- Page 1 INSTALLATION MANUAL Wall Casing Designed by Borhan Nekzada Art No: WC4300-0101 WC5500-0101 WC6500-0101...
- Page 2 Hi-Nd shall not be liable for any damage caused by the product after it has been delivered and whilst it is in the possession of the buyer, e.g. defects due to faulty maintenance, incorrect installation or faulty repair by the Buyer or to alterations carried out without the Supplier’s consent in writing.
-
Page 3: List Of Parts
LIST OF PARTS M6x16 M8x20 4xSpacer 3mm 4xWasher D6/D8 NUMBER OF PERSONS REQUIRED... - Page 4 SCREWS & SPACERS Installation for Samsung QMC Screw: M8x35 Spacer: 18 mm Installation for LG UHN Screw: M6x25 Spacer: 10 mm Installation for LG UMN Screw: M6x15...
- Page 5 ASSEMBLY INSTRUCTIONS Remove screws...
- Page 6 Remove front cover...
- Page 7 Mount the back cover to the wall...
- Page 8 Attach display...
- Page 9 Attach front cover with screws...
- Page 10 Finished!
-
Page 11: Warranty
• Send the product back to HI-ND on a pallet in the original package. The purchaser pays the freight cost. • We will send a credit if the product is found faulty after our quality controls.
