- Page 1 Skypher Pro Do not use this product before carefully reading this instruction manual and understanding the performance of your e-bicycle. Please keep the instruction manual safe for future reference Phone: +91 8988845555 | Website: www.acerelectric.in | Support email: support@acerelectric.in...
-
Page 2: Parts And Components
PARTS & COMPONENTS 1. Handlebar Tube 2. Grip Cover 3. Mechanic Shifter 4. Display 5. Front Reflector Light 6. Brake Lever 7. Front Light 8. Front Fork 9. Front Wheel Reflector 10. Front Mudguard Stay 11. Tire 12. Wheel Hub 13. -
Page 3: Getting Started
For battery replacement due to damage, please contact our customer service. Refer to page 11 for contact Important: information. • Do not charge your Skypher Pro indoors. When charging outdoors, avoid exposure to rain and direct sunlight on the charger. 3. Power On and Off: •... -
Page 4: Installing The Front Wheel
Right Brake Charging Port Power Switch Derailleur Lever Left Brake Lever Handlebar Battery On/Off Bell Reflector Indicator Button & Light Switch INSTALLING THE FRONT WHEEL 1. Basic Mechanical Principle with the Hub and Anchor Nuts: • Turn the anchor nuts clockwise to increase the clamping force. •... - Page 5 GEARS Skypher Pro is equipped with gears, which consists of: • Rear sprocket cluster, called freewheel or cog set • Rear derailleur • Shifter • Control cable • Front sprocket, called chaining • Drive chain A downshift involves shifting to a lower or slower gear, making pedalling easier, especially for uphill riding.
-
Page 6: Specification
SPECIFICATION Model Skypher Pro Expanded size 1770*605*1050 mm Packing size 1516*240*790 mm Build Wheelbase 1110 mm Pedal ground clearance 120 mm (4.72 inches) Wheel hub 27.5*1.95 inches Weight 23.8 kg Load 120 kg Speed 25 km/h Range in throttle mode... - Page 7 SPECIFICATION Model Skypher Pro Battery type lithium-ion Battery capacity 10Ah Battery rated voltage Charging voltage DC 42V Core Charger input voltage AC100-220V Charging time 4-5 hours Motor rated power 250W Motor rated voltage Controller under voltage value Controller over current value...
-
Page 8: Circuit Diagram
CIRCUIT DIAGRAM DC2. 1 Charging Port Power_36V Power_36V Electrolock_36V Electrolock_36V Display 36V Battery Pack Phase Wire A Hall1 Controller Shifter Motor Phase Wire B Phase Wire C Brake Hall-effect Speed Sensor Left Power Cut-off Brake Lever Brake Right Power Cut-off Brake Lever Hall2 Booster Electrolock... - Page 9 ATTENTION Battery & Charging Do not connect the positive and negative terminal of the battery with conductive materials like wire or metal piece. Do not damage or disassemble the battery. Avoid inserting water and other liquids, or any other foreign objects inside the battery to prevent short circuit. Instructions in this manual must be followed before using the product.
-
Page 10: Maintenance
Only use factory-approved replacement parts to avoid voiding the warranty and assuming full responsibility for any resulting damages. SUPPORT If you have any questions or need assistance with your Skypher Pro, please contact our support team • Email: For general enquiries or technical support, send us an email at: support@acerelectric.in... - Page 11 The Acer or AcerElectric trademark is licensed to THINK EBIKEGO PRIVATE LIMITED by Acer Incorporated.
