Page 3
(3) you represent and warrant that you have the right, authority and capacity to enter into this agreement and to abide by all its terms and conditions, just as if you had signed it. The EULA for this product is available on the Flyingvoice Support page for the product.
Page 4
compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 5
"Flyingvoice Network Technology Co., Ltd.”declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. For the full RED DoC file, Please download it as follow web: https://www.flyingvoice.com The wireless operation frequency: WIFI:24012-2472MHz, Max output power ≤ 20dBm(E.I.R.P) 5150-5350MHz, Max output power ≤...
Chapter 1 Product Introduction Chapter 1 Product Introduction This chapter contains the following: Specifications Hardware Installation...
Page 9
Chapter 1 Product Introduction Product Specifications Specification/ Model SR3000 Photos Power • 12V / 2A • 1.7-inch round touch color screen LCD Screen • Visually display time, up/downlink network speed, number of wireless terminals, Mesh agent status, etc. • 1*WAN, 10/100/1000Mbps, uplink to the Internet Ethernet port •...
Page 10
Chapter 1 Product Introduction Specification/ Model SR3000-lite Photos Power • 12V / 2A • 1*WAN/LAN, 10/100/1000Mbps. Network • Support uplink to the Internet or downlink to the PC to access the web for configuration. • 802.11 a/n/ac/ax, 2*2 MIMO, 1024-QAM@160MHz 2402Mbps, eFEM.
Chapter 1 Product Introduction Hardware Installation Preparation for Installation Before installing the equipment, please check whether the items are complete and whether the installation conditions are available. Open the packing box of the equipment and check whether the items in the box are complete against the list of items. If you find that the items in the box do not match the list, please contact us directly.
Page 12
Chapter 1 Product Introduction - Check that the power supply, LCD and LED are working properly. Warning - Do not attempt to use a power adapter that does not come standard and do not unplug the power supply while configuring or changing the device. - Using another power adapter may damage the device and will void the manufacturer's warranty.
(SR3000 only), LED indicators (SR3000-lite only), or by accessing the device's web. 1. LCD Display When the SR3000 is powered on, the boot loading progress bar is automatically displayed, as shown in the following figure: After the progress is loaded, it will automatically jump to the language selection interface, which currently supports only 2 languages: English (default), Simplified Chinese.
Page 15
2.Web Access SR3000 and SR3000-lite support Web Login access. After the device is powered on, user can connect to a PC through the LAN port , and can access the IP address (192.168.1.1) to log in to the web interface for viewing or configuration.
Page 16
Chapter 2 Boot Configuration for the highest permissions, can view and configure all pages. User account: the initial account/password is: user/SN last eight digits; restricted permissions, only support to view some pages and basic configuration. (2) Web Login Ensure that the PC is properly connected to the LAN port of the device. The device has a built-in web server to respond to HTTP get/post requests, and users can access the web through the browser.
Page 17
Chapter 2 Boot Configuration Parameter Description Display the product model of the current device, which cannot be Model modified. Display the firmware version of the device, which can be upgraded Firmware Version on demand. Display the hardware version of the device's current internal Hardware Version hardware PCBA.
Chapter 2 Boot Configuration Basic Configuration After the device boots up successfully, it supports logging into the Web to configure basic functions, including account/password modification, language modification, local time synchronization, upload/download configuration file, upgrade firmware, rebooting or restore factory setting. 1.
You can modify the language of the system web display: Simplified Chinese, Language English. Note: The SR3000's LCD display will also change the language setting synchronously. 3. Setting Time and Date User can modify the time and date after logging in to the web.
Chapter 2 Boot Configuration Parameters Description Optional enable or disable NTP settings to synchronize the current NTP Enable network time. Fill in the modified primary NTP server address for time Primary NTP server synchronization. Secondary NTP server Fill in the modified Secondary NTP server address for backup. Local Time Zone UTC timezone, optional the corresponding country and region.
Chapter 2 Boot Configuration version of the device. Path: System -> Maintenance -> System Upgrade -> Firmware Upgrade, as shown in the following figure: Parameters Description Firmware One click to select a local firmware file and then upload it. Note: User is generally not supported to upgrade or downgrade the firmware version at will, which may result in the device not being able to boot up.
Chapter 2 Boot Configuration Parameters Description Factory Setting Set the device to factory status with one click. Note: Do not disconnect the device from power and Internet during the process of restoring the device to the factory. 7. Reboot User can reboot the device with one click after logging in to the web, or by short pressing the reset button at the bottom of the device for 1 second.
Chapter 3 Network Configuration Chapter3 Network Configuration This chapter contains the following: - WAN Port Configuration - LAN Port Configuration - Wireless Network Configuration - Mesh Network Configuration...
Path: IP Config-> Internet-> IPv4 (1)DHCP mode SR3000 built-in DHCP server assigns a dedicated IP address to each local client. The factory default DHCP mode allows the device to automatically obtain an IP address from the DHCP server without manually assigning an IP address to the client.
Page 25
Chapter 3 Network Configuration Optional a mode: Auto, Manual. DNS Mode After choosing the Manual mode, you need to fill in the Primary DNS & Secondary DNS. Primary DNS Fill in the Primary DNS. Secondary DNS Fill in the Secondary DNS for backup. (2)Static IP mode You can use this configuration when you receive a fixed public IP address or a public subnet from your Internet provider.
Page 26
Chapter 3 Network Configuration Default Gateway Fill in the local gateway address. Primary DNS Fill in the Primary DNS. Secondary DNS Fill in the Secondary DNS for backup. (3)PPPoE mode PPPoE is mostly used for DSL modem users, ISP provide information about user names, passwords, and authentication modes, and all local users can share a PPPoE public connection to access the Internet.
Chapter 3 Network Configuration Secondary DNS Fill in the Secondary DNS for backup. PPPoE Account Fill in the PPPoE account obtained from the ISP. PPPoE Password Fill in the PPPoE password obtained from the ISP. Fill in the PPPoE authentication service name. Service Name If it is empty, the service name is automatically detected.
Chapter 3 Network Configuration LAN Port Configuration The device supports acting as a DHCP server to set the IPv4 and IPv6 address of the LAN port, and can assign IP addresses to the terminal devices connected to the LAN ports. 1.
Chapter 3 Network Configuration After the DHCP server is enabled, you need to fill in the DHCP start IP. Fill in a valid IP address as the start IP address sent by the DHCP server to the DHCP client. Start IP If the IP address of the LAN port is 192.168.1.1, the start IP address must be greater than or equal to 192.168.1.2 but smaller than the end IP address.
Chapter 3 Network Configuration Wireless Network Configuration After the device is powered on and started, the wireless network (dual-band 2.4GHz & 5GHz) is enabled by default, and is supported wireless access by the terminal devices. After logging in to the web, user can modify the SSID, password, encryption algorithm of WiFi, etc.
Chapter 3 Network Configuration Password Fill in the password of 2.4G band WiFi, the default is SN after eight digits. Optional a Encryption Algorithm: CCMP(AES), TKIP/CCMP(AES) mixed Encryption Algorithm mode or Auto. Optional network modes for 2.4G band WiFi: 802.11g、802.11b/g/n、 802.11b/g/n/ax;...
Page 32
Chapter 3 Network Configuration Optional a method: WPA-PSK, WPA2-PSK, WPA-PSK/WPAs-PSK mix mode Authorization Method or no encryption.Choose an appropriate authorization method to improve the security and privacy of your wireless data packets. Password Fill in the password of 5G band WiFi, the default is SN after eight digits. Optional a Encryption Algorithm: CCMP(AES), TKIP/CCMP(AES) mixed Encryption Algorithm mode or Auto.
Mesh Agent Mesh Controller After SR3000 is normally powered up and networked, user can slide up and down to switch the LCD display content, if it is in the default standby page, just slide down a page, as shown in the following figure:...
Page 34
Chapter 3 Network Configuration Title Diagram of Mesh Network Number of Agent Router Button of Mesh Connection Parameters Description Title Display the current page for the mesh networking setting. Display the diagram of the mesh networking status, in this figure, there is no mesh networking.
Page 35
Chapter 3 Network Configuration Parameters Description After normal connection, LCD will show connection successful and Connection Successful jump to Mesh page automatically after 2 seconds. If the connection is abnormal (e.g. the controller and agent routers are temporarily disconnected, or they are too far away to scan, etc.), LCD Connection Failed will display connection failed and need to manually click the Back button, so that user can reconnect again.
Page 36
Any model of controller and agent router, while pressing the WPS button on the bottom of the device, the device will automatically scan and connect. The connection result can be viewed via LCD (SR3000 only) and LED indicator (SR3000-lite only) . 3. Mesh Networking Configuration by Web Interface After logging in to the web, user can configure the mesh networking and view the network topology and network status information of the controller and agent routers in the web page.
Chapter 4 Function Configuration Chapter 4 Function Configuration This chapter contains the following: - FXS Port Configuration - Log Setting and View - Management Configuration...
The device integrates 1 FXS port and supports registration of 1 SIP account, which can be externally connected to the analog phone, fax machine, fire/burglar alarm panel to send down the account to realize analog line to IP call. Note: This feature is only supported by SR3000. 1. SIP Account Registration Path: SIP->Registration Setting,...
Chapter 4 Function Configuration Fill in the port number of the outbound server, , the default is Outbound Proxy Server1 Port 5060. Fill in the domain name or IP address of the backup outbound Outbound Proxy Server2 server. Fill in the port number of the backup outbound server, , the Outbound Proxy Server2 Port default is 5060.
Chapter 4 Function Configuration Path: Status-> Information-> FXS, as shown in the following figure: Parameters Description Port Status Display whether the FXS port is in Connected or Idle. Dispaly whether the call status of FXS port is in the offhook or Hook Status hang up state.
Chapter 4 Function Configuration Log Setting and View The device supports setting and viewing local and remote system logs. 1. Log Setting Path: System-> Config-> Log Setting, as shown in the following figure: Parameters Description Optional different levels of syslog output: Debug, INFO, Notice, Warning, Error, Critical, Alert, Emergency.
Chapter 4 Function Configuration Remote Syslog Enable Optional whether to enable the remote syslog function. After the remote syslog is enable, fill in the remote logging server Remote Syslog Server domain name or IP address. After the remote syslog is enable, fill in the remote logging server Remote Syslog Port port number.
Chapter 4 Function Configuration Path: Status-> Log-> Exception Log, as shown in the following figure: User can refresh the exception log and save the exception log locally with one click.
After telnet is enable, fill in the host name of the device. The Hostname default is model of the device, such as SR3000. User Name Fill in the username for logging in to the Telnet remotely.
Chapter 4 Function Configuration 2. Provision Configuration Provision configuration supports 3 implementations: TFTP (supports option 66), HTTP and HTTPS. It also supports remote deployment, user only needs to set the value of the profile rule and recync parameter, the device automatically re-synchronize the remote TFTP / HTTP / HTTPS server.
Page 46
Chapter 4 Function Configuration Fill in the maximum delay time for requesting synchronized files, default 40 seconds. A random value is generated in the interval from 0 to 40 seconds, and the Resync Random device waits for this value for the interval before requesting the provision Delay(sec) server.
