  • Page 1 All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 The G801 High Speed Router User’s Guide V1.3 The page 1 of 52 Revision time: 2013-08-16 18:00...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Table of Contents 1 Preface ................................................................ 4 2 LED Indicators and Connectors ......................................................... 5 2.1 LED Indicators ..........................................................5 2.2 Hardware Installation ........................................................6 3 Voice Prompt ..............................................................
  • Page 3 All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.3.3 DMZ/Port Forward ......................................................27 5.3.4 MAC Clone ........................................................28 5.3.5 Multi WAN ........................................................29 5.4 Wireless ............................................................29 5.4.1 Basic ..........................................................29 5.4.2 Security ..........................................................

  • Page 4: Preface

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 1 Preface The page 4 of 52 Revision time: 2013-08-16 18:00...

  • Page 5: Led Indicators And Connectors

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 2 LED Indicators and Connectors 2.1 LED Indicators Front Panel Status Explanation Rear Panel Interface Description The page 5 of 52 Revision time: 2013-08-16 18:00...

  • Page 6: Hardware Installation

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 2.2 Hardware Installation The page 6 of 52 Revision time: 2013-08-16 18:00...

  • Page 7: Voice Prompt

    Step 5.Choose the new WAN port connection type from 1.DHCP and 2.Static Step 4.Report “operation successful” if user operation properly. Step 6.Report “operation successful”, this means user make the changes successfully, and then G801 will return to sound prompting “please enter ...
  • Page 8  If you want to quit by the wayside, press “*”. Step 4.Prompt “operation successful” if password is right and then G801 will be factory setting. Step 5.Press “7” reboot to make changes effective. Step 1.Pick up phone and press “****” to start IVR Step 2.Choose “7”, and G801 report “Reboot”...
  • Page 9 All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3          To input: D, E, F, d, e, f -- press ‘3’  To input: G, H, I, g, h, i -- press ‘4’...

  • Page 10: Configuring Basic Settings

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 4 Configuring Basic Settings 4.1 Two-Level Management “ ” “ ” “ ” “ ” 4.2 Accessing Web Page 4.2.1 From LAN port ’...

  • Page 11: From Wan Port

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Shooting” for detecting and solving your problem. 4.2.2 From WAN port ’ ’ “ “ ” ” “ ” “ ” Notice: If you fail to access to the web configuration, please go to “Trouble Shooting”...

  • Page 12: Setting Up The Time Zone

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3     4.4 Setting up the Time Zone The page 12 of 52 Revision time: 2013-08-16 18:00...

  • Page 13: Setting Up The Internet Connection

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 4.5 Setting up the Internet Connection 4.5.1 Static IP The page 13 of 52 Revision time: 2013-08-16 18:00...

  • Page 14: Dhcp

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Type the IP address IP Address Type the subnet mask Subnet Mask Gateway IP Type the gateway IP address Address Primary DNS...

  • Page 15: Pppoe

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Secondary DNS Type in secondary IP address for necessity in the future Server 4.5.3 PPPoE Assign a specific valid user name PPPoE Account...

  • Page 16: Setting Up The Wireless Connection

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 4.6 Setting up the Wireless Connection 4.6.1 Enable Wireless and Setting SSID Click the button to enable or disable wireless. Press to disable wireless.

  • Page 17: Register

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Select an appropriate encryption mode to improve the security and privacy of your wireless data Security Mode packets. Each encryption mode will bring out different web page and ask you to offer additional configuration.

  • Page 18: Make Call

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 4.8 Make Call 4.8.1 Calling phone or extension numbers 4.8.2 Direct IP calls The page 18 of 52 Revision time: 2013-08-16 18:00...

  • Page 19: Call Hold

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 “ ” “ ” 4.8.3 Call Hold “ “ ” ” “ ” “ ” 4.8.4 Blind Transfer “ ” ’ “...

  • Page 20: Web Configuration

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5 Web Configuration 5.1 Login “ “ ” ” The page 20 of 52 Revision time: 2013-08-16 18:00...
  • Page 21 All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 The page 21 of 52 Revision time: 2013-08-16 18:00...

  • Page 22: Status

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.2 Status ’ ’ The page 22 of 52 Revision time: 2013-08-16 18:00...

  • Page 23: Network&Security

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.3 Network&Security 5.3.1 WAN IP Address Type the IP address Subnet Mask Type the subnet mask Gateway IP Type the gateway IP address...
  • Page 24 All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Set the DNS Mode from Auto and Manual, If user choose manual, you should fill the DNS Mode primary DNS address and Secondary DNS address into Primary DNS Address and Secondary DNS Address.

  • Page 25: Lan

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Set the DNS Mode from Auto and Manual, If user choose manual, you should fill the primary DNS DNS Mode address and Secondary DNS address into Primary DNS Address and Secondary DNS Address.
  • Page 26 All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Type in local IP address for connecting to a local private Local IP Address network (Default: 192.168.1.1) Type in an address code that determines the size of the Local Subnet Mask network.

  • Page 27: Dmz/Port Forward

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 You must specify a DNS server IP address here because your ISP should provide you with usually more than one DNS Primary DNS Server.

  • Page 28: Mac Clone

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.3.4 MAC Clone ’ ’ The page 28 of 52 Revision time: 2013-08-16 18:00...

  • Page 29: Multi Wan

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.3.5 Multi WAN 5.4 Wireless 5.4.1 Basic The page 29 of 52 Revision time: 2013-08-16 18:00...

  • Page 30: Security

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Select Radio On to enable the wireless, select Radio Off Radio On/Off to disable wireless. Network Mode Choose one network mode from the five types.

  • Page 31: Wmm

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 Select an appropriate encryption mode to improve the security and privacy of your wireless data packets. Security Mode Each encryption mode will bring out different web page and ask you to offer additional configuration.

  • Page 32: Station List

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 If or not enable WPS. Press the button to apply. 5.4.5 Station list The page 32 of 52 Revision time: 2013-08-16 18:00...

  • Page 33: Advanced

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.4.6 Advanced The page 33 of 52 Revision time: 2013-08-16 18:00...

  • Page 34: Sip Account

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.5 SIP Account 5.5.1 SIP Settings The page 34 of 52 Revision time: 2013-08-16 18:00...

  • Page 35: Line 1

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.5.2 Line 1 The page 35 of 52 Revision time: 2013-08-16 18:00...

  • Page 36: Voip Qos Setting

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.5.3 VOIP QoS Setting 5.6 Phone 5.6.1 Preferences The page 36 of 52 Revision time: 2013-08-16 18:00...

  • Page 37: Dial Plan

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.6.2 Dial Plan The page 37 of 52 Revision time: 2013-08-16 18:00...

  • Page 38: Phonebook

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.6.3 Phonebook The page 38 of 52 Revision time: 2013-08-16 18:00...

  • Page 39: Call Log

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.6.4 Call Log The page 39 of 52 Revision time: 2013-08-16 18:00...

  • Page 40: Security

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.7 Security 5.7.1 Filtering Setting The page 40 of 52 Revision time: 2013-08-16 18:00...

  • Page 41: Dmz

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.7.2 DMZ 5.7.3 MAC Clone The page 41 of 52 Revision time: 2013-08-16 18:00...

  • Page 42: Port Forward

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.7.4 Port Forward The page 42 of 52 Revision time: 2013-08-16 18:00...

  • Page 43: Content Filtering

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.7.5 Content Filtering The page 43 of 52 Revision time: 2013-08-16 18:00...

  • Page 44: Administration

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.8 Administration 5.8.1 General The page 44 of 52 Revision time: 2013-08-16 18:00...

  • Page 45: Firmware Upgrade

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.8.2 Firmware Upgrade 1) Choose upgrade file type from Image File and Dial Rule 2) Press to browser file. 3) Press to start upgrading.

  • Page 46: Snmp

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.8.4 SNMP The page 46 of 52 Revision time: 2013-08-16 18:00...

  • Page 47: Tr069

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.8.5 TR069 5.9 System Log The page 47 of 52 Revision time: 2013-08-16 18:00...

  • Page 48: Logout

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 5.10 Logout 5.11 Reboot The page 48 of 52 Revision time: 2013-08-16 18:00...

  • Page 49: Trouble Shooting Of The Guide

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 6 Trouble shooting of the guide 6.1 Setting your PC gets IP automatically “ ” “ ” “ ” “ ” “...

  • Page 50: Can Not Connect To The Configuration Website

    All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 6.2 Can not connect to the configuration Website 6.3 Forget the Password The page 50 of 52 Revision time: 2013-08-16 18:00...

  • Page 51: Statement

    FCC Radiation Exposure Statement FlyingVoice Technology Ltd. Declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 52 All manuals and user guides at all-guides.com Copy Right 2013 All Rights Reserved by FLYINGVOICE TECHNOLOG LIMITED V1.3 This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
