Quantum
Intersegmental Table
User Manual
Applies to the following Models:
Q400
Q400P
Important! This User Manual contains important information for the user of the product.
All who use this product should review and completely understand its contents. Remember to keep
this manual in a place where it is always available to those using the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quantum Q400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for pivotal Quantum Q400

Summary of Contents for pivotal Quantum Q400

  • Page 1 Quantum Intersegmental Table User Manual Applies to the following Models: Q400 Q400P Important! This User Manual contains important information for the user of the product. All who use this product should review and completely understand its contents. Remember to keep this manual in a place where it is always available to those using the product.

  • Page 2: Table Of Contents

    Table of Contents: Intended Use: ..................................2 Contraindications: ................................... 2 Safety Definitions: ................................... 3 Safety Precautions: ................................. 3 Installation & Unpacking: ................................ 5 Shipping Blocks/Restraints: ..............................6 Patient Assist Installation: ............................... 7 Technical Specifications: ................................. 8 Operation: ....................................9 Preventative Maintenance:..............................11 Upholstery Cleaning &...

  • Page 3: Safety Definitions

    Safety Definitions: Warning and Precautions through this manual are indicated by specific symbols. Applicable symbols are shown below along with a description of the symbol. Review these symbols and all safety precautions before operating the table. CAUTION: Text with a “CAUTION” indicator will explain possible safety infractions that could have the potential to cause injury.
  • Page 4  Follow preventative maintenance instructions provided in this manual.  Ensure all components have been inspected for damage and are fully functional.  Inspect cables and connectors before each use. If you need service assistance contact Pivotal Health Solutions at 1-800-743-7738. Quantum Intersegmental Table...

  • Page 5: Installation & Unpacking

    Once the table is out of the shipping crate, place table in a level location and inspect the table cushions, frame, cables, etc. for damage. If no damage is noted, remove the shipping restraints, then plug in the table and test the options that are on your table. Contact Pivotal Health Solutions or your dealer with any questions or concerns.

  • Page 6: Shipping Blocks/Restraints

    Shipping Blocks/Restraints: FAILURE TO FOLLOW THESE INSTRUCTIONS WILL DAMAGE YOUR TABLE AND VOID FACTORY WARRANTY Quantum Intersegmental Table...

  • Page 7: Patient Assist Installation

    Patient Assist Installation: Quantum Intersegmental Table...

  • Page 8: Technical Specifications

    Expected Life: This product has an approximate expected life time of 10 years when correctly handled, serviced, and inspected in accordance with these instructions. Design and Quality: Pivotal Health Solutions is certified in accordance with ISO 13485, the standard for the medical device industry.

  • Page 9: Operation

    Table including cables associated with the Quantum Table. Otherwise, degradation of the performance of this equipment could result. WARNING: Use of accessories and cables other than those specified or provided by Pivotal Health Solutions could result in increased electromagnetic emissions or decreased electromagnetic immunity and result in improper operation.

  • Page 10: Hand Controls

    Hand Controls: Note:  The hand-control defaults to the last settings used.  These tables no longer have a heat option. Power – Turns the main power to the table on or off. Vibration – Turns the vibration mode on or off.

  • Page 11: Preventative Maintenance

     Check moveable components (electrical and non-electrical) to ensure functionality.  Check components to ensure they lock and function properly.  Contact Pivotal Health Solutions with questions or concerns. At six month intervals, it is recommended the top be removed and the following items checked: (Note: Use caution when operating the table with the top removed.

  • Page 12: Upholstery Cleaning & Care

    If freight was arranged by Pivotal Health Solutions, note any damage on the Bill of Lading before signing acceptance of product and notify Pivotal Health Solutions right away. Failure to inspect for shipping damage prior to signing for the product may affect your warranty.

  • Page 13: Troubleshooting

    A chiropractic table is considered a medical device by the Food and Drug Administration. Therefore, it is necessary that Pivotal Health Solutions, Inc. be notified if the table is sold, destroyed, or otherwise disposed of. Please notify in writing providing your name and the serial number of your table to:...

  • Page 14: Replacement Parts

    Replacement Parts: Note: Diagrams follow the parts list. See Patient Assist Installation section for Patient Assist parts. PARTS LIST BY: ITEM NO ITEM NO. PART NO. DESCRIPTION QUANTITY 18613 CABINET BASE 02539 SCREW HEX HEAD #12x1-1/4 01118 ALUMINUM TRIM 03148 INDICATOR PANEL CERVICAL LUMBAR 03111 CASTER HOODED 1-7/8"...
  • Page 15 18620 BAR TURN AROUND 02160 WASHER NYLON 5/16 ID 02114 SCREW HEX HEAD CAP 1/4-20x3/4 13039 ROD THREADED 5/16-18x9-1/2 INDICATOR LED 18608 BASE FRAME ROLLER CARRIAGE PARTS LIST BY: ITEM NO ITEM NO. PART NO. DESCRIPTION QUANTITY 02513 SCREW HEX HEAD CAP 3/8-16x1-3/4 12448 BAR 1/8x1 POTENTIOMETER LINK 13”...
  • Page 16 Q400TV QUANTUM TOP VINYL SEWN (OPTIONAL REPLACEMENT) 18622 PATIENT ASSIST BAR 12483 PATIENT ASSIST BAR BACK PLATE 02523 WASHER LOCK SPLIT 3/8 ZINC 14485 BOLSTER Q400 7x6x20 Quantum Intersegmental Table...
  • Page 17 Quantum Intersegmental Table...
  • Page 18 Quantum Intersegmental Table...
  • Page 19 Quantum Intersegmental Table...
  • Page 20 Quantum Intersegmental Table...

  • Page 21: Warranty

    Warranty: https://www.phschiropractic.com/customer-service/warranty.aspx Note to user: If a serious incident occurs, report the incident to Pivotal Health solutions. (See section with Manufacturer Contact Information for contact details). Manufacturer Information: Rev B 3-24-2025 800-743-7738 Pivotal Health Solutions, Inc. 011-1-605-753-0110 3003 9 Ave. SW...
