- Page 1 Technical Manual 03.011.02 REPLACE CHAIN...
-
Page 2: Safety Warnings
SAFETY WARNINGS Observe your local health and safety guidelines. Ensure a safe working environment. Wear appropriate protective gear. Deviating from the prescribed order may result in injury or damage to the products. TOOLS Chain breaker CONSUMABLES Master link OPERATION TIME 15 Minutes 03.011.02 Replace chain... - Page 3 REMOVAL WARNING Before proceeding with any work on the bike, make sure it is turned off and the charger disconnected. Rotate the rear wheel to place the master link on the lower side of the swingarm and halfway between the front and rear sprockets.
- Page 4 NOTE Take care not to damage the swingarm as the chain clears the rear sprocket. 03.011.02 Replace chain...
-
Page 5: Installation
INSTALLATION WARNING Before proceeding with any work on the bike, make sure it is turned off and the charger disconnected. Run the chain through the chain guide and around the rear spocket. NOTE Take care no to trap your fingers. 2 Run the chain around the front sprocket until both ends meet at the below the swingarm. - Page 6 NOTE The rivet diameter expansion should not exceed 5.5 mm + 0.1/0. 6 Adjust the chain tension. Refer to: 03.011.06 Ajusting the chain tension Ajusting the chain tension ↗. ↗. 03.011.02 Replace chain...
- Page 7 ENG 2023-07 Copyright © 2023 Stark Future SL. All rights reserved. Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission of the copyright owner.
