Input / Output Connections


VGA2- IN VGA1- IN / SCART
6
. VGA-In/SCART Connector
(PC Analog Signal/Component Video Input/HDTV/SCART)
2. S-Video Input Connector
3. Composite Video Input Connector
4. RS-232 Connector (3-pin)
5. Audio Output Connector (3.5mm Mini Jack)
6. Power Socket
7. Audio Input Connector (3.5mm Mini Jack)
8. Security Bar
9. Kensington
0. VGA-Out Connector (Monitor Loop-through Output)
The items below are only for models that operate
with XGA model:
. VGA2-In Connector
(PC Analog Signal/Component Video Input/HDTV)
Introduction
2 3 4
S-VIDEO VIDEO RS232
Lock Port
TM
0 5
AUDIO-OUT
VGA-OUT
AUDIO-IN
7 8
9
9
