  • Page 1 LAB GT2 EP Instruction Manual...
  • Page 2 BAG 1 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Shock Bladder Cap 3127 Shock Body Cap 3132 Medium Teflon Coated Shock Cap + Ball Cap 3134 Cap 3131K Shock Shaft Bushing + Screw Cap 3133 Shock Piston 8Holes...

  • Page 3: Shock Absorbers

    BAG 1 Shock Absorbers BUILD Step 0 Cap 17039 Flat side Apply some mineral oil before assembling Measure with the shock shaft fully extended Cap 3143 Cap 3133 DEFAULT SETUP Cap 3134 FRONT: 23.0mm Cap 3127 REAR: 23.0mm Cap 3138K Cap 3140 Apply some mineral oil before assembling...
  • Page 4 BAG 1 Shock Absorbers BUILD Step 1 DEFAULT SETUP FILL SHOCK AS FOLLOWS FRONT: 1000cSt Extend the shock shaft completely REAR: 1000cSt Fill up the shock body fully with silicone oil (not included) Move the shock shaft slowly up and down to let all air bubbles escape from oil Insert the O-Ring inside the...
  • Page 5 BAG 1 Shock Absorbers BUILD Step 2 Cap 3131K Cap 3131K Cap 3131K INITIAL VALUE FRONT: 9.0mm REAR: 10.0mm Cap 3132 This initial value must be changed to set up the CLOSE SHOCK AS FOLLOWS required ride height Insert the shock bladder into the shock cap and close the shock cap DEFAULT SETUP...
  • Page 6 BAG 2 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Differential Bevel Cap 3115 Differential Case Cap 3118K Gear 10T Cap 3117 Crown Gear 43T Cap 3118K Washer 3.5x10x0.2 Differential Paper Cap 2017 Bearing 8x16x5 Cap 3116...
  • Page 7 BAG 2 Differentials BUILD Step 0 Cap 3121 Cap 3115 Cap 2017 Cap 3124 Align pin with groove in the bevel gear Cap 3125 Cap 3118K Cap 3160 Graphite grease Graphite grease Cap 3160 Graphite grease Graphite grease Cap 3124 Cap 3125 Align pin with groove in the bevel gear...
  • Page 8 BAG 2 Differentials BUILD Step 1 (4x) Cap 2143 Cap 3118K (2x) (4x) Cap 3118K Use graphite grease to coat the differential paper gasket before installation (4x) Cap 3118K Cap 3116 Fill the differential with silicon oil (not included) a bit above the bevel gears as shown on the left DEFAULT SETUP...
  • Page 9 BAG 3 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Differential Pinion Cap 3007 Cap 3180 Front Shock Column Holder Cap 3065 Bearing 5x13x4 Cap 3023 Rear Shock Column Button Head Cap Cap 3113 Pinion Gear 13T Cap 17032...
  • Page 10 BAG 3 Parts included in the bag Part Code Part Name & Picture Cap 17006 Grub Screw M3x3 Cap 3048-2.5 Rear Anti-Roll Bar 2.5 Cap 3049-2.7 Rear Anti-Roll Bar 2.7...
  • Page 11 BAG 3 Differential Pinion Holder BUILD Push the shaft driver against the pinion gear to Cap 3113 leave a very small gap and then tighten the grub screw onto the pinion gear flat spot (2x) Cap 3065 Cap 3113 Cap 3112 Thread lock Cap 3007...
  • Page 12 BAG 3 Front Bulkhead Step 0 (4x) Cap 17034 Thread lock (2x) Cap 17032 Thread lock DEFAULT SHOCK ABSORBER POSITION DIFFERENTIAL (2x) Cap 3180 PINION HOLDER Cap 3181 (4x) Cap 40229 Thread lock (2x) Cap 3007 DEFAULT PINION POSITION DOWN...

  • Page 13: Front Differential

    BAG 3 Front Bulkhead Step 1 (8x) Cap 17030 Thread lock DOWN Cap 3045 Cap 3046 FRONT DIFFERENTIAL...
  • Page 14 BAG 3 Front Bulkhead Step 2 Cap 3048-2.5 (2x) Cap 17006 Thread lock (2x) Cap 3046 (2x) Cap 18082...
  • Page 15 BAG 3 Rear Blukhead Step 0 (2x) Cap 17034 Thread lock (2x) Cap 17032 Thread lock DEFAULT SHOCK ABSORBER POSITION (2x) Cap 3023 DIFFERENTIAL PINION HOLDER Cap 3216 (4x) Cap 40229 (2x) Cap 3007 DEFAULT PINION POSITION DOWN...

  • Page 16: Rear Differential

    BAG 3 Rear Blukhead Step 1 (8x) Cap 17030 Thread lock DOWN Cap 3046 Cap 3045 REAR DIFFERENTIAL...
  • Page 17 BAG 3 Rear Blukhead Step 2 Cap 3049-2.7 (2x) Cap 17006 Thread lock (2x) Cap 3046 (2x) Cap 18082...
  • Page 18 BAG 4 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3205 Lower Front Arm Cap 3032P Anti-roll Bar Arm Holder Cap 3266 Upper Front Arm Cap 3030P Down Stop Arm Holder Upper front Arm Turnbuckle Cap 3212 Lower Rear Arm...
  • Page 19 BAG 4 Front Lower Arms BUILD Cap 2018 (2x) Cap 2129 (2x) Cap 17032 Cap 3187P Cap 17032 Cap 3030P (2x) Cap 3210K Cap 3205 (4x) Cap 17023 Cap 3032P Cap 17023...
  • Page 20 BAG 4 Front Upper Arms BUILD Cap 3042 Cap 3070P (2x) Cap 2129 Cap 2129 Cap 3210K Cap 3210K Cap 3068P Cap 3266 (4x) Cap 17023 Cap 3211K...
  • Page 21 BAG 4 Rear Lower Arms BUILD Cap 17032 Cap 2018 (2x) Cap 17032 (2x) Cap 2129 Cap 3213 (2x) Cap 3210K Cap 3212 Cap 17023 (4x) Cap 17023 Cap 3030P Cap 3032P...
  • Page 22 BAG 5 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3018 Front Upright Cap 3220 Pivot Ball 10mm Cap 3219 Rear Upright Cap 3028 Wheel Hub Offset 0 Cap 3020 Front Upper Upright Cap 3013 CVD Axle Shaft 94mm...
  • Page 23 BAG 5 Parts included in the bag Part Code Part Name & Picture Cap 2017 Bearing 8x16x5 Cap 2012 Bearing 12x18x4 Cap 2134 Parallel Pin 2.5x11.8 Cap 3082 Parallel Pin 2.5x15.8 Cap 17010 Grub Screw M4x4 Cap 3084 Grub Screw M4x14 Button Head Cap Cap 17030 Screw M3x6...

  • Page 24: Front Upright

    BAG 5 Front Upright BUILD Step 0 Cap 17010 Thread lock Cap 2007 Cap 2018 Cap 3033 Cap 3013 Cap 3028 Cap 2018 Cap 2012 Cap 3028 Cap 2017 Graphite grease Cap 3028 DEFAULT SETUP Central hole Cap 3026 Screw and adjust the Cap 3044R-K nut so as the pivot ball can be moved smoothly...
  • Page 25 BAG 5 Front Upright BUILD Step 1 Cap 17023 Thread lock (2x) Cap 17030 Thread lock Cap 3063 Cap 22015 Cap 3084 Thread lock Cap 2237...
  • Page 26 BAG 5 Rear Upright BUILD Cap 3223 (4x) Cap 17030 Cap 3020P Cap 2007 Cap 3033 (4x) Cap 17030 Thread lock Cap 3013 (2x) Cap 3061 Cap 2017 Cap 3028 Cap 3028 Graphite grease (2x) Cap 3220 Cap 3028 Cap 2012 DEFAULT SETUP Cap 3219...
  • Page 27 BAG 6 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3035 Left Steering Bellcrank Cap 3034 Servo Saver Column Cap 3037 Lower Steering Bellcrank Cap 18169 Uniball 5.8mm Cap 2435 Upper Steering Bellcrank Cap 2237 Uniball 7mm...
  • Page 28 BAG 6 Parts included in the bag Part Code Part Name & Picture Cap 17040 Self-locking Nut M3 Button Head Cap Cap 2235 Screw M3x5 Button Head Cap Cap 17030 Screw M3x6 Countersunk Head Cap Cap 17029 Screw M3x6...

  • Page 29: Steering System

    BAG 6 Steering System Step 0 Cap 16019 Cap 3035 Cap 16019 Cap 3067 Cap 2013 Cap 17040 Screw and adjust the self-locking nut M3 position for minimum play and freely movement Cap 29209...
  • Page 30 BAG 6 Steering System Step 1 Use a lubricant for the OR assembly Cap 17029 Thread lock to prevent tears, twisting, pinching, cutting and abrasion of the rubber Cap 18169 Cap 171015 DEFAULT SETUP Cap 16033 Around 1.0mm Cap 3037 Cap 16019 Cap 16019 Cap 16014...
  • Page 31 BAG 6 Steering System Step 2 (2x) Cap 2235 Thread lock (2x) Cap 22023 (2x) Cap 17030 Thread lock Cap 3207 (4x) Cap 2361 (2x) Cap 2237 (2x) Cap 3043 (2x) Cap 3034 BOOMERANG DEFAULT SETUP DEFAULT SETUP Around 38.0mm...
  • Page 32 BAG 7 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3057K Front Upper Arm Plate 7° Cap 2120-3.0 Anti-Roll Bar Pivot 3.0 Turnbuckle Cap 3217 Cap 17006 Grub Screw M3x3 4mm x 28mm Anti-roll Bar Button Head Cap...

  • Page 33: Rear Bulkhead

    BAG 7 Front & Rear Bulkhead Mounting REAR BULKHEAD Cap 2146 The chassis is (2x) Cap 17032 included the box Cap 3225 FRONT BULKHEAD (4x) Cap 2146 Thread lock (4x) Cap 2146 Thread lock...
  • Page 34 BAG 7 Steering System Mounting STEERING SYSTEM (2x) Cap 2146 Thread lock...
  • Page 35 BAG 7 Front Lower Arms BUILD Mounting Cap 2120-3.0 Cap 17006 Thread lock DEFAULT SETUP 0.0mm (2x) Cap 14042KS Cap 18169 Cap 40463 Thread lock for screw M3x10 DEFAULT SETUP Around 3.0mm (2x) Cap 2146 Thread lock...
  • Page 36 BAG 7 Rear Lower Arms BUILD Mounting Cap 2120-3.0 Cap 17006 Thread lock DEFAULT SETUP 0.0mm (2x) Cap 14042KS Cap 18169 Cap 40463 DEFAULT SETUP Thread lock for Around 3.0mm Screw M3x10 (2x) Cap 2146 Thread lock...
  • Page 37 BAG 7 Front Upper Arms BUILD Mounting RIGHT FRONT UPPER ARM Cap 3057K LEFT FRONT UPPER ARM (2x) Cap 2147 Thread lock...
  • Page 38 BAG 7 Rear Upper Arms BUILD Mounting Cap 17006 Thread lock Cap 17006 REAR UPPER ARM DEFAULT POSITION (2x) Cap 3218 Cap 3217 DEFAULT SETUP Around 16.0mm...
  • Page 39 BAG 7 Front Upright BUILD Mounting Cap 3036-1.0 Graphite grease FRONT UPRIGHT...

  • Page 40: Rear Upright

    BAG 7 Rear Upright BUILD Mounting REAR UPRIGHT Graphite grease REAR PIVOT FRONT PIVOT DEFAULT SETUP DEFAULT SETUP Around 6.5mm Around 5.0mm...
  • Page 41 BAG 8 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Central Transmission Motor Cap 3008 Cap 40114 Column M3 21mm Holder Central Transmission Cap 3009 Cap 40018P Central Battery Holder Holder Cap 3017 Gear Flange Cap 3226...
  • Page 42 BAG 8 Parts included in the bag Part Code Part Name & Picture Cap 17040 Self-locking Nut M3 Cap 17102 Parallel Pin 3x17.8 Button Head Cap Cap 17026 Screw M3x12 Button Head Cap Cap 2397 Screw M3x14 Button Head Cap Cap 17034 Screw Flange M3x8 Button Head Cap...
  • Page 43 BAG 8 Central Transmission Step 0 Cap 3017 Cap 17102 Cap 3009 Cap 3008 Cap 3016 Cap 2129 (3x) Cap 17029 Cap 2051-57B (3x) Cap 2147...
  • Page 44 BAG 8 Central Transmission Step 1 (4x) Cap 17026 (2X) FAN (NOT INCLUDED) Cap 3060 (2X) FAN (NOT INCLUDED) (8x) Cap 17026 Cap 3039...
  • Page 45 BAG 8 Central Transmission Mounting CENTRAL Cap 3015-B TRANSMISSION Cap 3224-B (4x) Cap 2146 Thread lock...
  • Page 46 BAG 8 Central Transmission Mounting (4x) Cap 29354 (4x) Cap 17034 (4x) Cap 40114 Thread lock (4x) Cap 17040 (4x) Cap 40018P (8x) Cap 2143 Thread lock (4x) Cap 3062 (4x) Cap 17029...
  • Page 47 BAG 8 Central Transmission Mounting (4x) Cap 17025 Thread lock (4x) Cap 2397 Thread lock Cap 3215 REAR UPPER DECK (4x) Cap 17025 Thread lock Cap 3226 Cap 3228 FANS HOLDER MUST BE MOUNTED ON THE TOP...
  • Page 48 BAG 9 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 3230 Steering Servo Radioplate Cap 17040 Self-locking Nut M3 Cap 3229 ESC Radioplate Cap 17010 Grub Screw M4x4 Button Head Cap R802231 Pinion 23T Cap 17030...

  • Page 49: Steering Servo

    BAG 9 Radioplate Step 0 Cap 18169 Cap 17030 Thread lock DEFAULT SETUP Around 5.0mm Cap 40463 (2x) Cap 14043KS Cap 17030 Thread lock STEERING SERVO STEERING SERVO LEVER (NOT (NOT INCLUDED) INCLUDED) (3x) Cap 40115 (3x) Cap 17030 Thread lock (4x) Cap 17023 Thread lock Cap 3230...
  • Page 50 BAG 9 Radioplate Step 1 RECEIVER (NOT INCLUDED) (NOT INCLUDED) Cap 3229...

  • Page 51: Radioplate Mounting

    BAG 9 Radioplate Mounting RADIOPLATE (2x) Cap 17040 (3x) Cap 17031 Thread lock (2x) Cap 22015 (2x) Cap 17027...
  • Page 52 BAG 9 Motor Mounting MOTOR (NOT INCLUDED) R802231 Cap 17010 Thread lock (2x) Cap 18024 Thread lock...
  • Page 53 BAG 10 Parts included in the bag Part Code Part Name & Picture Part Code Part Name & Picture Cap 2458-GT Bumper Cap 3152 Rear Body Mount Cap 3238 Bumper Foam Cap 3151 Rear Body Bracket Cap 3237 Bumper Foam Plate Cap 22021 Shim 3x6x1.0 Cap 3239...
  • Page 54 BAG 10 Parts included in the bag Part Code Part Name & Picture Button Head Cap Cap 17023 Screw M3x10 Button Head Cap Cap 17012 Screw M3x12 Button Head Cap Cap 17120 Screw M3x20 Button Head Cap Cap 17140 Screw M3x25 Button Head Cap Cap 17034 Screw Flange M3x8...

  • Page 55: Front Shock Absorber

    BAG 10 Front Shock Absorbers BUILD Mounting Cap 17034 Thread lock FRONT SHOCK DEFAULT SHOCK ABSORBER ABSORBER POSITION Cap 22021 Cap 17012...
  • Page 56 BAG 10 Rear Shock Absorbers BUILD Mounting Cap 17034 Thread lock REAR SHOCK Cap 22015 ABSORBER Cap 17012...
  • Page 57 BAG 10 Bumper Cap 3239 (2x) Cap 3244 (2x) Cap 3155 (2x) Cap 17139 (2x) Cap 3236 Cap 3237 Cap 3238 (3x) Cap 2112 Cap 2458-GT (2x) Cap 2397...
  • Page 58 BAG 10 Bumper Mounting Cap 3155 Cap 17139 Cap 3153 Cap 17032 Cap 3235 Cap 2146 Thread lock BUMPER Cap 2146 Thread lock (3x) Cap 2145...
  • Page 59 Rear Differential Cover BAG 10 These parts are optionals non included Cap 17040 Cap 17031 Cap 3159K (2x) Cap 17032 Thread lock...
  • Page 60 BAG 10 Rear Body Holder (2x) Cap 3155 (2x) Cap 17030 (2x) Cap 3153 Cap 3152 (2x) Cap 17139 (4x) Cap 17040 (2x) Cap 17140 (2x) Cap 3151...
  • Page 61 BAG 10 Rear Body Holder Mounting REAR BODY HOLDER (2x) Cap 17120 (2x) Cap 17023 Remove temporarily the rear upper arm to insert the nut in (2x) Cap 17040 its seat...
