PANIO CQ4310K User manual
Button operation instructions
1: Short press, input 1 signal full screen, long press for 3 seconds, switch input 1 to ring outlet output;
2 : Short press, input 2 signal full screen, long press for 3 seconds, switch input 2 to ring outlet output;
3 : Short press, input 3 signal full screen, long press for 3 seconds, switch input 3 to ring outlet output;
4 : Short press, input 4 signal full screen, long press for 3 seconds, switch input 4 to ring outlet output;
: Short press once to display four images on dual screens at the same time; press once again to
display two images on dual screens separately;
Scenes : cyclic switching of three internal scenes of M1, M2, and M3;
Audio : cyclically switches the internal audio of the 4-channel HD input signal source, and
simultaneously de-embeds the output through the 3.5mm analog audio interface;
Resolution : Cycle through different output resolution displays.
