  • Page 1 User Manual User Manual AMTL-UHF-10 Date: March 2025 Version: 1.0 P a g e...

  • Page 2: About This Manual

    AMTL-UHF-10 User Manual About This Manual This manual introduces the operation of user interfaces and menu functions of AMTL-UHF-10.  The pictures in this manual may not be exactly consistent with those of your product; the actual  product's display shall prevail.

  • Page 3: Table Of Contents

    8.3.8 Restore ............................. 22 8.3.9 Password Settings ..........................24 8.3.10 UHF Reader Settings ........................24 8.3.11 Developer ............................25 8.4 Log ............................27 ECO-FRIENDLY OPERATION ....................... 28 FCC WARNING ..........................29 P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 4: Overview

    User Manual 1 Overview AMTL-UHF-10 is Armatura's latest third-generation UHF reader, featuring enhanced stability, an extended reading range, and quicker recognition. It utilizes a passive UHF card, making it suitable for vehicle and personnel management. It conforms to CE and FCC standards, awaiting further security certifications.

  • Page 5: Side View & Wiring

    2 Side View & Wiring Mounting Bracket Cables Description +12V Power In +12V Power Out (Green) IWD0 Wiegand In IWD1 Sensor, Button, Trigger (Black) TRIG Ethernet COM1 Lock COM2 Lock P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 6: Specifications

    20 AWG shielded, 164ft (50m) Mechanical Dimensions 12.17" x 12.17" x 2.74" (309 x 309 x 69.5mm) Weight 3.2KG Mounting Suited for any at surface mounting Housing Material Polycarbonate P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 7 Software Interface TCP/IP Mode 10 Base-T/100 Base-TX, Auto MDI/MDIX TCP/IP Protocol VLAN, SSH, HTTP, IPv4, DNS TCP/IP Communication Push Protocol over HTTP/HTTPS Supported Software Armatura One Security System P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 8: Dimensions

    AMTL-UHF-10 User Manual 4 Dimensions P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 9: Device Connection

    (The maximum operating current of device is 100mA, and the LOCK Device Lock rated current is 60mA); When U ≠12V; LOCK When the lock is far from the device. P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 10: Barrier Connection

    Access Control System, it is required to connect one FR107 diode (equipped in the package, do not reverse the polarities) in parallel to release the self- inductance EMF. 5.2 Barrier Connection P a g e Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 11: Connected With Other Parts

    The device features Wiegand signal input capability, allowing it to connect with an independent card reader. When installed on each side of the door, they work together to control access and the lock. P a g e | 10 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 12: Connected With Computer

    5.6 Connected with Computer Connect the RJ45 port of the device to the computer’s Ethernet port. The device is compatible with the Armatura One Security Platform. P a g e | 11 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 13: Installation Procedure

    The detection distance of the integrated machine may vary depending on weather conditions  such as rain, snow, or wind. The device should be away from strong magnetic field when working.  P a g e | 12 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 14: Install The Uhf Card

    AMTL-UHF-Mini Tag AMTL-UHF-Mini Tag is also generally used in long distance fixed vehicle access management. It is pasted on the interior windshield of the car. P a g e | 13 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 15 The distance between the UHF tag and the metal frame shall be 80 mm at least. The position of the tag/card in the vehicle is as follows: UHF Tag P a g e | 14 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 16: Recommended Tags

    Standard protocols: ISO18000-6C, EPC Gen2 (V1.2.0) Operating frequency: 860 to 960MHZ Storage capacity: 128Bits AMTL-UHF-Tag Operating temperature:-30°C to 55°C Storage temperature:-10°C to 40°C Storage humidity:40% to 50%RH Recognition distance:11m (AMTL-UHF-10) P a g e | 15 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 17: Software Configuration

    Enter the IP Address (default: 192.168.1.201) of the device in the address bar of a web browser. The address format should be https://IP Address. For example: https://192.168.1.201. Then enter the Username (default: admin) and password (default: 123456), as displayed in the below figure. P a g e | 16 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 18: Live

    Device Information, Time Settings, Data Management, Comm Configuration, Network Settings, User Management, Firmware Upgrade, Restore, Password Settings, UHF Reader Settings and Developer. P a g e | 17 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 19: Device Information

    After setting the time as needed, [Save] users can click [Save] to apply the changes. Click [Time Settings] on the Setup. P a g e | 18 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 20: Data Management

    Push protocol allows to communicate with various software platforms. To use this feature, set the corresponding parameters here. Note: Parameters in the POMS Configuration need to be set only when communicating with the Parking Operation and Maintenance System. P a g e | 19 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 21: Network Settings

    HTTP Port: Enter the corresponding port (the default port number is 80).  TCP Port: Enter the corresponding port (the default port number is 14370).  Click [Save] after setting the parameters.  P a g e | 20 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 22: User Management

    To upgrade the device firmware, click [Browse] and select the firmware upgrade file in the format of .tgz, and click [Update]. After upgrading the firmware, restart the device. Click [Firmware Upgrade] on the Setup. P a g e | 21 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 23: Restore

    Restores the device parameter settings. With this function, all the settings of the device can be restored to factory default values. Click [Restore], select the parameters to be restored, and click [OK]. P a g e | 22 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 24 AMTL-UHF-10 User Manual Reboot It restarts the system. P a g e | 23 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 25: Password Settings

    Output Bit Count: Select the Wiegand output bit count for the device. The default Wiegand  format is WG26, and it can be set as WG34, WG42, WG50, WG58, WG66, WG74, WG82, WG90, WG98. P a g e | 24 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 26: Developer

     Click [Factory Default] to restore the device to factory parameters.  8.3.11 Developer Click [Developer] on the Setup. Telnet Settings Whether to enable telnet function. P a g e | 25 Copyright © 2025 ARMATURA LLC. All rights reserved.
  • Page 27 AMTL-UHF-10 User Manual Network Diagnosis Tests whether you can ping the server. P a g e | 26 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 28: Log

    The user can filter the search list with options such as search type, start time, end time, and the number of log results per page. After selecting the criteria, click [Search] to related logs. P a g e | 27 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 29: Eco-Friendly Operation

    The components which contain toxins or harmful elements are included due to the current economic or technical limitations which prevent their replacement with non-toxic materials or elements. P a g e | 28 Copyright © 2025 ARMATURA LLC. All rights reserved.

  • Page 30: Fcc Warning

    This transmitter must not be co-located or operating in conjunction with any other antenna or  transmitter. IMPORTANT! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. P a g e | 29 Copyright © 2025 ARMATURA LLC. All rights reserved.
