- Page 1 EX3000.1 EX1500.1 Full Range Class D Monoblock EX300.4 EX200.4 EX100.4 4 Channel Full Range Class D USER MANUAL Installation Instructions | Owner’s Manual Due to continuous improvement of the product, specifications are subject to change without notice.
- Page 2 1.1 AMPLIFIERS’ SPECIFICATION AMPLIFIERS: EX300.4, EX200.4, EX100.4 SPECIFICATIONS @14.4 Volts - 1% THD EX300.4 EX200.4 EX100.4 Rated Power: Rated Power: Rated Power: Rated Power: Working Voltage 10-16 Volts 10-16 Volts 10-16 Volts Frequency Response: 10Hz - 20KHz 10Hz - 20KHz 10Hz - 20KHz Signal to Noise Ratio: <95dB...
- Page 3 1.2 AMPLIFIERS’ SPECIFICATION AMPLIFIERS: EX3000.1, EX1500.1 SPECIFICATIONS @14.4 Volts - 1% THD EX3000.1 EX1500.1 Rated Power: Rated Power: Rated Power: Working Voltage 10-16 Volts 10 - 16 Volts Frequency Response: 10Hz - 20KHz 10Hz - 20KHz Signal to Noise Ratio: <95dB <95dB Damping Factor:...
- Page 4 AMPLIFIERS’ DIMENSIONS EX100.4 Dimensions EX200.4 Dimensions 5” /127mm 7.36” /187mm 2.37” /60.39mm 2.37” /60.39mm EX300.4 Dimensions EX1500.1 Dimensions 8.93” /227mm 8.93” /227mm 2.37” /60.39mm 2.37” /60.39mm EX3000.1 Dimensions 10.11” /257mm 2.37” /60.39mm...
-
Page 5: Installation
+12V (POWER CONNECTION) INPUT GAIN (6V ~ 0.2V) GND (GROUND CONNECTION) ACT- Adaptive Crossover Technology REM (REMOTE) APC Audio Protection Circuit SESI - Signal Evaluation Status Indicator 3. INSTALLATION Please take all steps into consideration or, you can have a Euphoria authorized dealer check the installation and set your car audio systems. - Page 6 GND ( GROUND CONNECTION ) REM ( REMOTE CONNECTION ) AMPLIFIER +12V, GROUND, REMOTE CONNECTION DIAGRAM Ground Ground 3-4. SPEAKER CONNECTION...
- Page 7 EX300.4/EX200.4/EX100.4 AMPLIFIER SPEAKER CONNECTION DIAGRAM 1 EX300.4/EX200.4/EX100.4 working voltage is 10-16 Volts EX300.4/EX200.4/EX100.4 EX300.4/EX200.4/EX100.4 AMPLIFIER SPEAKER CONNECTION DIAGRAM 2...
-
Page 8: Troubleshooting
EX3000.1/EX1500.1 AMPLIFIER SPEAKER CONNECTION DIAGRAM 1 EX3000.1/EX1500.1 working voltage is 10-16 Volts EX3000.1/EX1500.1 4. TROUBLESHOOTING NO SOUND (NO OUTPUT) Please check built-in or external fuses, if it is blown, please replace with new one. PROTECTION Minimum working impedance for EX200.4, EX300.4, EX100.4 is 2 stereo. Working voltage is 10-16 Volts. EX1500.1/EX3000.1 minimum working impedance is 1 stereo. -
Page 9: Limited Warranty
LIMITED WARRANTY Euphoria™ warrants any products purchased in the U.S.A. from an authorized Euphoria™ dealer. All products are warranted to be free from defects in material and workmanship under normal use and service for a period of two (2) years when the unit is installed by an authorized Euphoria dealer.
