V-Sol 1GE DUAL MODE ONU User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
广 州 芯 德 通 信 科 技 股 份 有 限 公 司
Guangzhou V-Solution Telecommunication Technology Co., Ltd.
1GE DUAL MODE ONU
USER MANUAL
Version V1.0
Release Date 2020-08-24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1GE DUAL MODE ONU and is the answer not in the manual?

Questions and answers

Related Manuals for V-Sol 1GE DUAL MODE ONU

Summary of Contents for V-Sol 1GE DUAL MODE ONU

  • Page 1 广 州 芯 德 通 信 科 技 股 份 有 限 公 司 Guangzhou V-Solution Telecommunication Technology Co., Ltd. 1GE DUAL MODE ONU USER MANUAL Version V1.0 Release Date 2020-08-24...

  • Page 2: Table Of Contents

    1GE Dual Mode ONU User Manual Contents Chapter 1 Product Introduction................... 1 1.1 Product Description....................1 1.2 Special features.....................1 1.3 Technical Parameter..................... 1 1.4 Application chart....................2 1.5 Panel description....................3 Chapter 2 Quick Installation..................5 2.1 Standard Packing Contents...................5 2.2 Quick Installation....................5 Chapter 3 Configuration....................7...
  • Page 3 1GE Dual Mode ONU User Manual 3.5.3 Port Forwarding................... 29 3.6 Administration....................30 3.6.1 User Management..................30 3.6.2 Login Timeout..................... 30 3.6.3 System Management..................31 3.6.4 Diagnosis......................32 3.6.5 Loopback Detection..................34 3.6.6 LED Control....................36 3.8 Help........................36 Page II...

  • Page 4: Chapter 1 Product Introduction

    1GE Dual Mode ONU User Manual Chapter 1 Product Introduction 1.1 Product Description 1GE Dual mode ONU meets telecom operators FTTO (office), FTTD (Desk), FTTH(Home) broadband speed, SOHO broadband access, video surveillance and other requirements and design EPON/GPON Gigabit Ethernet products. It is based on mature and stable, cost-effective EPON/GPON technology, high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees.

  • Page 5: Application Chart

    1GE Dual Mode ONU User Manual Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm Transmission distance: 20KM Wavelength Tx1310nm,Rx 1490nm Optical interface SC/PC connector 1* 10/100/1000Mbps auto adaptive Ethernet interfaces. Full /Half Interface Duplex, RJ45 connectors. Indicator 3 indicators, SYS, LINK/ACT, REG.

  • Page 6: Panel Description

    1GE Dual Mode ONU User Manual 1.5 Panel description Interface/Button panel Figure 1-3: Interface/Button panel Name Function Connect to OLT by SC type fiber connector, single mode optical fiber cable. Connect PC or other devices with Ethernet port by Cat5 cable, RJ-45 connector.
  • Page 7 1GE Dual Mode ONU User Manual Blink Normal running Page 4...

  • Page 8: Chapter 2 Quick Installation

    1GE Dual Mode ONU User Manual Chapter 2 Quick Installation 2.1 Standard Packing Contents When you received our product, please check carefully to make sure that our products whether have some defects or not. If something wrong with shipping, please contact carrier;...
  • Page 9 1GE Dual Mode ONU User Manual much or too little attenuation over the optical fiber. Please refer to the Layout Description section of this installation manual for normal LED activity. 4. Check all signal levels and services on all the ONU communication ports.

  • Page 10: Chapter 3 Configuration

    1GE Dual Mode ONU User Manual Chapter 3 Configuration After finishing the basic connection configuration, you can use its basic function. In order to satisfy individuation service requirements, this charter provides the user parameter modification and individuation configuration description. This model of ONU is designed as SFU(single family unit, bridge mode), there is no bridge mode WAN in ONU.

  • Page 11: Status

    1GE Dual Mode ONU User Manual For security, you will be asked to modify password after you logged in by default password. The new password must meet the requirements that display on the webpage. After submitted, it requires you to login by new password.

  • Page 12: Network Interface

    1GE Dual Mode ONU User Manual Figure 3-3: Device Information 3.2.2 Network Interface 3.2.2.1 WAN Connection This page shows WAN connection information you have configured. Figure 3-4: WAN Connection 3.2.2.2 PON Inform This page shows the PON information, such as PON state, input power, output power, and optical module voltage, current, temperature.

  • Page 13: User Interface

    1GE Dual Mode ONU User Manual Figure 3-5: PON Information 3.2.3 User Interface This page shows the Ethernet port information, including port status, MAC address and statistics. Figure 3-6: Ethernet Information Page 10...

  • Page 14: Network

    1GE Dual Mode ONU User Manual 3.3 Network 3.3.1 Internet This page allows user to configure router mode WAN connection. You can only configure route mode WAN connections here. The device default settings is bridge mode(without any WAN). Figure 3-7: WAN Connection...
  • Page 15 1GE Dual Mode ONU User Manual New Connection Name of new connection that you want to create. Name Checked indicates the packets are transmitted by the PON Enable port take VLAN tag. Unchecked indicates the packets are VLAN transmitted by the PON port don’t take VLAN tag.

  • Page 16: Lan

    1GE Dual Mode ONU User Manual Method of WAN connection obtains Global Unique IPv6 GUA From Address. DNSv6 From Method of WAN connection obtains DNSv6. Prefix Delegation Method of prefix delegation. From 3.3.2 LAN This page supports the management of the ONU's IP address, dynamic address management, including dynamic address distribution and relevant parameters distribution, such as lease time, address range, DHCP Proxy, etc.
  • Page 17 1GE Dual Mode ONU User Manual Enable DHCP Server Switch of ONU DHCP server. Start IP Address The start IP address of DHCP IP pool. End IP Address The end IP address of DHCP IP pool. Assign ISP Checked indicates LAN DHCP will use ISP DNS. Unchecked indicates LAN DHCP use DNS that set in the textbox.
  • Page 18 1GE Dual Mode ONU User Manual Figure 3-10: LAN IPv6 Address Settings 3.3.2.4 Prefix Management This page is used to configure IPv6 prefix parameters. Figure 3-11: Prefix Management 3.3.2.5 Port Service(Ipv6) This page is used to configure DHCPv6 and RA function of LAN port.

  • Page 19: Pon Settings

    1GE Dual Mode ONU User Manual Figure 3-12: Port Service(IPv6) 3.3.3 PON Settings 3.3.3.1 LOID This page allows user to configure LOID and password which are used for registering to OLT. Figure 3-13: LOID settings 3.3.3.2 SN This page allows user to configure GPON SN and password which are used for...
  • Page 20 1GE Dual Mode ONU User Manual registering to OLT. Figure 3-14: GPON SN Settings 3.3.3.3 PON Mode This page allows user to configure PON mode when connected to corresponding system. AUTO: ONU will detect PON mode and shift to proper PON mode.

  • Page 21: Routing(Ipv4)

    1GE Dual Mode ONU User Manual 3.3.4 Routing(Ipv4) 3.3.4.1 Default Gateway configure default gateway of ONU This page allows user to . Just need to specify the WAN connection that connected to the gateway. Figure 3-16: Default Gateway 3.3.4.2 Static Routing This page allows user to specify a WAN connection as the Route Interface, and then configure destination IP, mask and gateway.

  • Page 22: Security

    1GE Dual Mode ONU User Manual Parameter Illustration WAN Connection Select WAN connection as static routing interface. Network Address Destination network address. Subnet Mask The Mask of destination network address. Gateway Gateway IP address of static routing. 3.3.4.3 Routing Table This page displays IP routing rules.
  • Page 23 1GE Dual Mode ONU User Manual Figure 3-19: Firewall Level Parameter Illustration Enable Anti-Hacking Anti-Hacking Protection switch. Protection Low: Allow all inner or outer hosts to access. Middle: Allow inner or outer hosts which are limited by the Firewall Level rules that have been created to access.
  • Page 24 1GE Dual Mode ONU User Manual Figure 3-20: Custom Firewall Rule Parameter Illustration IP Version Select IPv4 or IPv6. Name Firewall rule name. Enable Enable or disable the rule. Order Order of the rule. Select protocol which the rule used for. There are only Protocol several protocols can be selected.

  • Page 25: Service Control

    1GE Dual Mode ONU User Manual Address Destination IP Mask Mask of destination IP address. Start destination TCP or UDP port. The protocol must be Start Destination Port TCP or UDP. End destination TCP or UDP port. The protocol must be TCP End Destination Port or UDP.

  • Page 26: Mac Filter

    1GE Dual Mode ONU User Manual Service List Service list for IP filter. User also can configure remote access port for different service, such as http and telnet. Figure 3-22: Remote Access Port 3.4.3 MAC Filter This page allows user to set the relevant parameters of the MAC filter function. The table will display the MAC Filter rules after setting completed.

  • Page 27: Application

    1GE Dual Mode ONU User Manual Figure 3-23: MAC Filter Parameter Illustration Enable Enable or disable the rule. Mode Data transfer mode, including discard or permit. Type Select ONU working mode that the rule takes effect. Protocol Select protocol of data traffic.
  • Page 28 1GE Dual Mode ONU User Manual Figure 3-24: IGMP Mode 3.5.1.2 Basic Configuration This page allows user to configure IGMP basic configuration, including multicast aging time and non-fast leave. Figure 3-25: IGMP Basic Configuration 3.5.1.3 VLAN Configuration This page allows user to configure multicast VLAN for the port. If WAN VLAN is not the same as LAN VLAN, it means multicast VLAN will be translated.
  • Page 29 1GE Dual Mode ONU User Manual Figure 3-26: Multicast VLAN 3.5.1.4 Tag Configuration This page allows user to configure multicast VLAN untag mode. Figure 3-27: Tag Configuration 3.5.1.5 Maximum Address Configuration This page allows user to configure maximum multicast address.

  • Page 30: Bpdu

    1GE Dual Mode ONU User Manual Figure 3-28: Maximum Address Configuration 3.5.2 BPDU This page allows user to enable or disable RSTP BPDU(Bridge Protocol Data Unit) forwarding. Figure 3-29: BPDU Forwarding 3.5.3 DNS Service Page 27...
  • Page 31 1GE Dual Mode ONU User Manual 3.5.3.1 Domain Name This page allows user to configure domain name of ONU. Users can access ONU webpage by this domain name. Figure 3-30: Domain Name 3.5.3.2 DNS This page allows user to configure DNS server. DNS request will be sent to these DNS servers.

  • Page 32: Port Forwarding

    1GE Dual Mode ONU User Manual 3.5.3 Port Forwarding This page allows user to configure port forwarding. Figure 3-32: Port Forwarding Parameter Illustration Enable Enable or disable port forwarding rule. Name Name of the port forwarding rule. Protocol Protocol of the port forwarding rule, including TCP and UDP.

  • Page 33: Administration

    1GE Dual Mode ONU User Manual 3.6 Administration 3.6.1 User Management This page allows user to change password of current login username. Figure 3-33: User Management 3.6.2 Login Timeout This page allows user to set webpage login timeout. If don’t operate the webpage for the time out, the account will logout automatically.

  • Page 34: System Management

    1GE Dual Mode ONU User Manual Figure 3-34: Login Timeout 3.6.3 System Management 3.6.3.1 System Management This page allows user to reboot the device, restore factory default and restore backup configuration. The process of reboot will take several minutes. Figure 3-35: System Management 3.6.3.2 Software Upgrade...

  • Page 35: Diagnosis

    1GE Dual Mode ONU User Manual Figure 3-36: Software Upgrade 3.6.3.3 Configuration Management This page allows user to backup and restore configuration. Figure 3-37: Configuration Management 3.6.4 Diagnosis 3.6.4.1 PING Diagnosis This page shows about the ping test. You can diagnose connection status between ONU and other devices.
  • Page 36 1GE Dual Mode ONU User Manual Figure 3-38: PING Diagnosis Parameter Illustration IP Address or Host Input the destination IP you want to ping. Name Egress Select the egress interface you want to ping. 3.6.4.2 Mirror Configuration This page allows user to set port mirror for troubleshooting. After configured port mirror, the traffic of WAN connection will be copied and sent to LAN port.

  • Page 37: Loopback Detection

    1GE Dual Mode ONU User Manual Parameter Illustration Source Select WAN connection as mirrored interface. Destination The LAN port is mirroring interface. 3.6.5 Loopback Detection 3.6.5.1 Basic Configuration This page allows user to set basic parameters of loopback detection. Figure 3-40: Basic Configuration...
  • Page 38 1GE Dual Mode ONU User Manual Figure 3-41: Enable Configuration Parameter Illustration Loopback Enable Enable or disable LAN port loopback detection. Alarm Enable Enable or disable LAN port loopback alarm. Portdislooped Enable Enable or disable LAN port automatic recovery. 3.6.5.3 VLAN Configuration This page allows user to set VLAN of loopback detection packet.

  • Page 39: Led Control

    1GE Dual Mode ONU User Manual Figure 3-42: VLAN Configuration 3.6.6 LED Control This page allows user to turn off or turn on the LED indicators. Figure 3-43: LED Control 3.8 Help The Help information of ONU displays instruction and prompt of each web UI.
  • Page 40 1GE Dual Mode ONU User Manual Page 37...
