- Page 1 DRIVING VIDEO RECORDER Instruction Manual DR-120 Thank you for purchasing this product. For correct usages and application, please read this instruction manual thoroughly. ver. 1.0 PRINTED IN KOREA * Design and Specifications are subject to change without notice.
-
Page 3: Table Of Contents
CONTENTS SAFEGUARD INSTRUCTIONS ............4 PRODUCT FEATURE ..............5 COMPONENTS ................5 PARTS ....................6 INSTALL IN YOUR CAR ............... 7 ..............8 PRODUCT OPERATION ............. 8 - Power On/Off & Recording Status .................... 9 - F/W Update ..................... 9 - Malfunction .................. -
Page 4: Safeguard Instructions
Safeguard Instructions GPS antenna must be free of any obstructions, ex. navigation systems. - It may cause problem with GPS signal reception. GPS function requires acquisition time when powered on. - Signal acquisition may take a few seconds or longer depending on operating environ- ment. -
Page 5: Product Feature
PRODUCT FEATURE - AUTO RECORDING (DIRIVING, ACCIDENT, ETC..) - H.264 - PC VIEWER MANAGER - Trigger (CAM1 / CAM2) - Min. 16GB to Max. 128G SD card support (MLC Class 10 Type) - Lock system - EXTERNAL MIC. - BEEP SOUND (EVENT RECORDING, FIRM WARE UPDATE & ETC.) - MUTE - External GPS Antenna - Integrated 3G-Sensor... -
Page 6: Parts
PARTS DR-120 Front of DVR body Back of DVR body 1. SD CARD INSERTION HOLE 6. GPS TERMINAL 2. LED (POWER & EVENT/GPS/AUDIO) 7. VIDEO OUT TERMINAL 3. MUTE BUTTON 8. POWER CABLE 4. TRIGGER SENSOR CONNECTION TERMINAL 9. USB PORT (WIFI / OPTION) -
Page 7: Install In Your Car
INSTALL IN YOUR CAR Please check the following points prior to installation: - Turn off the product before installation, and install the product with the car key taken out. - Do not use any other unverified cable except for the supplied cable. - The vehicle which has dark sunting or metallic sunting can be influenced on low GPS receiver rate. -
Page 8: Product Operation
PRODUCT OPERATION Please noted followings before operating the product. - Please do not touch the device during driving. - Please connect GPS, VIDEO OUT, MIC before turn on the vehicle. - After device power on, there could be device rebooting. This is not device fault. - Recording is only possible when the MEMORY is inserted. -
Page 9: F/W Update
F/W Update 1. During firmware update, POWER/GPS/AUDIO LEDs are all flicker- ing at intervals of a second and occurring beep sound until comple- GPS AUDIO tion. MUTE POWER/ EVENT If adjust SD card bigger than 64G capacity, please follow below information. - Our device supports FAT32 format automatically at the first time use. -
Page 10: Buzzer And Led Status
BUZZER AND LED STATUS * In Connection with Cameras POWER/ Status GPS LED AUDIO LED BEEP EVENT LED Light on After Light on and out After Light on and out STAND-BY (Booting) Flickering per second Flickering per second F/W Update / SD Card Format Flickering per second Flickering per second Flickering per second... -
Page 11: Pc Viewer Manager
PC VIEWER MANAGER * Recommended PC specifications for PC VIEWER MANAGER CPU : Pentium 2.0GHz or more Memory : 1GB RAM or more OS : WINDOW XP/VISTA/WINDOW7/8 HDD : 1GB or more supported VIDEO : Geforce 4 or more How to install & Execute PC VIEWER MANAGER Installation of PC VIEWER MANAGER. -
Page 12: About User Interface
About User Interface 1. Play screen Display quad recorded video 2. 3G sensor Display 3G sensor information. 3. Volume control Adjusts sound. (mute/volume +,-) 4. Movie control Previous File/Backward/Play(Pause)/Forward/Next File 5. Play speed control Adjusts play speed (x1/4 ~ x4) 6. -
Page 13: File List
File list Normal file list screen Extend file list screen 1. Import file 1. Click [File open] button in the file list. 2. Select the file to be imported, and then click the [OK] button. 3. If connected drive can’t be checked, please try to open “open other folder”. -
Page 14: File Attribute
File Attribute [ALL] All recorded files are displayed and will be classified as normal or event files. [EVENT] All event files are displayed and classified by type. [LOG] Power, Recording ON/OFF, time information of recovered file, etc. are displayed. -
Page 15: Mode Change
Mode Change - Once PC Viewer is displayed, both interior and exterior views are shown simultaneously. (see photo) - Clicking on an image will allow you to toggle between full screen and split screen views. (see photos) <Exterior screen> <Interior screen> Checking GPS information It is possible to view the driving speed, time, direction and location information at the time video was recorded. -
Page 16: Configuration
Configuration Click Configuration button to open the Configuration Window. 1. Speedometer Unit Selects the indication units for GPS information speedometer. 2. Recording Quality Sets the quality of recording. (High/Normal/Low) 3. Shock Sensitivity Sets sensitivity of the 3G sensor into 0~5steps. 4. - Page 17 - The optimal sensitivity of shock sensor varies with the kind of vehicle. Accordingly, first perform driving test with the three levels of sensitivity, and then set the appropriate sensitivity. - It may be different from real time because the time information from checking “Apply to RTC” is applied after SD card inserting.
-
Page 18: Specification
SPECIFICATION DR-120 Video signal Input 1 Channel input Output 1 Output Audio signal 1 Input Recording Resolution 960H (960 x 480) VGA(640X480) CAMERA OPTION Frame 30fps*2 Mode normal / Event (G-sensor) Compression H.264 Memory SD Card (min.16GB ~ max.128GB) Power supply DC 12~24V (with super cap) max.32V... -
Page 19: Check Point Before Service Request
CHECK POINT BEFORE SERVICE REQUEST * You can solve some problems as below with simple check. If you still have a problem though you try as below instruction, please contact to service center or store that you purchased. Q Recording LED is not operating even power is on. A - The key should be locked after inserting hard case with memory. - Page 20 INSTRUCTION MANUAL...
