- Page 1 PANIO CQ4155K User Manual...
- Page 2 Contents 1、Split mode switching .................... 2 2、KVM function operation ..................3 3、Aspect Ratio Preservation Mode ................3 4、Audio settings ....................... 4 5、Menu Functions ....................5 6、Software Control ....................5 7、Software operation ....................6 8、Resolution Settings ....................9 9、Central Control Commands .................. 9 １...
- Page 3 Packing 1 x CQ4155K 1 x AC power cord 1 x IR (battery not provided) 1 x Quick guide 1. Split mode switching The display mode of the video splitter can be switched via the chassis buttons, computer keyboard, or infrared remote control.
- Page 4 2. KVM function operation To switch display modes or edit content on the four connected computers, use the single set of keyboard and mouse. To initiate a mode switch, press and hold the * key, then press the corresponding function key. For example, to switch to a quad-split mode, press and hold *, then press 0.
- Page 5 Left and right splitting without deformation: Switch to the left and right split display mode, press the menu key on the remote control to switch to the following screenshot modes. Vertical Split Aspect Ratio Preservation Mode: When switching to the vertical split mode, press the [corresponding button] on the remote control to activate the aspect ratio preservation mode.
- Page 6 5. Menu Functions Signal Source: Switch the input signal source for windows 1, 2, 3, and 4. Example: You can switch the input signal source of window 1 from HDMI1 to HDMI2, HDMI3, or HDMI4. Example: You can switch the input signal source of window 2 from HDMI2 to HDMI1, HDMI3, or HDMI4. ...
- Page 7 7. Software operation Please download the CQ4155K software from the official website, unzip it, and run the Quarsystem file. https://www.epanio.com.tw/download/CQ4155K.zip Open the "Settings" in the upper left corner of the software, check if the port number matches the port number of the control computer device manager, confirm that it is correct, and then click "Confirm", as shown in the settings...
- Page 8 Bring to Top: In the overlay, selecting any number from 1 to 4 will connect the corresponding input source and display it on the first overlay layer. Poll: Set up scene cycle display. Default scenarios: Built-in 16 quick scene recall keys. ...
- Page 9 B. Functional Area: Quick settings for single-screen display, left-right split display, top-bottom split display, three-screen split display, four-screen split display, picture-in-picture, and more. C. Resolution: When setting the output, please make sure to choose the same resolution as specified in the menu. D.
- Page 10 8. Resolution Settings The product supports the following output resolutions: 1280x720@60Hz, 1920x1080@60Hz, 2560x1440@60Hz, and 3840x2160@30Hz. Resolution can be adjusted using either the remote control or the chassis buttons: Remote Control: Use the remote control to access the menu and adjust the resolution. ...
- Page 11 0x05,0x36,0x51,0x67,0x0a Switch the fourth window to HDMI2 input. 0x05,0x36,0x52,0x67,0x0a Switch the fourth window to HDMI3 input. 0x05,0x36,0x53,0x67,0x0a Switch the fourth window to HDMI4 input. Resolution: 3840*2160@30Hz： 0x05,0x32,0x38,0x67,0x0a 2560*1440@60Hz： 0x05,0x32,0x37,0x67,0x0a 1920*1080@60HZ： 0x05,0x32,0x36,0x67,0x0a 1280*720@60HZ： 0x05,0x32,0x35,0x67,0x0a Aspect ratio：...
