- Page 1 INSTALLATION MANUAL Videorow portrait/landscape for Samsung 43”-55” Designed by Borhan Nekzada Art No: VR4300 VR5000 VR5500...
- Page 2 Hi-Nd shall not be liable for any damage caused by the product after it has been delivered and whilst it is in the possession of the buyer, e.g. defects due to faulty maintenance, incorrect installation or faulty repair by the Buyer or to alterations carried out without the Supplier’s consent in writing.
-
Page 3: List Of Parts
LIST OF PARTS A1 Wall Mount bar 1 B1 Wall Mount bar 2 C1 VESA connectors D1 Black Top List E1 M8 x 16mm Screws NUMBER OF PERSONS REQUIRED... - Page 4 ASSEMBLY INSTRUCTIONS Measure and mount the metal wall mount bar (A1)
- Page 5 If a second bar is needed, repeat the same proce- dure with B1. The part A1 and B1 is easy to connect to each other to build a long video row. Installation procedure is the same for both lands- cape and portrait. Put the screen in portrait or landscape mode.
- Page 6 The screen can now be attached to the wall mount bar (A1) Attach all screens for the specific video row that has been chosen.
- Page 7 Cables from the screen can pass trough the wall mount The screen can not be lifted straight up from the bar, due to the angle of the VESA connector...
- Page 8 Add the black top list for screen leveling Top list added...
-
Page 9: Warranty
• Send the product back to HI-ND on a pallet in the original package. The purchaser pays the freight cost. • We will send a credit if the product is found faulty after our quality controls.
