CKMOVA Wicom E User Manual

Full-duplex wireless intercom headset system
Hide thumbs

Advertisement

Table of Contents

Wicom E
Full-Duplex Wireless Intercom Headset System
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wicom E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CKMOVA Wicom E

Summary of Contents for CKMOVA Wicom E

  • Page 1 Wicom E Full-Duplex Wireless Intercom Headset System User Manual...
  • Page 2 Introduction: The CKMOVA Wicom E system is a full-duplex wireless intercom system featuring Environmental Noise Cancellation (ENC) suitable for loud environments. The system includes single-ear headset version and dual-ear headset version for different condition choice. The system features A & B group isolate settings...
  • Page 3 Available Combo: Wicom E S3 (one single-ear master headset + two single-ear remote headsets) Wicom E S5 (one single-ear master headset + four single-ear remote headsets) Wicom E S7 (one single-ear master headset + six single-ear remote headsets) Wicom E S9...
  • Page 4 Available Combo: Wicom E SM5 (one single-ear master headset + two single-ear remote headsets + two dual-ear remote headsets) Wicom E SM9 (one single-ear master headset + four single-ear remote headsets + four dual-ear remote headsets) Wicom E DM5 (one dual-ear master headset + two single-ear remote...

  • Page 5: Product Structure

    Product Structure: 1. Wicom E SM: Single-ear Master Headset 1. Microphone 2. Status Indicator (Group A; Power; Group B) Group A Indicator: Double blinking: under pairing status Single blinking: disconnected Static: connected Dim: Group A isolation Power Indicator: Blue led: >10% power Red led: <10% power...
  • Page 6 3. Group A Button Long press button for pairing remote headset Short press button for isolating group B remote headset 4. Group B Button Long press button for pairing remote headset Short press button for isolating group A remote headset 5.
  • Page 7 2. Wicom E SR: Single-ear Remote Headset 1. Microphone 2. Status Indicator (Group A; Power; Group B) Group A Indicator: Double blinking: under pairing status Single blinking: disconnected Static: connected Power Indicator: Blue led: >10% power Red led < 10% power...
  • Page 8 3. Group A Button Long press button for pairing master headset Group A Short press button for switching to group A 4. Group B Button Long press button for pairing master headset Group B Short press button for switching to group B 5.
  • Page 9 3. Wicom E DM: Dual-ear Master Headset 1. Microphone 2. Status Indicator (Group A; Power; Group B) Group A Indicator: Double blinking: under pairing status Single blinking: disconnected Static: connected Dim: Group A isolation Power Indicator: Blue led: >10% power Red led <...
  • Page 10 3. Group A Button Long press button for pairing remote headset Short press button for isolating group B remote headset 4. Group B Button Long press button for pairing remote headset Short press button for isolating group A remote headset 5.
  • Page 11 4. Wicom E DR: Dual-ear Remote Headset 1. Microphone 2. Status Indicator (Group A; Power; Group B) Group A Indicator: Double blinking: under pairing status Single blinking: disconnected Static: connected Power Indicator: Blue led: >10% power Red led < 10% power...
  • Page 12 3. Group A Button Long press button for pairing master headset Group A Short press button for switching to group A 4. Group B Button Long press button for pairing master headset Group B Short press button for switching to group B 5.

  • Page 13: How To Wear Headset

    Operation Guide: How to wear headset 1. Adjust the headset to the comfortable size and position 2. Adjust the microphone 2cm away from your mouth for optimal audio Headsets Mute : Communication : Mute On...

  • Page 14: Frequency Band Selection

    Frequency Band Selection There are five frequency band versions as below: Standard Version: 1880-1900MHz American Version: 1920-1930MHz Brazilian Version: 1910-1920MHz Japanese Version: 1893-1906MHz Taiwanese Version: 1880-1895MHz Make sure the master headset is power off, long press group A button then press power button, till the group A led light is blinking that mean enter “selecting frequency band status”, short press “+”...
  • Page 15 Headsets Pairing The default is paired before leaving factory, if they are disconnected or adding more remote headsets to master, please follow the below steps: (1): Make sure the master headset and remote headset are powered on (2): Long press master headset Group A or Group B button then related indicator double blinking that mean master headset is under pairing, then long press remote headset Group A or Group B then...
  • Page 16 Clearing headsets paired Long press group A button on master headset for about 3 seconds till the A light blinking, then short press “+” button 7~10 times on master headset till the A&B lights blinking together and change to off, then waiting to clear the connection to all remote headsets.
  • Page 17 A & B Group Isolate Setting Short press Group A button on master headset enables isolate all Group B remote headsets, then the master headsets can only communicate with Group A remote headsets. Short press Group B button on master headset enables isolate all Group A remote headsets, then the master headsets can only communicate with Group B remote headsets.
  • Page 18 A & B Group Manage Setting The remote headset conveniently switch to group A or group B (group A + group B up to 8 remote headsets) Noted: Before manage group, make sure the headset is paired Short press power button on master or remote headset then entering ENC functions, it hepls to reduce ambient noise, enables the users using in some loud noise environments, short press again then exit.
  • Page 19 PPT Talk Long press “+” button on master headset about 3 seconds then entering PPT talk mode, it enables the master headset user hear their voice when talking, long press about 3 seconds again then exit. ANNOUNCE Long press and hold “-” button on master headset then activating this function, all remote headsets are instantly muted, allowing the entire team to only hear the instructions from master headset, release button then exit.

  • Page 20: Battery Charging

    Cloud Meetings Master headset connect computer via AC-T3C(not included) for cloud meetings Battery charging Please charge the battery when battery is low 1. Charge the battery via charger 2. Charge the battery via headset type-c port directly...

  • Page 21: Specifications

    Specifications: Standard Version: 1880-1900MHz American Version: 1920-1930MHz Frequency Band Brazilian Version: 1910-1920MHz Japanese Version: 1893-1906MHz Taiwanese Version: 1880-1895MHz Full-Duplex Duplex Mode: Modulation: GFSK Microphone Type: Condenser Microphone Operation Range: 1312ft(400m) Frequency Response: 300Hz-5kHz <1% Distortion: SNR: 65dB and more RF Output Power: <24dBm Power Consumption: <0.5W...

  • Page 22: Packing List

    Packing List Wicom E S3 Wicom E S5 Wicom E SM headset x 1 Wicom E SM headset x 1 Wicom E SR headset x 2 Wicom E SR headset x 4 BL-5C battery x 3 BL-5C battery x 5...
  • Page 23 Wicom E D5 Wicom E D3 Wicom E DM headset x 1 Wicom E DM headset x 1 Wicom E DR headset x 4 Wicom E DR headset x 2 BL-5C battery x 5 BL-5C battery x 3 AC-BC9 battery charger x 1...
  • Page 24 Wicom E SM9 Wicom E SM5 Wicom E SM headset x 1 Wicom E SM headset x 1 Wicom E SR headset x 4 Wicom E SR headset x 2 Wicom E DR headset x 4 Wicom E DR headset x 2...
  • Page 25 Shenzhen Shenyao Technology Co., Ltd 深圳市神堯科技有限公司 CKMOVA is the trademark of Shenzhen Shenyao Technology Co., Ltd Add: Floor 6, 38th Building, BaoNan Street, LongGang District, Shenzhen Guangdong, China Email: sales@ckmova.com Web: www.ckmova.com...

This manual is also suitable for:

Wicom e s3Wicom e s5Wicom e s7Wicom e s9Wicom e d3Wicom e d5 ... Show all
