  • Page 1 PXIe-1085 Modular Power Supply Getting Started 2025-03-09...
  • Page 2 PXIe-1085 Modular Power Supply Getting Started ........

  • Page 3: What You Need To Get Started

    PXIe-1085 Modular Power Supply Getting Started PXIe-1085 Modular Power Supply Getting Started Introduction The PXIe-1085 modular power supply is a replacement part for the PXIe-1085 chassis. Caution This power supply is not compatible with any other National Instruments chassis. Unpacking 1.

  • Page 4: Installation

    1. Disconnect the power cable from the power supply on the back of the chassis. 2. Identify the eight mounting screws for the PXIe-1085 that attach the power supply to the chassis. 3. Using a Phillips screwdriver, remove the screws.
  • Page 5 PXIe-1085 Modular Power Supply Getting Started prevent the power supply from falling out. Figure 1. Removing the Power Supply 1. Power Supply Mounting Screws (8x) 2. Power Supply 3. Modular Power Supply Screws (4x) 4. PXIe-1085 chassis 5. Rail Safety Catch (Both Sides) 5.

  • Page 6: Installing The Power Supply

    PXIe-1085 Modular Power Supply Getting Started Figure 2. Removing Modular Power Supply from Power Supply 1. Power Supply 2. Modular Power Supply Handle 3. Modular Power Supply Installing the Power Supply 1. Ensure that there is no visible damage to the new power supply assembly.

  • Page 7: Configuring The Power Supply

    2. Set the Inhibit Mode switch to the Default position. Connecting Safety Ground Caution The PXIe-1085 chassis are designed with a three-position NEMA 5-15 style plug for the U.S. that connects the ground line to the chassis ground. To minimize shock hazard, make sure the electrical power outlet you use to power the chassis has an appropriate earth safety ground.
  • Page 8 PXIe-1085 Modular Power Supply Getting Started To completely remove power, you must disconnect the AC power cable. 1. Attach input power through the rear AC inlet using the appropriate AC power cable supplied. 2. Set the Inhibit Mode switch on the back of the chassis to the Manual position.
