Summary of Contents for AMV ELECTRONICA SK1500
-
Page 2: Table Of Contents
Contents 1. Important Safety Instructions……………………………………………… General Safety Precautions…………………………………………… Precautions When Working With Batteries………………………….. 2. Features………………………………………………………………………... Application………………………………………………………………. Electrical Performance………………………………………………… Mechanical Drawings………………………………………………….. 3. Introduction…………………………………………………………………… Front Panel Operations………………………………………………... Rear Panel Operations………………………………………………… 9~10 Protections Features…………………………………………………… Installation………………………………………………………………. Making DC Wiring Connections ……………………………………... 12~13 AC Safety Grounding………………………………………………….. 14~15 Inverter Operation………………………………………………………... -
Page 3: Important Safety Instructions
1. Important Safety Instructions WARNING! Before using the Inverter, read and save the safety instructions. 1-1. General Safety Precautions 1-1-1. Do not expose the Inverter to rain, snow, spray, bilge or dust. To reduce risk of hazard, do not cover or obstruct the ventilation openings. -
Page 4: Features
2. Features Pure sine wave output (THD < 3%) Output frequency 50 / 60Hz switch selectable Input & output fully isolation design Low power “ Power Saving Mode “ to conserve energy High efficiency 88~94% Capable of driving highly reactive & capacitive loads at start moment. Tri-Color indicators display input voltage &... -
Page 5: Electrical Performance
2-2. Electrical Performance Model No. Specification SK1500- SK1500- SK1500- SK1500- SK1500- SK1500- Item Continuous Output Power 1500W Maximum Output Power (3Min.) 1725W Surge Rating 3000W Input voltage 100 / 110 / 120V +/- 3% 220 / 230 / 240V +/- 3%... -
Page 6: Mechanical Drawings
2-3. Mechanical Drawings PURE SINE WAVE INVERTER 1500W INPUT LEVEL LOAD LEVEL STATUS REMOTE FREQ. PWR. SAV. AC OUTPUT... -
Page 7: Introduction
3. Introduction This power inverter series is a the member of the most advanced line of mobile AC power systems available. To get the most out of the power inverter, it must be installed and used properly. Please read the instructions in this manual before installation and operation this model. - Page 8 3-1-3. Input Level Display Input Voltages LED Status DC 12V DC 24V DC 48V RED Blink (slow) 10.5~10.9 21.0~21.8 42.0~43.6 10.9~11.3 21.8~22.6 43.6~45.2 ORANGE 11.3~12.0 22.6~24.0 45.2~48.0 GREEN 12.0~14.0 24.0~28.0 48.0~56.0 ORANGE Blink 14.0~14.7 28.0~29.4 56.0~58.8 OVER RED BLINK 14.7 29.4 58.8 3-1-4.
- Page 9 3-1-6. Status Display Power & Fault Status Green LED LED Signal Status Solid Power OK Blink (Slow) Power Saving Red LED LED Signal Status Blink (Fast) Blink (Slow) Blink (Intermittently) Solid 3-1-7. Power Saving Mode: Power Saving Mode is adjustable and set by the Dip Switches, S1, S2 and S3 on front pan Example: With the watt setting at 20W, a 20W↑...
- Page 10 3-1-8. AC outlets (available): North America (GFCI) NEMA 5-15R Continental European Universal Australia / New Zealand United Kingldom IEC-2...
-
Page 11: Rear Panel Operations
GROUND REVERSE POLARITY WILL DAMAGE UNIT 3-2-1. Remote Port: The SK1500 Series Inverter can be compatible with any of remote controllers, CR-6, CR-7 or CR-8. Before using the remote unit, make sure the main switch must be “ REMOT E”. -
Page 12: Protections Features
Under INTERIOR HEAT SINK Model Voltage Voltage Shut- Shut- Shut- Shut- Alarm Restart Restart Restart Restart down down down down SK1500-112 15.3 14.2 11.0 10.5 12.5 SK1500-212 SK1500-124 30.6 28.4 22.0 21.0 25.0 SK1500-224 SK1500-148 61.2 56.8 44.0 42.0 50.0... -
Page 13: Installation
3-4. Installation Where to install. The power inverter should be installed in a location that Meets the following requirements 3-4-1. Dry – Do not allow water to drip or splash on the inverter. 3-4-2. Cool – Ambient air temperature should be between 0 and 40 , the cooler the better. -
Page 14: Making Dc Wiring Connections
The longer or narrower the cables, the greater the voltage drop. Increasing your DC cable size will help improve the situation. Following cable recommendations for the best performance of inverte (Apply both 120V and 230V versions Model No Wire AWG Inline Fuse SK1500-112 200A SK1500-212 200A SK1500-124 100A SK1500-224... - Page 15 WARNING! The installation of a fuse must be on positive cable. Failure to place a fuse on “+” cables running between the inverter and battery may cause damage to the inverter and will void warranty. Also, use only high quality copper wire and keep cable length short, a maximum of 3 - 6 feet.
-
Page 16: Ac Safety Grounding
3-6. AC Safety Grounding The AC output ground wire should go to the grounding point for your loads ( for example, a distribution panel ground bus ). 3-6-1. Neutral Grounding (GFCI’S) 3-6-1-1. 120V models The neutral conductor of the AC output circuit of the Inverter is automatically connected to the safety ground during inverter operation. -
Page 17: Inverter Operation
Ground Fault Circuit Interrupters (GFCI) Installations in Recreational Vehicles (for North American approvals) will require GFCI protection of all branch circuit connected to the AC output of the hardwire terminal equipped Inverter. In addition, electrical codes require GFCI protection of certain receptacles in residential installations. While the pure sine wave output of the Inverter is equivalent to the waveform provided by utilities, compliance with UL standards requires us to test and recommend specific GFCI. -
Page 18: Troubleshooting Guide
4. Troubleshooting guide WARNING! Do not open or disassemble the Inverter. Attempting to service the unit yourself may result in a risk of electrical shock or fire. Problems and Symptoms Possible Cause Solutions “No AC Power Output” STATUS illuminates the red LED a. -
Page 19: Maintenance
5. Maintenance Very little maintenance is required to keep your inverter operating properly. You should clean the exterior of the unit periodically with a damp cloth to prevent accumulation of dust and dirt. At the same time, tighten the screws on the DC input terminals. 6. - Page 20 DIRECCIÓN Y TELEFONOS DE CONTACTOS AMV ELECTRONICA SL C/NAVA Nº 7 – BAJO 33207 GIJON ASTURIAS ESPAÑA FAX 00 34 985346795 PAGINA WEB : www.amvelectronica.com TELEFONOS EMAIL DE CONTACTO Teléfono DEPARTAMENTO RESPONSABLE e-MAIL Gracia Comercial y Ventas 985319171 Ext. 10 gracia@amvelectronica.com...
- Page 21 TOTAL DE 2 AÑOS. GARANTÍA CUBRE SITUACIONES DAÑO INTRÍNSECO, Y NO LAS PROVOCADAS POR CAUSAS EXTERNAS O LA MANIPULACIÓN POR PARTE DEL USUARIO. LA GARANTÍA SE ENTIENDE EN NUESTROS TALLERES, SIENDO POR CUENTA DEL USUARIO LOS COSTES DEL TRANSPORTE. AMV ELECTRONICA...
