- Page 1 HCLH/SOP-YF-072-108 MT300MIX Gas Monitoring Series Operation and Installation Manual...
- Page 2 B1-MT300MIX [Manufacturer]: Wuhan Huchuang Union Technology Co., Ltd. [Production Address]: No.1 Workshop, 1F, Building B10, Wuhan Hi-Tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-Tech Development Zone, Wuhan, Hubei, China [After-Sales Service Unit]: Wuhan Huchuang Union Technology Co., Ltd.
-
Page 3: Table Of Contents
B1-MT300MIX Contents 1 Overview .................................3 1.1 Operation Instructions of Manual .........................3 1.2 Overview ..............................3 1.3 Environmental Requirements ........................3 1.4 Environmental Protection Instructions ......................3 2 Structure Features and Equipment Parameters ......................4 2.1 Structure Features ............................4 2.2 Equipment Parameters ..........................6 3 Basic Operation Instructions ............................7 3.1 Power-On for Use ............................7... -
Page 4: Overview
When MT300MIX is installed and used for the first time, it is necessary to add the sampling frequency (operated by professional engineers) in order to empty the excess air inside the device in a short time and ensure the accuracy of premixed gas concentration detection. -
Page 5: Structure Features And Equipment Parameters
1.4.2 During recycling and handling MT300MIX, it is recommended that the company's technical personnel dismantle it and recycle it according to different waste groups. 1.4.3 According to national regulations, the compositions of the main raw materials of MT300MIX shall be are shown in (Table 1). - Page 6 B1-MT300MIX Power Interface Equipped with a 5V/2A power adapter. Antenna Gas Outlet Refers to the gas outlet of the device. After the solenoid valve of the device is opened for the intake detection, excess gas will be discharged through the outlet. Do not block the gas outlet.
-
Page 7: Equipment Parameters
Refers to the manual valve of the gas inlet pipe; in case of equipment leakage alarm, the user can manually close this valve to ensure that the equipment will not leak. Equipment Parameters Table 2 MT300MIX Parameters Item Parameter Overall dimensions... -
Page 8: Basic Operation Instructions
After MT300MIX and MT500 devices are installed normally, users can download the "Laboratory Monitoring System" APP to view the monitored temperature data; or view the temperature data through the... -
Page 9: Operation Instructions Of Buttons
B1-MT300MIX 3.2 Operation Instructions of Buttons 3.2.1 Button Description a) UP key b) DOWN key c) OK key d) Menu key 3.2.2 Main Interface Instructions f) g) e) Breathing point of system operating state: It will flash when the system runs normally; it will be normally on or off when the system breaks down;... - Page 10 B1-MT300MIX Main Interface and Operation Instructions During Intake UP key: No function (disabled) DOWN key: No function (disabled) OK key: No function (disabled) Menu key: No function (disabled) Main Interface and Operation Instructions During Sampling after Intake UP key: No function (disabled)
- Page 11 B1-MT300MIX Menu Function Description: "1. SET O2": O concentration calibration function; "2. SET CO2": CO concentration calibration function; "3. SET DATA FREQ": Setting function of data upload frequency; "4. SET SAMPLE FREQ": Setting function of sampling frequency; "5. SET VALVER TIME": Setting function of intake time of single sampling;...
- Page 12 B1-MT300MIX UP key: No function DOWN key: No function OK key: No function Menu key: The system returns to the setting interface when this key is pressed Interface and Operation Instructions Upon O Concentration Calibration Failure UP key: Press this button to add the value by 0.1% and press and hold this button to add the...
- Page 13 B1-MT300MIX Concentration Calibration Interface: Operation Instructions of Buttons: "+" key: Press this button to add the value by 0.1% and press and hold this button to add the value by 0.1% continuously; "-" key: Press this button to reduce the value by 0.1% and press and hold this button to reduce the value by 0.1% continuously;...
- Page 14 B1-MT300MIX Menu key: The system does not save the calibration value and directly returns to the setting interface when this key is pressed Note: CO concentration calibration setting range: From 0% to 10%. 3.2.7 "3. SET DATA FREQ" Select "3. SET DATA FREQ" on the setting interface, and then press the "OK" button to enter the...
- Page 15 B1-MT300MIX 3.2.9 "5. SET VALVE TIME" Select "5. SET VALVE TIME" on the setting interface, and then press the "OK" button to enter the intake time setting interface for single sampling, as shown in the picture below: Operation Instructions of Buttons: "+"...
- Page 16 30 seconds) when the button is pressed; Note: The default working mode is "Normal Mode". "Sleep Mode" is generally applicable to MT300MIX with battery function: In this mode, all detection functions are disabled and the device enters the sleep state.
-
Page 17: Installation Instructions
The sampled data on the main interface will be updated only when the intake is sampled, and will be automatically locked until the next sampling. Installation Instructions Installation Method 1 Connect the pre-mixing gas pipe to MT300MIX through a gas tee; COOK incubator Gas tee... -
Page 18: Installation Method 2
Note: 1) In this installation mode, a disc filter should be added at the front end of the gas intake of MT300MIX to prevent impurities from entering the equipment; 2) Hoops shall be installed at hose joints and tightened;... -
Page 19: Precautions
B1-MT300MIX 3) Note that the total length of the pipe from the last incubator to MT300MIX should not exceed 2 meters. Precautions When MT300MIX is installed and used for the first time, because there is air inside the device, the air cannot be guaranteed to be emptied at one time, therefore, the concentrations tested first few times after the installation of the device will be inaccurate;... - Page 20 B1-MT300MIX which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver.
- Page 21 B1-MT300MIX Wuhan Huchuang United Technology Co., Ltd. Address: No.1 Workshop, 1F, Building B10, Wuhan Hi-Tech Medical Device Park, No. 818 Gaoxin Avenue, East Lake Hi-Tech Development Zone, Wuhan, Hubei, China...
