- Page 1 A M P L I F I E R S WDX 1000.1 WDX 100.4 WDX 1500.1 WDX 200.4 WDX 2000.1 WDX 300.4 WDX 3000.1 WDX 5500.5 WDX 4000.1 User’s Manual Due to continuous improvement of the product, the specifications are subject to change without notice.
- Page 2 Introduction Congratulations on your purchase of a DB Drive state-of-the-art amplifier. Your selection of a DB Drive product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your DB Drive amplifier in a new system, you are certain to notice immediate performance benefits.
- Page 3 1. WDX AMPLIFIER’S SPECIFICATION 1-1. WDX Digital Monoblock Class D Amplifiers Load Voltage & THD WDX 1500.1 WDX 2000.1 WDX 3000.1 WDX 4000.1 WDX 1000.1 4ohm 14.4 volts & 1% 1 X 500 Watts 1 X 750 Watts 1 X 1000 Watts 1 X 250 Watts 1 X 375 Watts 1 X 750 Watts...
- Page 4 2. WDX AMPLIFIER’S CONTROL & CONNECTION. 2-1. WDX Digital Monoblock Class D Amplifiers AUDIO PROTECTION CIRCUIT POWER & PROTECTION INDICATOR Power LED - GREEN-lit shows normal operation Protect LED - RED-lit shows general malfunction, faulty connection or thermal protection SIGNAL EVALUATION STATUS INDICATOR.
- Page 5 2-2. WDX Multi-Channel Class D Amplifiers AUDIO PROTECTION CIRCUIT POWER & PROTECTION INDICATOR Power LED - GREEN-lit shows normal operation Protect LED - RED-lit shows general malfunction, faulty connection or thermal protection SIGNAL EVALUATION STATUS INDICATOR. RED-lit LED shows clipping peaks of audio signal GAIN ( 6V ~ 0.2V ) POWER CONNECTION GAUGE SIZE...
- Page 6 2-3. ADAPTIVE CROSSOVER TECHNOLOGY Adaptive Crossover Technology (4 Channel) Settings for high-frequency speakers Channel 1/2 & Channel 3/4 Tweeter Crossover Selection to HPF position High Pass Variable Crossover HPF : 20Hz - 5KHz 500Hz 2.5kHz 20kHz Settings for subwoofers Channel 1/2 & Channel 3/4 Woofer Crossover Selection to LP position Low Pass...
-
Page 7: Installation
Should you install the WDX amplifiers by yourself, please read the owner's manual very carefully. Before you start your installation, please take all steps into consideration, or you can have a DB Drive or DB Research’s authorized dealer check the installation and help install your car audio system. -
Page 8: Speaker Connection
C) REM ( REMOTE CONNECTION ) Run a remote turn on cable from the head units remote switched + 12V output. WDX +12V, GROUND, REMOTE CONNECTION DIAGRAM. Ground BATTERY SPEAKER CONNECTION DB Drive recommends to use a minimum of 12 gauge speaker connecting cables. Run 12 gauge speaker connecting cables from your speakers to WDX amplifier's mounting location. - Page 9 WDX MONOBLOCK AMPLIFIERS’ SPEAKER CONNECTION DIAGRAM 2. 8~ 2 ohms 8~ 2 ohms CAUTION !! WDX 1000.1, WDX 1500.1, WDX 2000.1, WDX 3000.1 WDX 4000.1 amplifiers minimum impedance is 1 ohms WDX 4 CHANNEL AMPLIFIERS’ SPEAKER CONNECTION DIAGRAM 1. 8 ~ 2 ohms 8 ~ 2 ohms 8 ~ 2 ohms 8 ~ 2 ohms...
- Page 10 WDX 4 CHANNEL AMPLIFIERS’ SPEAKER CONNECTION DIAGRAM 2. 8 ~ 2 ohms 8 ~ 2 ohms 8~ 4 ohms CAUTION !! WDX 100.4, WDX 200.4 & WDX 300.4 Amplifiers’ minimum impedance is 2 ohms stereo or 4 ohm mono WDX 5 CHANNEL AMPLIFIERS’ SPEAKER CONNECTION DIAGRAM. 8 ~ 2 ohms 8 ~ 2 ohms 8~ 2 ohms...
-
Page 11: Troubleshooting
4. TROUBLE SHOOTING NO SOUND ( NO OUTPUT ) 1) Check all connections, cables' routing, short and voltage at WDX amplifiers and headunit. 2) Check external fuses. If any are blown, replace with new one. 3) Check whether speakers work well. You can test speakers by connecting to another amplifier. PROTECTION 1) Please check overload, overheat ( thermal ), short, voltage and DC offset. -
Page 12: Limited Warranty
DB Research directly or visit our website www.dbdrive.net for more details. DB Research L.L.P. ▪ 302 Hanmore Industrial Parkway ▪ Harlingen, TX 78550 Ph: (877) 787-0101 ▪ Fax: (956) 421-4513 ▪ tech support: support@dbdrive.net Designed and Engineered in the U.S.A...
