Summary of Contents for AMV ELECTRONICA SK3000 Series
-
Page 2: Table Of Contents
Contents 1. Important Safety Instructions……………………………………………… General Safety Precautions…………………………………………… Precautions When Working With Batteries………………………….. 2. Features………………………………………………………………………... Application………………………………………………………………. Electrical Performance………………………………………………… Mechanical Drawings………………………………………………….. 3. Introduction…………………………………………………………………… Front Panel Operations………………………………………………... Rear Panel Operations………………………………………………… 10~11 Protections Features…………………………………………………… Installation………………………………………………………………. Making DC Wiring Connections ……………………………………... 13~15 AC Safety Grounding………………………………………………….. 16~17 Inverter Operation………………………………………………………... -
Page 3: Important Safety Instructions
1. Important Safety Instructions WARNING! Before using the Inverter, read and save the safety instructions. 1-1. General Safety Precautions 1-1-1. Do not expose the Inverter to rain, snow, spray, bilge or dust. To reduce risk of hazard, do not cover or obstruct the ventilation openings. -
Page 4: Features
2. Features Pure sine wave output (THD < 3%) Output frequency：50 / 60Hz switch selectable Input & output fully isolation design Low power “ Power Saving Mode “ to conserve energy High efficiency 88~94% Capable of driving highly reactive & capacitive loads at start moment. Tri-Color indicators display input voltage &... -
Page 5: Electrical Performance
2-2. Electrical Performance Model No. Specification SK3000- SK3000- SK3000- SK3000- SK3000- SK3000- Item Continuous Output Power 3000W Maximum Output Power (3Min.) 3450W Surge Rating 6000W Input voltage 100 / 110 / 120V +/- 3% 220 / 230 / 240V +/- 3% Output Voltage Frequency 50 / 60Hz... -
Page 6: Mechanical Drawings
2-3. Mechanical Drawings... -
Page 7: Introduction
3. Introduction This power inverter series is a the member of the most advanced line of mobile AC power systems available. To get the most out of the power inverter, it must be installed and used properly. Please read the instructions in this manual before installation and operation this model. - Page 8 3-1-2. ON / OFF/ REMOTE (Main) switch： Before installing the inverter, make sure the main switch must be “OFF”. Before using the remote unit, make sure the main switch must be “ REMOTE”. 3-1-3. Input Level：Display Input Voltages LED Status DC 12V DC 24V DC 48V...
- Page 9 3. Introduction This power inverter series is a the member of the most advanced line of mobile AC power systems available. To get the most out of the power inverter, it must be installed and used properly. Please read the instructions in this manual before installation and operation this model.
- Page 10 3-1-7. Power Saving is enable and adjusted through dip switches S1, S2 and S3 on the front of the inverter Example: With the watt setting at 40W, a 40W or greater load will “wake up” the inverter and the load will operate normally. Any load less than 40W will not operate and the inverter will remain in power save made.
- Page 11 3-1-8. AC outlets (available): North America (GFCI) NEMA 5-20R Continental European Universal Australia / New Zealand United Kingldom IEC-2 WARNING! Never connect the inverter’s output to the AC distribution grid, such as your household AC wall outlet. It will damage the inverter.
-
Page 12: Rear Panel Operations
3-2. Rear Panel Operations： 3000W 3-2-1. Remote Port: The SK3000 Series Inverter can be compatible with any of remote controllers, CR-6, CR-7 or CR-8. Before using the remote unit, make sure the main switch must be “ REMOTE”. 3-2-2. Fan Ventilation: Do not obstruct, allow at least 1 inch for proper air flow. -
Page 13: Protections Features
3-2-4. Chassis Ground: using # 8 AWG wire to connect vehicle chassis. WARNING! Operation of the inverter without a proper ground connection may result in an electrical safety hazard. 3-3. Protections Features: DC Input (VDC) Over Temperature Protection Under Over Voltage Under INTERIOR HEAT SINK... -
Page 14: Installation
3-4. Installation： Where to install. The power inverter should be installed in a location that Meets the following requirements： 3-4-1. Dry – Do not allow water to drip or splash on the inverter. 3-4-2. Cool – Ambient air temperature should be between 0℃ and 40℃, the cooler the better. -
Page 15: Making Dc Wiring Connections
3-5. Making DC Wiring Connections： Follow this procedure to connect the battery cables to the DC input terminals of the Inverter. Your cables should be as short as possible (Ideally, less than 6 feet / 1.8 meters ) enough to handle the required current in accordance with the electrical codes or regulations application. - Page 16 WARNING! The installation of a fuse must be on positive cable. Failure to place a fuse on “+” cables running between the inverter and battery may cause damage to the inverter and will void warranty. Also, use only high quality copper wire and keep cable length short, a maximum of 3 - 6 feet.
- Page 17 SPRING WASHER PVC WIRE 3-5-1. Unpack and inspect the power inverter to check its performance, switch to OFF position. 3-5-2. Connect the cables to the power input terminals on the rear panel of the inverter. The red terminal is positive (+) and black terminal is negative (-).
-
Page 18: Ac Safety Grounding
3-6. AC Safety Grounding： The AC output ground wire should go to the grounding point for your loads ( for example, a distribution panel ground bus ). 3-6-1. Neutral Grounding (GFCI’S)： 3-6-1-1. 120V models：The neutral conductor of the AC output circuit of the Inverter is automatically connected to the safety ground during inverter operation. -
Page 19: Inverter Operation
Ground Fault Circuit Interrupters (GFCI)： Installations in Recreational Vehicles (for North American approvals) will require GFCI protection of all branch circuit connected to the AC output of the hardwire terminal equipped Inverter. In addition, electrical codes require GFCI protection of certain receptacles in residential installations. While the pure sine wave output of the Inverter is equivalent to the waveform provided by utilities, compliance with UL standards requires us to test and recommend specific GFCI. -
Page 20: Troubleshooting Guide
4. Troubleshooting guide： WARNING! Do not open or disassemble the Inverter. Attempting to service the unit yourself may result in a risk of electrical shock or fire. Problems and Symptoms Possible Cause Solutions “No AC Power Output” STATUS illuminates the red LED a. -
Page 21: Maintenance
5. Maintenance： Very little maintenance is required to keep your inverter operating properly. You should clean the exterior of the unit periodically with a damp cloth to prevent accumulation of dust and dirt. At the same time, tighten the screws on the DC input terminals. - Page 22 DIRECCIÓN Y TELEFONOS DE CONTACTOS AMV ELECTRONICA SL C/NAVA Nº 7 – BAJO 33207 GIJON ASTURIAS ESPAÑA FAX 00 34 985346795 PAGINA WEB : www.amvelectronica.com TELEFONOS EMAIL DE CONTACTO Teléfono DEPARTAMENTO RESPONSABLE e-MAIL Gracia Comercial y Ventas 985319171 Ext. 10 gracia@amvelectronica.com...
- Page 23 TOTAL DE 2 AÑOS. GARANTÍA CUBRE SITUACIONES DAÑO INTRÍNSECO, Y NO LAS PROVOCADAS POR CAUSAS EXTERNAS O LA MANIPULACIÓN POR PARTE DEL USUARIO. LA GARANTÍA SE ENTIENDE EN NUESTROS TALLERES, SIENDO POR CUENTA DEL USUARIO LOS COSTES DEL TRANSPORTE. AMV ELECTRONICA...
