HopeRF HPNI01 Quick Start Manual

General Description of HPNI01
HPNI01 is an ultra-low-power, high-performance LoRa
transceiver for various frequency of 868,915
MHz wireless applications.It
SEMTECH RF product line,
complete transmitters, receivers and transceivers.The
high integration of
peripheral materials needed in the
The sensitivity up to - 136 dBm which can optimize
the link performance of applications.In addition,
HPNI01 also supports Duty-Cycle operation mode,
channel interception, high-precision RSSI, power-on
reset, noise output and other more functions, which
makes the application design more flexible thus to
achieve product differentiation
design. The working voltage of HPNI01 is
3.3V. When the sensitivity is reaching -136
dBm, it only consumes
Thisultra-low power mode can further reduce the
power consumption of the chip
Features
•
Frequency Range: 868，915MHz
•
Modulation: LoRa
•
Data Rate: 0.018~37.5 kbps
•
Sensitivity: -136 dBm , BW=125KHz, SF=12
•
Voltage Range: 1.8~3.3V
•
Receiving Current: 12.5 mA @ BW=125KHz
•
BW: Supports a maximum of 500 KHz
•
Supports Ultra Low Power Receiving Mode
•
Sleeping Current:1.5ua
•
4-wire SPI Interface
•
Supports Full-automatic Independent Working Mode
LoRa Transceiver Module
is part of the
which includes
HPNI01 simplifies the
system design.
12.5 mA current.
.
HPNI01 V1.0
1
