Important! This User Manual contains important information for the user of the product.
All who use this product should review and completely understand its contents. Remember to keep
this manual in a place where it is always available to those using the product.
Essential Thera-P
Treatment Table
User Manual
Applies to the following Models:
EPT9020
EPT9024
EPT9021
EPT9025
EPT9028
EPT9029
Advertisement
Table of Contents
Related Manuals for pivotal Thera-P
Summary of Contents for pivotal Thera-P
- Page 1 Essential Thera-P Treatment Table User Manual Applies to the following Models: EPT9020 EPT9024 EPT9028 EPT9021 EPT9025 EPT9029 Important! This User Manual contains important information for the user of the product. All who use this product should review and completely understand its contents. Remember to keep...
-
Page 2: Table Of Contents
Manufacturer Contact Information: ............................. 15 Introduction: Ease of use, multiple options and a sleek but durable design make the Essential THERA-P line of electric treatment tables the choice affordable choice of therapists everywhere. Seven top options allow therapists to choose the table that best meets their needs and that ensures patients' most comfortable positioning. The Essential THERA-P electric treatment table is constructed of precision-cut flat and tube steel for durability and style. -
Page 3: Safety Precautions & Definitions
If you need assistance, contact Safety Precautions & Definitions: Pivotal Health Solutions service at 1-800-743-7738. WARNING: Never leave patient on table unattended. CRUSH HAZARD: Powered components used to elevate and lower this table present a potential crush hazard. KEEP CHILDREN AWAY FROM TREATMENT AREA. Allow only the patient and authorized staff in treatment area. -
Page 4: Explosion Hazard
Indicates the product is a medical device. WARNING: Under no circumstances should the table be modified from its original design. Contact Pivotal Health Solutions if you need help with service. DANGER: Possible explosion hazard if used in the presence of flammable anesthetics. -
Page 5: Installation & Unpacking
If freight was arranged by Pivotal Health Solutions, note any damage on the Bill of Lading before signing acceptance of product and notify Pivotal Health Solutions right away. Failure to inspect for shipping damage prior to signing for the product may affect your warranty. -
Page 6: Technical Specifications
IP Rating Power Cord (120V) 96 in (243 cm) cable length, 10A, unshielded 96 in (243 cm) cable length, 10A, unshielded Power Cord (240V) WARNING: Keep table out of high moisture areas. For indoor use only. Essential Thera-P Electric Treatment Table... - Page 7 Expected Life: This product has an approximate expected life time of 10 years when correctly handled, serviced, and inspected in accordance with these instructions. Design and Quality: Pivotal Health Solutions is certified in accordance with ISO 13485, the standard for the medical device industry.
-
Page 8: Operation
Note to user: If a serious incident occurs, report the incident to Pivotal Health solutions. (See section with Manufacturer Contact Information for contact details). If the incident occurs in the EU, also report any serious incident to the Competent Authority of the Member State in which the user and/or patient is established. - Page 9 Table Options and Features: Battery Installation: Interpreting Battery LED for status determination when on table: Interpreting Battery LED for status determination when charging: Note: From low battery to a fully charged battery takes approximately 10 hours. Essential Thera-P Electric Treatment Table...
- Page 10 • If the table is equipped with elevating middle section and elevating lift back, use the attached hand control to raise and lower the section as indicated below. Elevate and lower the liftback Elevate and lower the mid-section Essential Thera-P Electric Treatment Table...
-
Page 11: Preventative Maintenance
• Check moveable components (electrical and non-electrical) to ensure functionality. • Check components to ensure they lock and function properly. • Contact Pivotal Health Solutions with questions or concerns. LUBRICATION: It is recommended that every six (6) months the table drive bearings be lubricated using a light machine oil such as 3-in-1 oil. -
Page 12: Upholstery Cleaning & Care
Do not use any cleaning agents that contain alcohol, harsh chemicals or abrasives. Service: Refer to Warranty section in this manual for specific warranty information. When replacing worn parts, use genuine Pivotal Health Solutions, Inc. parts by contacting our service department. When ordering replacement parts: • Ask for the service department, 800-743-7738 •... - Page 13 A therapy table is considered a medical device by the Food and Drug Administration. Therefore, it is necessary that Pivotal Health Solutions, Inc. be notified if the table is sold, destroyed, or otherwise disposed of. Please notify in writing providing your name and the serial number of your table to:...
-
Page 14: Replacement Parts
Dual Foot Control Pedal S1077 Dual Foot Bar Control S1158 Hand Control (EPT9028 & EPT9029) S1195 *xxx is a place holder for the color code. Contact Pivotal Health for the appropriate color code for your table. Essential Thera-P Electric Treatment Table... -
Page 15: Warranty
‘as-is’ and are limited to a (1) year warranty on the frame only, commencing on the date of delivery. Note to user: If a serious incident occurs, report the incident to Pivotal Health solutions. (See section with Manufacturer Contact Information for contact details). If the incident occurs in the EU, also report any serious incident to the Competent Authority of the Member State in which the user and/or patient is established.
