- Page 1 MultiPay POS Setup Guide (DX8000) MultiPay POS Setup Guide (DX8000) Version 2.0 January 21, 2025 ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
-
Page 2: Table Of Contents
DataPointe User Registration....................4 Configuring your Axium DX8000 Device ................6 Device Settings ..............................6 Connecting your Axium DX8000 Device to Wi-Fi ................6 Adjusting Date and Time Settings ......................7 Adjusting Screen Timeout ..........................8 (Optional) Configuring your DX8000-BASE-W2 Docking Base ............9 Base Operating Modes ........................ -
Page 3: Setup Prerequisite
This guide describes how to add and manage users in DataPointe for MultiPay POS, configure Axium DX8000 device settings, and log into the MultiPay POS application for the first time. Details on how to use the application can be found in the MultiPay POS User Guide. -
Page 4: Datapointe User Registration
After entering a unique ‘POS Username’ for the user, select the ‘POS Contract’ the user is associated with. IMPORTANT! Enter a mandatory ‘Clerk Id’ for the user. This field is required for accurate receipt printing. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. - Page 5 View Permissions page. Once all permissions are set, you must select Save on the View Permissions page to save the permissions for the profile. An Add User Complete message is displayed. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
-
Page 6: Configuring Your Axium Dx8000 Device
Connecting your Axium DX8000 Device to Wi-Fi To connect to wi-fi, complete the following: 1. Power on the Axium DX8000 device. 2. Open the Android Settings menu: Note: The generic password is: 350000. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. -
Page 7: Adjusting Date And Time Settings
• Selecting your Network, selecting Forget, and then re-adding can help refresh your connection. Adjusting Date and Time Settings 1. Open the Android Settings menu. Note: The generic password is: 350000. 2. Select System > Date & time ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. -
Page 8: Adjusting Screen Timeout
3. Select the appropriate screen timeout setting to meet your needs: • 15 seconds • 30 seconds • 1 minute • 2 minutes • 5 minutes • 10 minutes • 30 minutes • Never 4. Click Save. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. -
Page 9: (Optional) Configuring Your Dx8000-Base-W2 Docking Base
MultiPay POS Setup Guide (DX8000) (Optional) Configuring your DX8000-BASE-W2 Docking Base With the Axium DX8000 Terminal, the Axium DX8000-BASE-W2 docking base is available for an additional cost to connect your terminal device to the internet through a hardwired ethernet connection. The docking station base is connected to the ethernet connection, and then the terminal device (up to 5 devices) connects to the base using wi-fi. -
Page 10: Base Operating Modes
• Base and devices are directly connected to local router and on the same network segment. • Base DHCP server is turned off and NAT is not used. • All device IP and MAC Addresses are visible to and addressable by the network. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. -
Page 11: Connecting Your Device And Docking Base
Connecting your Device and Docking Base Pairing your Device To quickly connect the AxiumDX8000 device to the Axium DX8000-BASE-W2 docking base you can pair the devices using the Pairing button on the side of the docking base. 1. Power on the Axium DX8000 device. - Page 12 • If the green indicator light is on, it indicates the docking base is successfully paired. Note: Only one Axium DX8000 device can be paired at a time. If the docking base is paired to another device, long press the pairing button to clear the pairing record.
- Page 13 MultiPay POS Setup Guide (DX8000) 2. Click Settings menu on the device and then click Base. 3. Click the Scanning Box and scan the data matrix barcode label on the back of docking base. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
- Page 14 MultiPay POS Setup Guide (DX8000) 4. On the Pop-up menu choose Only use base Wi-Fi. 5. Wait for the Successfully Connected status. 6. Click OK. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
-
Page 15: Accessing The Administrator Application
Manage - provides parameters to update firmware, save or load Base configuration and change the password. IMPORTANT! It is strongly recommended that all passwords are immediately changed from the default ones. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. - Page 16 2. Select Hidden SSID > Enable. 3. Click Save and then apply. 4. Wait for confirmation. 5. Click on the 5GHz WLAN tab at the top of the screen. 6. Repeat steps 2-4. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
-
Page 17: Resetting The Dx8000-Base-W2 Docking Station To Factory Settings
3. What do I do if the docking base is not connected to the DX8000 device, while the green indicator light flashes? The two devices are too far away from each other, and the connection is failing. Place the two devices in closer proximity. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. -
Page 18: (Optional) Mounting The Dx8000 Device Or Dx8000-Base-W2 Docking Station
5. Replace the battery cover of the DX8000 device. To mount the DX8000-BASE-W2 docking station permanently: 1. Remove the battery cover of the DX8000 device. 2. Position the space block on the table and install screws. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. - Page 19 5. Fasten the base-mounting structure on the base with three screws. Note: The fasteners should be appropriate for counter material. 6. Replace the battery cover of the DX8000 device. 7. Put the DX8000 device on the base to lock it. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
-
Page 20: Logging Into The Multipay Pos Application
Logging into the MultiPay POS Application To log into the application, follow the instructions below. On the device, open the MultiPay POS app published by Worldpay: After being added as a user, you will receive a temporary password to the registered e- mail with a validity of 24 hours. - Page 21 On the Change Password screen, enter the Current Password (temporary password), New Password, and then confirm the new password by entering it again in the Confirm Password field. Login with your new password. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
- Page 22 MultiPay POS Setup Guide (DX8000) A device connection status displays, and when complete, click Done. A Menu screen then displays, and you can begin using the application. Contact Us Worldpay Biller Solutions Support: 844-300-5510 ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
-
Page 23: Version History
Resetting the DX8000- BASE-W2 Docking Station to Factory Settings and the Docking Base FAQs. 8-22-2023 Revised POS DataPointe permissions and minor revisions for consistency throughout. 8-23-2024 Rebranded for Worldpay. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved. - Page 24 MultiPay POS Setup Guide (DX8000) Version Change Date Change Description 8-13-2024 Rebranded for latest Worldpay template. 1.10 12-20-2024 Updated images for new UI. 1-22-2024 Republish for MultiPay POS User Guide for DX8000 device users. ©2024 Worldpay, LLC and/or its subsidiaries. All Rights Reserved.
