Raypa AES-28 Instruction Manual For Use And Maintenance

Autoclaves for sterilization
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AESi/23
INSTRUCTION MANUAL
FOR USE AND MAINTENANCE
AUTOCLAVES FOR STERILIZATION
Models:
AES-28, AES-50,
AES-75, AES-110, AES-150
1/40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AES-28 and is the answer not in the manual?

Questions and answers

Related Manuals for Raypa AES-28

Summary of Contents for Raypa AES-28

  • Page 1 AESi/23 INSTRUCTION MANUAL FOR USE AND MAINTENANCE AUTOCLAVES FOR STERILIZATION Models: AES-28, AES-50, AES-75, AES-110, AES-150 1/40...
  • Page 2 AESi/23 It is very important to keep this instruction booklet with the unit in case you need to refer to it. If the appliance is sold or transferred to another person, remember to hand it over with the appliance so that the new owner is familiar with the operation of the appliance and its warnings.

  • Page 3: Table Of Contents

    AESi/23 14) Put on heat insulating gloves before removing a substance from the chamber. Do not put hands into the chamber until the steam has been vented. 15) Some time is required for liquids to cool. Be sure to check that the temperature has dropped enough before unloading a liquid from the chamber or burns can result.

  • Page 4: Description

    AESi/23 DESCRIPTION 1. Drain valve. 2. Lid thermal protection. 8, 9, 10 3. Closing wheel. 4. Microprocessor. 5. Thermal printer. (accessory that must be installed at the factory). 6. Mano-vacuometer. 7. Main switch. 8. RS-232 connection. 9. Selector PC/PRINTER (units with built-in printer, ref.

  • Page 5: Microprocessor Functions And Characteristics

    AESi/23 MICROPROCESSOR FUNCTIONS AND CHARACTERISTICS DESCRIPTION 1.- Operation mode: SOLIDS/LIQUIDS/AGAR. 2.- Number of the program. 3.- Sterilization temperature. 4.- Maintaining temperature (visible with AGAR mode). 5.- Sterilization time. 6.- (not available on this model) 7.- Key for sterilization temperature selection. (THERMOMETER) This key is used during a sterilization program edition to select a given temperature Also used in language configuration, type of degrees and to select PC/Printer .

  • Page 6: Technical Specifications

    220 V (optional) or 380 V triple phase + N (for AES-110 AES-150) Frequency: 50/60 Hz Consume: 2.000 W (Model AES-28) 3.200 W (Model AES-50/75) 4.500 W (Model AES-110) 6.000 W (Model AES-150) Sterilization time: from 1 to 250 minutes.
  • Page 7 RS-232 connection. CCI-28 Non-perforated stainless steel basket AISI-304 of Ø270x185mm for AE/AES-28 (2 per autoclave), AE/AES-50 (3 per autoclave) CCI-75S Non-perforated stainless steel basket AISI-304 of Ø370x180mm for AE/AES-75 (3 per autoclave) and AE/AES-110 (4 per...

  • Page 8: Installation

    The plug of the autoclave is a SCHUKO with central and lateral connection in mono-phased autoclaves (AES-28/50 and AES-75). For safety reasons the autoclave must be grounded. The tri phased autoclaves (AES-110 and AES-150) have a normalized plug of 16A, 3 poles, neutral and ground.

  • Page 9: Alphanumeric Display Functions

    To edit data of a program is necessary to start from the main menu. Follow the next steps: Connect the autoclave to the mains, and press the main switch (7). It will become lighted  The microprocessor screen will show the message: “RAYPA Sterilclav-Blue” during 2  seconds.

  • Page 10: Delayed Start

    AESi/23 DELAYED START Configuration of the delayed time: It will be programmed the hour - minute for the delayed start. To enter in programmed delay start, you should press simultaneously the keys CLOCK and START. It will be displayed: First row: " Start time " Second row: "...

  • Page 11: Selection Of Language And Type Of Degree

    AESi/23 SELECTION OF LANGUAGE AND TYPE OF DEGREE The control panel of the autoclave gives the possibility to display the steps of each cycle and messages in different languages, which are: SPANISH, CATALAN, ENGLISH and FRENCH. The default language of the autoclave is ENGLISH. Similarly the apparatus offers the possibility the change the type of degree to be used, which are: DEGREE CELSIUS and DEGREE FAHRENHEIT.

  • Page 12: Solid/Liquid/Agar Mode

    AESi/23 Selector for PC or printer connection To use the printer (ref. IT) after the PC, remember to change the selector and to disconnect the communications cord from the PC. SOLID/LIQUID AND AGAR MODE If the autoclave is not equipped with an accessory reference: PT-2 (Heart probe), when a program is edited it will be set: SOL/LIQ-1 to sterilize solids or liquids or AGAR-1 to sterilize a culture medium.

  • Page 13: Start Up Instructions

    Connect the autoclave to the mains and switch on by pressing the main button (7). At the microprocessor screen will be displayed the message: “RAYPA Sterilclav-Blue” and a few seconds later will appear a number of a program (it will always be the last program used).
  • Page 14 AESi/23 Make sure that the tap (1) (drain valve) is correctly closed (turning the handle 1/4 clockwise). Take care that the water don't overflow the lower grid. Put in the autoclave the materials to be sterilized, directly or with baskets, in a way that you leave space to the steam to circulate freely.

  • Page 15: Shut Down Of The Autoclave

    AESi/23 PURGE AND HEATING: Automatic air purge and heating phases. HEATING: Heating phases and pressure increasing. STERILIZING: Keeping the sterilization temperature during the programmed time. COOLING: Natural cooling period before the sterilization process and up to 95ºC. AGAR TEMPERAT.ON: Maintenance temperature at the end of the cycle (only AGAR mode) END OF PROCESS: Sterilization cycle ending message.

  • Page 16: Load Disposal

    AESi/23 LOAD DISPOSAL Place the material to be sterilized directly or in baskets, in a way that you leave space to the steam to circulate freely. LOADING THE AUTOCLAVE: o Maintain the lid open during 15 minutes between sterilizations, in the case of using the autoclave repeatedly.

  • Page 17: Printer Mode

    AESi/23 NOTE: For autoclaves equipped with the accessory reference: PT-2 (Heart probe), the required sterilization time (20 min.) begins just after the liquid reaches the required sterilization temperature. PRINTER MODE The microprocessor comes out from the factory with the configuration of “connection: PC”. To make possible printing a sterilization report, if the printer has a switch called “PRINT”, you just have to press it (only for table top printers “ITS”...
  • Page 18 AESi/23 In automatic printing mode, temperature data, step of the cycle, and also the time consumed by every step will be stated. To set automatic printing: 1.- Keep pressed key “TEMPERATURE” (4), during some seconds, the screen will show the message :”CONNECTION: PC”.

  • Page 19: Protected Programs (Info.)

    AESi/23 PROTECTED PROGRAMS (Info.) The autoclave comes from the factory with 4 standard program of sterilization, memorized in programs P0 to P3, and they are protected, that means impossibility to change them. Otherwise, to have access and block or unblock the program of our choice, we have to follow the next steps: 1.

  • Page 20: Cleaning And Maintenance

    AESi/23 In this case it can be continued the sterilization while the probe 2 is changed, by editing the programs as SOL/LIQ-1 / AGAR-1. FAULT HEATING When a cycle of sterilization starts, the evolution of the temperature is controlled up to the selected temperature.
  • Page 21 AESi/23 In case of using the autoclave intensively it is recommended to shorten the maintenance intervals: To clean the gasket and the inside part of the lid DAILY To clean the external surfaces To clean the sterilization chamber and its respective WEEKLY accessories To disinfect the external surfaces...
  • Page 22 AESi/23 To clean the inside of the autoclave, turn the drain tap (No. 1), connecting a hose to the terminal of the drain (No. 13) and place a container. Clean the sterilization chamber, the cover- resistance grid, and the baskets (as well as the internal surfaces in general) with a clean cotton cloth soaked in water, to which a little neutral detergent may eventually be added.
  • Page 23 AESi/23 - CHANGING THE PAPER ROLL OF THE PRINTER To change the paper roll of the printer, proceed as follows: 1) Open the paper roll compartment by pressing the OPEN key (fig. 1.15) or using the two opening levers on the plastic cover (fig.
  • Page 24 AESi/23 - MAINTENANCE OF THE SAFETY VALVE This operation is needed in order to make sure the valve will work properly for a long time. Important information the autoclave must be cold (room temperature) and without pressure the autoclave must be switched off Complying with above information, remove the four screws from the lid to access to the security valve at the back of the autoclave (1).

  • Page 25: Accidental Blocking Of The Lid Due To Failure Of The Safety System

    AESi/23 - CALIBRATION PORT To access the calibration port, remove the screws from the rear cover and remove the 1/2" cap (see image below, fig.3) with an allen key to have a free 1/2" hole. It is very important to use a watertight fitting to pass the corresponding probes as the port is in direct contact with the pressure vessel.

  • Page 26: Safety Thermostat

    AESi/23 We will press down the safety piston to liberate the central locking wheel with a soft material bar (made of wood, aluminum, brass, copper, etc.). We will proceed as follows: 1.- Remove the head of the locking wheel (3): Remove the plastic lid (1).

  • Page 27: External Dimensions

    AESi/23 EXTERNAL DIMENSIONS 27/40...
  • Page 28 AESi/23 28/40...
  • Page 29 AESi/23 29/40...

  • Page 30: Electric Diagram

    AESi/23 ELECTRIC DIAGRAM 30/40...
  • Page 31 AESi/23 31/40...
  • Page 32 AESi/23 32/40...
  • Page 33 AESi/23 33/40...
  • Page 34 AESi/23 34/40...

  • Page 35: Piping Diagram

    AESi/23 PIPING DIAGRAM 35/40...

  • Page 36: Declaration Of Conformity

    AESi/23 DECLARATION OF CONFORMITY 36/40...
  • Page 37 AESi/23 37/40...
  • Page 38 AESi/23 38/40...
  • Page 39 AESi/23 39/40...
  • Page 40 AESi/23 40/40...
