RIUKOE Ares Profile 600 User Manual

Rdm tft display & touch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
（RDM TFT DISPLAY & TOUCH）
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep
this manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
Ares Profile 600

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ares Profile 600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RIUKOE Ares Profile 600

Summary of Contents for RIUKOE Ares Profile 600

  • Page 1 Ares Profile 600 （RDM TFT DISPLAY & TOUCH） This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION................2 4.INSTALLATION ..................4 5.DMX CONNECTION ................. 5 6.RDM NOTE....................8 7.TECHNICAL SPECIFICATION..............8 8.PANEL OPERATION ................12 9.CHANNEL DESCRIPTION ..............23 10.TROUBLE SHOOTING ................. 28 11.CLEANING AND MAINTENANCE ............29...

  • Page 3: Statement

    1.STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee and also cannot be responsible for any malfunction &...

  • Page 4: Preventing Electric Shock

    installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock. Always power off/unplug the fixture before removing any covers. ⚫ Ensure that the power is turned off when connecting the fixture to the AC ⚫...

  • Page 5: Installation

    WARNING! Take measure to prevent personal injury. Do not look directly at the light source from close range. ⚫ Take precautions to prevent injury due to falls when working at height. ⚫ For permanent installation, ensure that the fixture is securely fastened to ⚫...

  • Page 6: Dmx Connection

    clamp to the included Omega Bracket using a M10 screw fitted through the center hole of the ‘omega bracket’. As an added safety measure be sure to attached at least one properly rated Safety Cable to the fixture using one of the safety cable rigging point integrated in the base assembly.

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise.

  • Page 8: Dmx Address Setting

    standards DMX Address Setting: By using a universal DMX controller to control the units, you will need to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink.

  • Page 9: Rdm Note

    6.RDM NOTE RDM is an extended version of DMX512-A protocol. It is a remote device management protocol. Traditional DMX512 protocol communication is one-way communication. The protocol is based on RS-485 bus. RS-485 is a time-sharing multi-point, half-duplex protocol. Only one port is allowed to output at the same time.
  • Page 10 - Light source life: 20000h - Voltage:AC100-240V,50/60Hz Optical System - Zoom angle: linear 5°- 50° Color Wheel - 1 color plate has 6 colors, can achieve two-way rainbow, half color effect - Linear CMY color mixing system - Variable CTO: CTO color temperature correction (7200-3200K) Gobo wheel - Fixed : 4 fixed gobos, which can change speed and shake - Rotating : 7 optional gobos (pluggable), variable speed jitter and two-way...
  • Page 11 Protocols - Control mode: DMX512, master-slave operation , Auto, Sound - Channel mode: 39 CHs mode - Support RDM function, DMX software upgrade function Display/Case/Base - Display mode: LCD touch screen, can reverse 180° display - High temperature resistant engineering plastic case + aluminum base - Dust-proof and oil-proof design Movement - Pan/ Tile: 540°/270°...

  • Page 12: Fixed Gobo Wheel

    Fixed Gobo Wheel Rotation Gobo Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice.

  • Page 13: Panel Operation

    8.PANEL OPERATION 8.1 Brief The light panel diagram show in below, above area is Title for fixture description, below area show fixture real-time status, such as DMX cable status, lamp status, error or information (ps.when there are message haven't been checked, echo ’ERR’...
  • Page 14 click item or value to complete operation of set light setting(parameters) or view light state. The area on the right hand side is rotary encoder with button or key, As ⚫ auxiliary input interface, if fixture disable touch function, the encoder/key can been choose to set or view the item, and then press the encoder button/key to confirm the selection, rotary encoder or push key again set the parameter value, finally, Press encoder button/key one again to save...

  • Page 15: Sub Menuļ¼ˆParameter

    when the selected parameters is a Boolean value (such as ON or OFF), can ⚫ directly modify setting by chick corresponding item, the setting will save right now. When the parameter is a key item, chick corresponding item, a dialog ⚫...
  • Page 16 8.3 Operation and parameter instruction Chick item of main menu, enter corresponding sub menu shown in Figure 6, In main menu, chick 1/6 function button into corresponding parameter menu. In sub menu(page), chick main item on the left side of displayer, can shift to...
  • Page 17 corresponding sub menu(page) quickly. 8.3.1 DMX Address setting Enter page show in above, can set fixture DMX address, channel mode and so on. The menu settings of fixture have optimized the setting of addresses. Several settings of the address are as follows: Select "...
  • Page 18 Automatically loops scenes in set time order (scenes with Auto time "0" are ignored). Master and slave selection, non-DMX mode takes effect, select the mode of data output, fixture detect DMX cable state automatic switch output, prevent data conflicts fixture runs built-in program. If DMX has no signal, it outputs Master M/S Choose data (synchronization), otherwise it does not output data.
  • Page 19 Set the display direction of the screen. Normal screen orientation (no reverse) Screen Rot Reverse screen display Automatically detect the direction of lamps and AUTO automatically switch direction. Set the indication mode of DMX signal indicator. Mode1 When signal is bright, no signal is off. Indicator Mode2 When signal is off, no signal is bright.

  • Page 20: Set Light Run Parameter

    channel table. Through this page, you can edit 10 scenes, as shown in the following table: Sence mode Scene Select Select the current operation scenario. 1~10 The 10 scenes sets the format Scene Time Sets the retention time of the current scene when it is automatic, unit in 0.1 seconds.

  • Page 21: Status And Information

    P/T Rectify Setting up fixture to detect XY lost step and correct Uncorrected position after out of step After losing step, the position is automatically corrected and the out of step fault is recorded. Pan Offset Setting the zero point of the PAN of the fixture 4-150 Tilt Offset Setting the zero point of the TILT of the fixture...
  • Page 22 Entering the page shown in below, you can view the information and real-time status of the fixture to get their usage status. If the fixture need customer service, please provide the status information displayed on the page as a basis for judgment, as shown in the following table: Status information Stepper Display information status of all motors and signals in fixture.
  • Page 23 Striking the positioning rod when the motor is reset NTC error The temperature sensor signal is abnormal Fixture Displays the critical state data of the current fixture for reference. status Communication 0~100%, Communication quality of internal data link of lamps and lanterns Error count The number of erroneous frames was detected after power on, and the total number of erroneous frames was...

  • Page 24: Channel Description

    9.CHANNEL DESCRIPTION This luminaire channel can be viewed in scene mode in order, channel mode is set in the "Address Settings" page, specific details of the data as follows: CHANNEL TABLE 39CHs Name Value DESCRIPTION Cyan Cyan 0-255 Magenta Magenta 0-255 Yellow Yellow...
  • Page 25 Orange+peach 55-59 Peach 60-64 Peach+CTO 65-69 Rotate reverse slow to 70-127 fast Linear color 128-255 Strobe 0-255 Dark Pulse strobe (slow to fast) 4-103 Open 104-107 Strobe Fade strobe (slow to fast) 108-207 Open 208-212 Random strobe (slow to fast) 213-251 Open 252-255...
  • Page 26 Stop 114-117 Rotate forward slow to fast 118-159 Shake slow to fast Gobo1 160-173 Shake slow to fast Gobo2 174-187 Shake slow to fast Gobo3 188-200 Shake slow to fast Gobo4 201-214 Shake slow to fast Gobo3 215-227 Shake slow to fast Gobo2 228-241 242-255 Shake slow to fast Gobo1...
  • Page 27 Shake slow to fast Gobo7 248-255 Gobo Autorotation 0-255 0-360 degrees 0-127 Gobo Rotate reverse (fast to slow) CH13 128-190 Autorotation Stop 191-192 Rotate forward (slow to fast) 193-255 Gobo Fine CH14 Gobo Fine 0-255 Prism 0-255 None CH15 Prism 0-127 Insert prism 128-255...
  • Page 28 Frame1 CH23 Frame1 0-255 Frame2 CH24 Frame2 0-255 Frame3 CH25 Frame3 0-255 Frame4 CH26 Frame4 0-255 Frame5 CH27 Frame5 0-255 Frame6 CH28 Frame6 0-255 Frame7 CH29 Frame7 0-255 Frame8 CH30 Frame8 0-255 Frame Rotation CH31 Frame Rotation 0-255 Frame Macro CH32 Frame Macro 0-255...

  • Page 29: Trouble Shooting

    10.TROUBLE SHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power and main fuse. 2.

  • Page 30: Cleaning And Maintenance

    1. Make sure the unit does not receive DMX signal.. 2. Check microphone to see if it is good by tapping the microphone. F. If The tilt belt is broken 1. The stepper motor might be damaged or the cable connected to the PCB is broken.
  • Page 31 Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician. Should you need any spare parts, please order genuine parts from your local dealer.
  • Page 32 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
