TLV-S SERIES
- INSTALLATION GUIDE
Information to consider before installing your autoclave.
INDEX
Electrical connection (Standard) .......................................................................................................................................................................Page 2
Electrical connection (North America) .............................................................................................................................................................Page 3
Connections graph ...............................................................................................................................................................................................Page 4
Included components ..........................................................................................................................................................................................Page 5
Drainage connections ..........................................................................................................................................................................................Page 6
Water supply for cooling .....................................................................................................................................................................................Page 8
Water supply for sterilization .............................................................................................................................................................................Page 9
Use of ECOPUR-TLV in combination with TLV-S Series autoclaves ........................................................................................................ Page 10
Integrated basket lift system installation ...................................................................................................................................................... Page 11
Dimensions to consider ................................................................................................................................................................................... Page 14
Environmental conditions ................................................................................................................................................................................ Page 14
Recommended maintenance .......................................................................................................................................................................... Page 15
Sterilization
VERTICAL MULTIPURPOSE
AUTOCLAVES
TLV-S SERIES
TLV-S SERIES - INSTALLATION GUIDE
1
Advertisement
Related Manuals for Raypa TLV-S Series
Summary of Contents for Raypa TLV-S Series
- Page 1 Drainage connections ......................................Page 6 Water supply for cooling .....................................Page 8 Water supply for sterilization .....................................Page 9 Use of ECOPUR-TLV in combination with TLV-S Series autoclaves ......................Page 10 Integrated basket lift system installation ..............................Page 11 Dimensions to consider ....................................Page 14 Environmental conditions ....................................
- Page 2 400 (3P+N+PE) V 16 A TLV-150-220T 50/60 Hz 9000 W 23 A 230 (3P+PE) V 32 A TLV-150-6K-220M 50/60 Hz 6000 W 26 A 230 (1P+N+PE) V 32 A 16 A 16 A 32 A 32 A TLV-S SERIES - INSTALLATION GUIDE...
- Page 3 3600 W 30 A 120 (1P+N+PE) V NEMA 5-50P TLV-110-220T-US 50/60 Hz 9000 W 23 A 230 (3P+PE) V NEMA L15-30P TLV-150-220T-US 50/60 Hz 9000 W 23 A 230 (3P+PE) V NEMA L15-30P 5-50R L15-30R TLV-S SERIES - INSTALLATION GUIDE...
- Page 4 STERILIZATION CHAMBER DRAIN OUTLET ATTENTION! Outlets 5 and 6 must be driven to the drain separately and must be properly attached to it. See page 6. *Outlet 4 must be left unobstructed at all times. TLV-S SERIES - INSTALLATION GUIDE...
- Page 5 4 reinforced NBR hoses 2m long with 3/4" connection at both ends for threaded connection to the equipment and tap (gaskets included). For: 5. STEAM OUTLET 6. DIRECT DISCHARGE OUTLET 12. COOLING WATER INLET 13. STERILIZATION WATER INLET TLV-S SERIES - INSTALLATION GUIDE...
- Page 6 DRAINAGE CONNECTIONS All models from the TLV-S Series are equipped with two drainage outlets which serve to discharge the purge, regulate internal pressure, and expel the steam and condensates produced during each sterilization cycle. Additionally, they feature an active cooling system, which utilizes a heat exchanger with the main water supply to reduce the temperature of these gas and liquid emissions to a safe level before being discharged into the drain.
- Page 7 Improperly secured hoses pose a substantial risk of detachment, which could lead to hazardous situations such as burns. CONSIDER: Height and position of drain outlets: STEAM DIRECT MODEL OUTLET DISCHARGE OUTLET TLV-50 170 mm 110 mm TLV-75 180 mm 110 mm TLV-110 190 mm 115 mm TLV-150 190 mm 110 mm TLV-S SERIES - INSTALLATION GUIDE...
- Page 8 TLV-S SERIES WATER SUPPLY FOR COOLING All models from the TLV-S Series are equipped with an active cooling system, which utilizes a heat exchanger with the main water supply to reduce the temperature of the gas and liquid emissions to a safe level before being discharged into the drain.
- Page 9 AUTOMATIC SUPPLY TLV-S Series autoclaves have automated filling of the steam generator that produces the steam during normal operation of the autoclave. Purified water must be used and supply options A, B and C are available using the STERILIZATION WATER INLET (13).
- Page 10 *Note: Take into account that distilled water that is too pure (conductivity less than 5µS/cm) is not recommended as it may cause corrosion on stainless steel in the long term and water level detection problems. USE OF ECOPUR-TLV IN COMBINATION WITH TLV-S SERIES AUTOCLAVES If you don’t have a purified water main...
- Page 11 To ensure safe handling of the baskets in larger volume autoclaves, it is recommended to use a basket lifting crane equipped with a rotating mast. For the TLV-S Series autoclaves, the recommended model is the FIX-LIFT crane, which is capable of handling loads up to 30 kg.
- Page 12 1. UPPER LIMIT OF THE MOBILE MAST 2. MOBILE MAST 4. SAFETY RING 5. CHAIN 3. VERTICAL COLUMN 6. BASKET HOLDER 7. LIFT SYSTEM CONTROL 8. MAIN SWITCH 9. ELECTRICAL PANEL 10. VERTICAL COLUMN HOUSING TLV-S SERIES - INSTALLATION GUIDE...
- Page 13 The accessory is ready for use. To ensure safety and proper the placement of the remaining components: carabiner, chain, and maintenance, we recommend following the instructions in the basket holder. specific lift system manual carefully. TLV-S SERIES - INSTALLATION GUIDE...
- Page 14 This equipment can operate under the following connections. maximum conditions: • Ambient temperature: 30 ºC • Humidity: 75% • Altitude: 3.000 meters above sea level.* *In case of higher altitudes, contact with our technical team. TLV-S SERIES - INSTALLATION GUIDE...
- Page 15 Ensure all components are dried completely after cleaning. ANNUAL MAINTENANCE Autoclaves from the TLV-S Series are equipped with a bacteriological filter, which should be replaced either upon reaching the recommended interval or when a filter blockage is detected.
- Page 16 Should you encounter any issues, have questions, or require further information regarding maintenance of the TLV-S Series autoclave, please don’t hesitate to reach out to our technical support service using the following contact details.
