AMT -21
Thank you for choosing our product. Please read the instructions carefully
before operation. Follow these instructions to ensure that the product is
functioning properly. The images shown in this manual are for illustrative
purposes only.
P a g e
| 1
User Manual
AMT-FAM-10
Date: October 2022
Doc Version: 1.2
English
For further details, please visit our Company's website
www.armatura.us.
Copyright© 2022 ARMATURA LLC. All rights reserved.
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMT-FAM-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for ARMATURA AMT-FAM-10

  • Page 1 Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only. For further details, please visit our Company’s website www.armatura.us. P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 2 The copyright in all the documents, drawings, etc. in relation to the ARMATURA supplied product vests in and is the property of ARMATURA. The contents hereof should not be used or shared by the receiver with any third party without express written permission of ARMATURA.
  • Page 3 The entire risk as to the results and performance obtained from using the information is assumed by the user. ARMATURA in no event shall be liable to the user or any third party for any incidental, consequential, indirect, special, or exemplary damages, including, without limitation, loss of...
  • Page 4 About the Manual This manual introduces the operations of AMT-FAM-10, a dual-lens near-infrared light and visible light face module. All figures displayed in this manual are for illustration purposes only which may not be exactly consistent with the actual product.
  • Page 5 The general information which helps in performing the operations faster. The information which is significant. Care taken to avoid danger or mistakes. The statement or event that warns of something or that serves as a cautionary example. P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 6: Table Of Contents

    ..........................18 NSTALLATION ETHOD ........................20 ERTICAL OUNT PPROACH ......................... 20 ILTING OUNT PPROACH ............... 21 ECOMMENDED NSTALLATION EIGHT AND OUNTING NGLE 10 FACIAL EXPRESSIONS AND STANDING POSTURE ..............21 P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 7: Product Introduction

    It supports USB interface communication and external power supply in one single cable. AMT-FAM-10 utilizes the Infrared light imaging sensor to capture grayscale face images for face recognition process by integrating with AMT FaceLite SDK, and the visible light camera captures the true color face image for display and other relevant process.
  • Page 8: Product Specifications

    1.0W (Standby) / 1.75W (Operating) Dimensions 60 * 22 * 19.30 mm (±1 mm) Certifications CE, FCC, RoHS Electrical Features Specifications Test Conditions Standard Operating Voltage 4.75V 5.0V 5.25V P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 9: Optical And Image Specifications

    Diagonal = 74° , Horizontal = 40° , Vertical = 65° Optical Distortion Rate ≤1% Lens Composition Composed of 4-Plastic Lens and an IR-Filter (4P+1IR) Default Output Format MJPEG P a g e Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 10: Model Specifications

    The SDK libraries assist to enhance the security requirements through facial recognition which protects spoofing attach and is widely used in various business applications, including attendance, P a g e | 10 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 11: Application Scenarios

    480W x 640H pixel and on quad-core Cortex-A9 @1.5 GHz processor platform. Application Scenarios The AMT-FAM-10 module is optimized on its physical structure for the purpose of the built-in design and integration, facilitating easy and fast integration into third-party hardware device.
  • Page 12: Structural Dimensions

    AMT-FAM-10 User Manual Structural Dimensions Figure 5.1 Bottom view Figure 5.2 Side view Figure 5.3 Top view P a g e | 12 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 13: Pin Socket Definition

    Figure 6.1 below. Figure 6.1 J1 Connector (7 Pin) Pin Description J1 (7 Pin / 1.25 mm) Detail Shield GND USB- USB+ Reserved Reserved P a g e | 13 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 14: Pin Socket Dimensions

    26AWG wire. The wire is on the side of the module with a magnetic ring. The reference design diagram is in the figure 7.1 below. P a g e | 14 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 15: Plug Wire

    64 or more to enhance the anti-interference of the USB cable. The reference design diagram is shown in Figure 7.2. Figure 7.2 Plug Interface Design Guide Front Lens Design P a g e | 15 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 16 Figure 8.2 Schematic diagram of the distance between the lens and the front transparent material P a g e | 16 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 17: Heat Dissipation Design

    The thickness of the thermal conductive silicone pad is recommended to be less than 3mm. • The schematic diagram of the conductive heat treatment is shown below. Figure 8.4 Schematic diagram of conductive heat treatment P a g e | 17 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 18: Installation Guide

    2.0 mm, as shown in Figure 9.1. Figure 9.1 Location of the mounting holes in the module The module has a positioning hole with an aperture of 1.6 mm, as shown below: • P a g e | 18 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 19 To avoid any damage to the module, the metal casing should not contact other part of the • module. P a g e | 19 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 20: Vertical Mount Approach

    0.4 to 0.8 meters. This can adapt to the height range of 1.5m to 2.2m, as shown in the below image. • P a g e | 20 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 21: Recommended Installation Height And Mounting Angle

    Incorrect facial expressions and standing postures may cause recognition failure. The guide of natural facial expressions and proper standing postures are illustrated in Figure 10.1 and 10.2, respectively. P a g e | 21 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 22 AMT-FAM-10 User Manual Figure 10.1 The facial expressions illustration Figure 10.2 The standing postures illustration P a g e | 22 Copyright© 2022 ARMATURA LLC. All rights reserved.
  • Page 23 AMT-FAM-10 User Manual 190 Bluegrass Valley Pkwy, Alpharetta, GA 30005 E-mail: info@armatura.us www.armatura.us P a g e | 23 Copyright© 2022 ARMATURA LLC. All rights reserved. Copyright © 2022 ARMATURA LLC. All Rights Reserved.
