- Page 1 Wicom E S5 5-Person Full-Duplex 1.9GHz Wireless Single-Ear Headset Intercom System User Manual...
- Page 2 Introduction: The CKMOVA Wicom E S5 system is a 5-person full-duplex single-ear headset wireless intercom system featuring Environmental Noise Cancellation (ENC) suitable for loud environments. It contains 1 single-ear master headset and 4 single-ear remote headsets. The system features A & B group isolate settings...
-
Page 3: Product Structure
Product Structure: 1. Wicom E SM: Single-ear Master Headset 1. Microphone 2. Status Indicator (Group A; Power; Group B) Group A Indicator: Double blinking: under pairing status Single blinking: disconnected Static: connected Dim: Group A isolation Power Indicator: Blue led: >10% power Red led: <10% power Blinking led: charging battery Static led: battery full... - Page 4 3. Group A Button Long press button for pairing remote headset Short press button for isolating group B remote headset 4. Group B Button Long press button for pairing remote headset Short press button for isolating group A remote headset 5.
- Page 5 2. Wicom E SR: Single-ear Remote Headset 1. Microphone 2. Status Indicator (Group A; Power; Group B) Group A Indicator: Double blinking: under pairing status Single blinking: disconnected Static: connected Power Indicator: Blue led: >10% power Red led < 10% power Blinking led: charging battery Static led: battery full Group B Indicator:...
- Page 6 3. Group A Button Long press button for pairing master headset Group A Short press button for switching to group A 4. Group B Button Long press button for pairing master headset Group B Short press button for switching to group B 5.
- Page 7 Operation Guide: How to wear headset 1. Adjust the headset to the comfortable size and position 2. Adjust the microphone 2cm away from your mouth for optimal audio Headsets Mute : Mute On : Communication...
- Page 8 Headsets Pairing The default is paired before leaving factory, if they are disconnected or adding more remote headsets to master, please follow the below steps: : Make sure the master headset and remote headset are powered on : Long press master headset Group A or Group B button then related indicator double blinking that mean mater headset is under pairing, then long press remote headset Group A or Group B then related indicator double blinking...
- Page 9 Noted: 1. Each Group can have a maximum of eight remote headsets paired simultaneously 2. Each master can have a maximum of eight remote headsets paired simultaneously After paired master & remote headsets keep connected code, so no need to re-pair again in next time A &...
- Page 10 A & B Group Manage Setting The remote headset can conveniently switch to group A or group B (group A + group B up to 8 remote headsets) Noted: Before manage group, make sure the headset is paired Headsets Expanding Expandable system up to 18 headsets for connecting via AC-T3S(not included) to two master headsets...
- Page 11 PPT Talk Short press power button on master headset then entering PPT talk mode, it enables the master headset user hear their voice when talking, short press again then exit. ANNOUNCE Long press and hold “-” button on master headset then activating this function, all remote headsets are instantly muted, allowing the entire team to only hear the instructions from master headset, release button then exit.
-
Page 12: Battery Charging
Cloud Meetings Master headset connect computer via AC-T3C(not included) for cloud meetings Battery charging Please charge the battery when battery is low 1. Charge the battery via charger 2. Charge the battery via headset type-c port directly... -
Page 13: Specifications
Specifications: Frequency Band 1920-1930MHz (only in US) Note: if you travel to other countries with this product, you need to follow local regulatory requirements. Please contact us for questions. Duplex Mode: Full-Duplex Modulation: GFSK Microphone Type: Condenser Microphone Operation Range: 1148ft(350m) Frequency Response: 300Hz-5kHz... -
Page 14: What's In The Box
BaoNan Street, LongGang District, Shenzhen Guangdong, China Email: info@swit.us Web: www.switusa.com Manufacturer Information Shenzhen Shenyao Technology Co., Ltd CKMOVA is the trademark of Shenzhen Shenyao Technology.,Ltd Add: Floor 6, 38th Building, BaoNan Street, LongGang District, Shenzhen Guangdong, China Email: sales@ckmova.com Web: www.ckmova.com...
