  • Page 1 LAB GT2 GP Instruction Manual...
  • Page 2 BAG 1 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Shock Bladder Cap 3127 Shock Body Cap 3132 Medium Teflon Coated Shock Cap + Ball Cap 3134 Cap 3131K Shock Shaft Bushing + Screw Cap 3133 Shock Piston 8Holes...

  • Page 3: Shock Absorbers

    BAG 1 Shock Absorbers BUILD Step 0 Cap 17039 Flat side Apply some mineral oil before assembling Measure with the shock shaft fully extended Cap 3143 Cap 3133 DEFAULT SETUP Cap 3134 FRONT: 23.0mm Cap 3127 REAR: 23.0mm Cap 3138K Cap 3140 Apply some mineral oil before assembling...
  • Page 4 BAG 1 Shock Absorbers BUILD Step 1 DEFAULT SETUP FILL SHOCK AS FOLLOWS FRONT: 1000cSt Extend the shock shaft completely REAR: 1000cSt Fill up the shock body fully with silicone oil (not included) Move the shock shaft slowly up and down to let all air bubbles escape from oil Insert the O-Ring inside the...
  • Page 5 BAG 1 Shock Absorbers BUILD Step 2 Cap 3131K Cap 3131K Cap 3131K INITIAL VALUE FRONT: 9.0mm REAR: 10.0mm Cap 3132 This initial value must be changed to set up the CLOSE SHOCK AS FOLLOWS required ride height Insert the shock bladder into the shock cap and close the shock cap DEFAULT SETUP...
  • Page 6 BAG 2 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Differential Bevel Cap 3115 Differential Case Cap 3118K Gear 10T Cap 3117 Crown Gear 43T Cap 3118K Washer 3.5x10x0.2 Differential Paper Cap 2017 Bearing 8x16x5 Cap 3116...
  • Page 7 BAG 2 Differentials BUILD Step 0 Cap 3121 Cap 3115 Cap 2017 Cap 3124 Align pin with groove in the bevel gear Cap 3125 Cap 3118K Cap 3160 Graphite grease Graphite grease Cap 3160 Graphite grease Graphite grease Cap 3124 Cap 3125 Align pin with groove in the bevel gear...
  • Page 8 BAG 2 Differentials BUILD Step 1 (4x) Cap 2143 Cap 3118K (2x) (4x) Cap 3118K Use graphite grease to coat the differential paper gasket before installation (4x) Cap 3118K Cap 3116 Fill the differential with silicon oil (not included) a bit above the bevel gears as shown on the left DEFAULT SETUP...
  • Page 9 BAG 3 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Differential Pinion Cap 3007 Cap 3180 Front Shock Column Holder Cap 3065 Bearing 5x13x4 Cap 3023 Rear Shock Column Button Head Cap Cap 3113 Pinion Gear 13T Cap 17032...
  • Page 10 BAG 3 Parts included in the bag Part Code Part Name & Picture Cap 17006 Grub Screw M3x3 Cap 3048-2.5 Rear Anti-Roll Bar 2.5 Cap 3049-2.7 Rear Anti-Roll Bar 2.7...
  • Page 11 BAG 3 Differential Pinion Holder BUILD Push the shaft driver against the pinion gear to Cap 3113 leave a very small gap and then tighten the grub screw onto the pinion gear flat spot (2x) Cap 3065 Cap 3113 Cap 3112 Thread lock Cap 3007...

  • Page 12: Front Bulkhead

    BAG 3 Front Bulkhead Step 0 (4x) Cap 17034 Thread lock (2x) Cap 17032 Thread lock DEFAULT SHOCK ABSORBER POSITION DIFFERENTIAL (2x) Cap 3180 PINION HOLDER Cap 3181 (4x) Cap 40229 Thread lock (2x) Cap 3007 DEFAULT PINION POSITION DOWN...

  • Page 13: Front Differential

    BAG 3 Front Bulkhead Step 1 (8x) Cap 17030 Thread lock DOWN Cap 3046 Cap 3045 FRONT DIFFERENTIAL...
  • Page 14 BAG 3 Front Bulkhead Step 2 Cap 3048-2.5 (2x) Cap 17006 Thread lock (2x) Cap 3046 (2x) Cap 18082...
  • Page 15 BAG 3 Rear Blukhead Step 0 (2x) Cap 17034 Thread lock (2x) Cap 17032 Thread lock DEFAULT SHOCK ABSORBER POSITION (2x) Cap 3023 DIFFERENTIAL PINION HOLDER Cap 3216 (4x) Cap 40229 (2x) Cap 3007 DEFAULT PINION POSITION DOWN...

  • Page 16: Rear Differential

    BAG 3 Rear Blukhead Step 1 (8x) Cap 17030 Thread lock DOWN Cap 3046 Cap 3045 REAR DIFFERENTIAL...
  • Page 17 BAG 3 Rear Blukhead Step 2 Cap 3049-2.7 (2x) Cap 17006 Thread lock (2x) Cap 3046 (2x) Cap 18082...
  • Page 18 BAG 4 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3205 Lower Front Arm Cap 3032P Anti-roll Bar Arm Holder Cap 3206 Upper Front Arm Cap 3030P Down Stop Arm Holder Upper front Arm Turnbuckle Cap 3212 Lower Rear Arm...
  • Page 19 BAG 4 Front Lower Arms BUILD Cap 2018 (2x) Cap 2129 (2x) Cap 17032 Cap 3187P Cap 17032 Cap 3030P (2x) Cap 3210K Cap 3205 (4x) Cap 17023 Cap 3032P Cap 17023...
  • Page 20 BAG 4 Front Upper Arms BUILD Cap 3042 Cap 3070P (2x) Cap 2129 Cap 2129 Cap 3210K Cap 3210K Cap 3068P Cap 3206 (4x) Cap 17023 Cap 3211K...
  • Page 21 BAG 4 Rear Lower Arms BUILD Cap 17032 Cap 2018 (2x) Cap 17032 (2x) Cap 2129 Cap 3213 (2x) Cap 3210K Cap 3212 Cap 17023 (4x) Cap 17023 Cap 3030P Cap 3032P...
  • Page 22 BAG 5 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3018 Front Upright Cap 3220 Pivot Ball 10mm Cap 3219 Rear Upright Cap 3028 Wheel Hub Offset 0 Cap 3020 Front Upper Upright Cap 3013 CVD Axle Shaft 94mm...
  • Page 23 BAG 5 Parts included in the bag Part Code Part Name & Picture Cap 2017 Bearing 8x16x5 Cap 2012 Bearing 12x18x4 Cap 2134 Parallel Pin 2.5x11.8 Cap 3082 Parallel Pin 2.5x15.8 Cap 17010 Grub Screw M4x4 Cap 3084 Grub Screw M4x14 Button Head Cap Cap 17030 Screw M3x6...

  • Page 24: Default Setup

    BAG 5 Front Upright BUILD Step 0 Cap 17010 Thread lock Cap 2007 Cap 2018 Cap 3081 Cap 3013 Cap 3028 Cap 2018 Cap 2012 Cap 3028 Cap 2017 Graphite grease Cap 3028 DEFAULT SETUP Central hole Cap 3026 Screw and adjust the Cap 3044R nut so as the pivot ball can be moved smoothly...
  • Page 25 BAG 5 Front Upright BUILD Step 1 Cap 17023 Thread lock (2x) Cap 17030 Thread lock Cap 3063 Cap 22015 Cap 3084 Thread lock Cap 2237...
  • Page 26 BAG 5 Rear Upright BUILD Cap 3223 (4x) Cap 17030 Cap 3020P Cap 2007 Cap 3081 (4x) Cap 17030 Thread lock Cap 3013 (2x) Cap 3061 Cap 2017 Cap 3028 Cap 3028 Graphite grease (2x) Cap 3220 Cap 3028 Cap 2012 DEFAULT SETUP Cap 3219...
  • Page 27 BAG 6 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3035 Left Steering Bellcrank Cap 3034 Servo Saver Column Cap 3037 Lower Steering Bellcrank Cap 18169 Uniball 5.8mm Cap 2435 Upper Steering Bellcrank Cap 2237 Uniball 7mm...
  • Page 28 BAG 6 Parts included in the bag Part Code Part Name & Picture Cap 17040 Self-locking Nut M3 Button Head Cap Cap 2235 Screw M3x5 Button Head Cap Cap 17030 Screw M3x6 Countersunk Head Cap Cap 17029 Screw M3x6...

  • Page 29: Steering System

    BAG 6 Steering System Step 0 Cap 16019 Cap 3035 Cap 16019 Cap 3067 Cap 2013 Cap 17040 Screw and adjust the self-locking nut M3 position for minimum play and freely movement Cap 29209...
  • Page 30 BAG 6 Steering System Step 1 Screw and adjust the self-locking Cap 3037 nut M3 position for minimum play and freely movement DEFAULT SETUP Cap 17040 Cap 2013 Around 1.0mm Cap 29209 Cap 16033 Cap 3067 Cap 16028 Cap 2435 Cap 16019 Cap 16019 Cap 16014...
  • Page 31 BAG 6 Steering System Step 2 (2x) Cap 2235 Thread lock (2x) Cap 22023 Cap 3207 (2x) Cap 17030 Thread lock (2x) Cap 2237 (2x) Cap 3043 (4x) Cap 2361 (2x) Cap 3034 BOOMERANG DEFAULT SETUP DEFAULT SETUP Around 38.0mm...
  • Page 32 BAG 7 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3057K Front Upper Arm Plate 7° Cap 2120-3.0 Anti-Roll Bar Pivot 3.0 Turnbuckle Cap 3217 Cap 17006 Grub Screw M3x3 4mm x 28mm Anti-roll Bar Button Head Cap...

  • Page 33: Rear Bulkhead

    BAG 7 Front & Rear Bulkhead Mounting REAR BULKHEAD Cap 2146 The chassis is (2x) Cap 17032 included the box Cap 3203 FRONT BULKHEAD (4x) Cap 2146 Thread lock (4x) Cap 2146 Thread lock...
  • Page 34 BAG 7 Steering System Mounting STEERING SYSTEM (2x) Cap 2146 Thread lock...
  • Page 35 BAG 7 Front Lower Arms BUILD Mounting Cap 2120-3.0 Cap 17006 Thread lock DEFAULT SETUP 0.0mm (2x) Cap 14042KS Cap 18169 Thread lock for screw M3x10 Cap 40463 Cap 3036-1.0 Put one shim here between the chassis and arm pivot DEFAULT SETUP Around 3.0mm (2x) Cap 2146...
  • Page 36 BAG 7 Rear Lower Arms BUILD Mounting Cap 2120-3.0 Cap 17006 Thread lock DEFAULT SETUP 0.0mm (2x) Cap 14042KS Cap 18169 Cap 40463 Thread lock for DEFAULT SETUP Screw M3x10 Around 3.0mm (2x) Cap 2146 Thread lock...
  • Page 37 BAG 7 Front Upper Arms BUILD Mounting RIGHT FRONT UPPER ARM Cap 3057K LEFT FRONT UPPER ARM (2x) Cap 2147 Thread lock...
  • Page 38 BAG 7 Rear Upper Arms BUILD Mounting Cap 17006 Thread lock Cap 17006 REAR UPPER ARM (2x) Cap 3218 DEFAULT POSITION Cap 3217 DEFAULT SETUP Around 16.0mm...
  • Page 39 BAG 7 Front Upright BUILD Mounting Cap 3036-1.0 Graphite grease FRONT UPRIGHT...

  • Page 40: Rear Upright

    BAG 7 Rear Upright BUILD Mounting REAR UPRIGHT Graphite grease REAR PIVOT FRONT PIVOT DEFAULT SETUP DEFAULT SETUP Around 6.5mm Around 5.0mm...
  • Page 41 BAG 8 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 2050-62B 1st Gear 62t Cap 17021 Gear Box Screw M2.5x10 Cap 2051-58B 2nd Gear 58t Cap 16031H Gear Box Hard Spring Cap 2058B Flange 1st Gear Cap 3164...
  • Page 42 BAG 8 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 2038 Brake Pad Bushing Cap 3215 Rear Spacer Plate Cap 3253 Differential Mounting Base Cap 3099 Rear Stiffener Cap 3258 Differential Holder Cap 18082 Flanged Bearing 5x8x2.5...
  • Page 43 BAG 8 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Button Head Cap Cap 3043 Steering Turnbuckle DX-SX Cap 17030 Screw M3x6 Button Head Cap Cap 3179 Ext Uniball Link 7mm Cap 17034 Screw M3x8 Button Head Cap...
  • Page 44 BAG 8 Central Transmission Step 0 GEAR GEAR Cap 17038 Cap 2015 Cap 17031 One way oil Cap 2050-62B Cap 2051-58B Cap 2059V2 Cap 2015 Cap 2058B...
  • Page 45 BAG 8 Central Transmission Step 1 (2x) Cap 2643 (2x) Cap 2068B (2x) Cap 17021 (2x) Cap 16031H (2x) Cap 16011 (2x) Cap 2128 Cap 3087 The screw M2.5x10 must be smooth as indicated for soft change gear adjustment DEFAULT SETUP Around 14.6mm Insert your hex driver all the way through the...
  • Page 46 BAG 8 Central Transmission Step 2 (2x) Cap 3112 Thread lock GEAR Cap 2006 GEAR (2x) Cap 3260 Cap 2127-0.3 (2x) Cap 3145...
  • Page 47 BAG 8 Central Transmission Step 3 Cap 3253 Cap 18021 Thread lock (2x) Cap 18082 Cap 3255 (2x) Cap 3254 Cap 3094 2063C-K (2x) Cap 2070 2063C-K (2x) Cap 17008 Thread lock Cap 25502 (2x) Cap 2038 DEFAULT SETUP Cap 17030 Thread lock Around 4.0mm...
  • Page 48 BAG 8 Central Transmission Step 4 Cap 3080 (2x) Cap 17040 Cap 3164 (2x) Cap 17031 (4x) Cap 2146 (2x) Cap 17031 Thread lock Thread lock...
  • Page 49 BAG 8 Central Transmission Step 5 (2x) Cap 17034 Thread lock (4x) Graphite grease Cap 3100 Cap 3085 Cap 3204 Cap 3088 (4x) Cap 40229 (2x) Cap 3258 Thread lock...
  • Page 50 BAG 8 Front Upper Deck (2x) Cap 17023 Thread lock (4x) Cap 17025 Thread lock Cap 3208...
  • Page 51 BAG 8 Rear Upper Deck Cap 3043 (4x) Cap 17025 Thread lock (2x) Cap 3179 Cap 3098 Cap 3215 (2x) Cap 2444 Cap 17030 Thread lock Cap 22018 (2x) Cap 17030 Cap 3080 Thread lock Cap 17012 Thread lock (4x) Cap 17029 Thread lock...
  • Page 52 BAG 9 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3096 Rear Radioplate Cap 601 Servo Lever Cap 3095 Front Radioplate Cap 3083 Brake Throttle Arm Cap 40083 Battery Plate Holder Cap 17041 Carburetor Linkage Throttle T Joint...
  • Page 53 BAG 9 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 18198 Battery Plate Cap 17041 Brake Regulator Knobble Cap 3079 Battery Plate Holder Cap 17006 Grub Screw M3x3 Button Head Cap Cap 14041L Long Uniball Link 5.8mm Cap 18019...
  • Page 54 BAG 9 Parts included in the bag Part Code Part Name & Picture Countersunk Head Cap Cap 17029 Screw M3x6...
  • Page 55 BAG 9 Steering Servo (4x) Cap 17034 Thread lock (2x) Cap 2452 (2x) Cap 14041L SERVO Cap 16073 (NOT INCLUDED) (4x) Cap 18086 Cap 18169 STEERING SERVO LEVER (NOT INCLUDED) DEFAULT SETUP Around 31.8mm (2x) Cap 17030 Thread lock...
  • Page 56 BAG 9 Throttle & Brake Servo (4x) Cap 17034 Thread lock SERVO (2x) Cap 14042KS (NOT INCLUDED) Cap 40463 (2x) Cap 2452 (4x) Cap 18086 Cap 18169 DEFAULT SETUP Around 4.0mm Select the lever that fits Cap 601 with your servo (2x) Cap 17030 Thread lock...
  • Page 57 BAG 9 Throttle & Brake Levers Cap 17041 (2x) Cap 17006 Thread lock DEFAULT LENGTH Around 59.0mm (2x) Cap 16015 Cut this side Cap 17041 Cap 3146 Cap 17041 Cap 17021 Thread lock Cap 17034 Thread lock Cap 17034 Thread lock Cap 3083 Cap 22017 Cap 18169...
  • Page 58 BAG 9 Radioplate Step 0 Cap 3102 Cap 3095 Cap 3096 (9x) Cap 17030 Thread lock Cap 17029 Thread lock (2x) Cap 40083 (7x) Cap 40115...

  • Page 59: Steering Servo

    BAG 9 Radioplate Step 1 (8x) Cap 17030 THROTTLE & BRAKE STEERING SERVO SERVO...
  • Page 60 BAG 9 Radioplate Step 2 Cap 14001 Cap 246-B Cap 246-C Cap 18019 (2x) Cap 17030 Cap 17035 Cap 18019 Cap 17035 PLACE THE POWER EXTENSION CABLE (NOT INCLUDED) Cap 246-A INSERT THE RECEIVER (NOT INCLUDED)

  • Page 61: Receiver Battery

    BAG 9 Radioplate Step 3 (2x) Cap 17038 Cap 18198 Cap 3079 (4x) Cap 17030 Thread lock RECEIVER BATTERY (NOT INCLUDED)
  • Page 62 BAG 9 Radioplate Step 4 (7x) Cap 17029 Thread lock...
  • Page 63 BAG 9 Radioplate Step 5 Cap 17034 Thread lock THROTTLE & BRAKE LEVERS Cap 3146 Silicone pipe Cap 17041...
  • Page 64 BAG 10 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3158 Bumper Foam Cap 3151 Rear Body Bracket Cap 3156 Bumper Cap 22021 Shim 3x6x1.0 Cap 3157 Bumper Plate Cap 22015 Shim 3x6x2.0 Cap 3066 Bumper Nose...
  • Page 65 BAG 10 Parts included in the bag Part Code Part Name & Picture Button Head Cap Cap 17012 Screw M3x12 Button Head Cap Cap 17120 Screw M3x20 Button Head Cap Cap 17140 Screw M3x25 Button Head Cap Cap 17034 Screw Flange M3x8 Countersunk Head Cap Cap 17031 Screw M3x8...

  • Page 66: Front Shock Absorber

    BAG 10 Front Shock Absorbers BUILD Mounting Cap 17034 Thread lock FRONT SHOCK DEFAULT SHOCK ABSORBER ABSORBER POSITION Cap 22021 Cap 17012...
  • Page 67 BAG 10 Rear Shock Absorbers BUILD Mounting Cap 17034 Thread lock REAR SHOCK ABSORBER Cap 22015 Cap 17012...
  • Page 68 BAG 10 Bumper (2x) Cap 3155 (2x) Cap 17031 (2x) Cap 17139 (2x) Cap 3153 Cap 3157 Cap 3066 Cap 3158 Cap 3156 (2x) Cap 17131...
  • Page 69 BAG 10 Bumper Mounting Cap 3155 Cap 17139 Cap 3153 Cap 17032 Cap 3022 Cap 2146 Thread lock Cap 2146 BUMPER (2x) Cap 2112 (2x) Cap 2145...
  • Page 70 BAG 10 Rear Differential Cover Mounting Cap 17040 Cap 3159K Cap 17031 (2x) Cap 17032 Thread lock...
  • Page 71 BAG 10 Rear Body Holder (2x) Cap 3155 (2x) Cap 17030 (2x) Cap 3153 Cap 3152 (2x) Cap 17139 (4x) Cap 17040 (2x) Cap 17140 (2x) Cap 3151...
  • Page 72 BAG 10 Rear Body Holder Mounting REAR BODY HOLDER (2x) Cap 17120 (2x) Cap 17023 Remove temporarily the rear upper arm to insert the nut in (2x) Cap 17040 its seat...
  • Page 73 BAG 11 Parts included in the bag Part Code Part Name & Picture Cap 3177 Tank Exhaust Pipe Spring Cap 16078L Column Cap 506XL Exhaust Pipe Spring Cap 2211K Engine Mounts Cap 17010 Grub Screw M4x4 Button Head Cap Cap 2147 Screw Flange M4x8 Countersunk Head Cap Cap 17031...
  • Page 74 BAG 11 Tank & Exhaust Pipe Spring Cap 3177 Cap 17010 Thread lock Cap 16078L Cap 506XL (2x) Cap 17031 Cap 2146 Thread lock...

  • Page 75: Engine Mount

    BAG 11 Engine Mount 2211K 2211K (4x) Cap 2147 Thread lock...
  • Page 76 BAG 12 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3166 Clutch flywheel Cap 2123-23 Pinion 23T Cap 2123V2- Cap 408 Clutch flywheel Nut Pinion 18T Clutch Shoes Cap 3167 Cap 3169 Clutch Bushing Low-Medium Grip...
  • Page 77 BAG 12 Clutch Long Gears Clutch Short Gears 5x10x4 (Optional Not Included) Cap 3172 (2x) 5x8x2.5 Cap 3175 (22T) Cap 3166 Cap 3174 (17T) Cap 408 Cap 3168 Cap 2391 Cap 3170 Cap 3171 Cap 2123-23 Cap 2123V2-18 Cap 3170 Cap 3167 Cap 415 Low-Medium Grip (Default)
