform calibration and the system will automatically save parameters and return to the setting interface; Key 4 - "EXIT" key: When you press the button, the system directly returns to the setting interface. -
Page 17: Notices For Use Of Equipment
The transmission distance of MT400 is limited and should generally not exceed 3 rooms. If the walls of the rooms are made of metal materials, it is better to install a data receiver host in each room;... - Page 18 B1-MT400 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 19 B1-MT400 Wuhan Huchuang United Technology Co., Ltd. Address: No.1 Workshop, 1F, Building B10, Wuhan Hi-Tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-Tech Development Zone, Wuhan, Hubei, China...
