User and Programming Manual

This document is intended for installers, set-up technicians and

IT professionals of the WaveLinx system

Engage appropriate network security professionals to ensure all lighting control system hardware and servers

are secure for access.

Ensure IT professionals review the WaveLinx network architecture document found at www.cooperlighting.com.

Network security is an important issue. Typically, the IT organization must approve configurations that expose

networks to the Internet. Be sure to fully read and understand customer IT Compliance documentation.

DISCLAIMER OF LIABILITY: Cooper Lighting Solutions assumes no liability for damages or losses of any kind

that may arise from the improper, careless, or negligent installation, handling or use of the products.

IMPORTANT: This manual provides information on the installation and operation of WaveLinx system. For proper operation it is

important to follow the installation instructions for each product/component.

ATTENTION

WaveLinx

Advertisement

Need help?

Need help?

Do you have a question about the WaveLinx and is the answer not in the manual?

Questions and answers

Summary of Contents for Cooper Lighting WaveLinx

Page 1 IMPORTANT: This manual provides information on the installation and operation of WaveLinx system. For proper operation it is important to follow the installation instructions for each product/component.
Page 2 WaveLinx PRO Universal Voltage Dimming Switchpack Reference Sheet ..................65 WaveLinx PRO Emergency Dimming Switchpack Reference Sheet ....................67 WaveLinx PRO Universal Voltage Dimming Switchpack with Dry Contact Input Reference Sheet ..........69 WaveLinx PRO Receptacle Reference Sheet ........................... 72 WaveLinx PRO Ceiling Sensor Reference Sheet ..........................
Page 3 Part 1: Verify WaveLinx PRO and LV Devices are Ready for Pairing ....................137 Part 2: Pair WaveLinx PRO and LV Devices with a WaveLinx Area Controller (Construction Grouping) ........137 Operation of Devices within the Construction Area ........................140 Discover the WaveLinx CAT Area Hub and Add CAT Devices ......................
Page 4 Step 3: (Partitioned Areas Only) Assign the Partition Wall Device(s) to a Sub Area ................168 Step 4: Identify, Assign and Configure Dual Channel WaveLinx PRO Nodes or Advanced Integrated Sensors (WPA IS Pro CCT) . 169 Changing Dual Channel WaveLinx PRO Node Configuration ......................171 Using Multi-Select During Dual Channel Device Assignment ......................
Page 5 Configuring the Contact Input Actions for a WaveLinx Universal Voltage Dimming Switchpack (model WSP-CA-010) ..... 227 Configuring the Contact Input Actions for a WaveLinx PRO Contact Closure Input Module (model CCI-P-V) ......229 Configuring the Contact Input Actions for a WaveLinx CAT Contact Closure Module ..............231 Modifying Occupancy Sensor Response ..............................
Page 6 Viewing NPS and EM Device Details ..............................310 Using the WaveLinx Apps to Control Lighting ............................311 Connect the WaveLinx Mobile App to a WaveLinx Area Controller as a Personal Control User ............311 Assigning a Favorite Area..................................312 Controlling Lighting from the WaveLinx Apps ............................312 Raise and Lower the Light Level of all Controlled Zones in an Area ....................
Page 7 Details on Restoring a Backup to the Same WaveLinx Area Controller ..................341 Details on Restoring a Backup to a Different WaveLinx Area Controller (WAC Replacement) ............. 341 Viewing and Updating Firmware of the WaveLinx Area Controller and WaveLinx Devices ..............344 Obtaining the Latest Firmware/Software for the WaveLinx System ....................
Page 8 Performing Relay Functions ................................367 Performing Dimmer Functions ................................. 371 Performing Network Functions ................................ 372 Sweeping Relays ON/OFF using the WaveLinx Networked Relay Panel Controller Card Buttons ............. 376 Replacing a Relay Panel Controller ............................... 376 Reconnecting after an IP Address Change ............................377 Replacing Relays and Dimming Modules .............................
Page 9 Step 5: Logout and Close .................................. 426 Appendix B: Accessing the WaveLinx CORE through a WaveLinx Area Controller ................. 427 Step 1: If Disabled, Enable the WaveLinx Area Controller’s Wi-Fi Access Point ................. 427 Step 2: Setup Access for the WaveLinx CORE ............................428 Step 3: Access the CORE ..................................
Page 10 WaveLinx CAT WaveLinx offers wired control devices that communicate with each other over a category 5 cable using WaveLinx CAT, a proprietary digital communication. While WaveLinx CAT devices can operate on their own in a standalone room-by-room system, the WaveLinx Area Hub can be added to allow the room-by-room systems to be combined for operation in a larger WaveLinx system.
Page 11 (4) relays to sixty- four (64) relays. Relays are available in 1, 2, or 3 pole options. Optional WaveLinx Panel Dimming Modules can be added within the panel or may be remotely mounted allowing for 0-10V dimming control for up to 64 dimmer channels.
Page 12 WaveLinx User Manual (Version 16.0) WaveLinx CORE Larger spaces can be brought together for management and efficiency using WaveLinx CORE. WaveLinx CORE leverages the data generated by WaveLinx PRO sensors and connected luminaires to improve operational efficiency and optimize experiences for occupants.
Page 13 WaveLinx Mobile App. WAC Gen 1 is not supported for version 16.0 software. The WaveLinx Mobile App will allow connection to a WAC Gen 1 unit with the latest Gen 1 firmware but connects through a browser based app rather than the Mobile App screens.
Page 14 The Area Controller(s) can then be added to WaveLinx CORE. Further use of WaveLinx CORE devices and Smart Space Apps is beyond the scope of this user guide. Refer to the specific materials for these products for information.
Page 15 WaveLinx Device Reference Sheets This section contains information about each device used in the WaveLinx system. Each device will have a reference sheet describing the device and its general functionality. Additional details include specific information that will be used for reference throughout the manual. Once familiar with the general programming steps, the reference sheets can act as a quick reference guide for specific device behavior or programming details.
Page 16 WaveLinx Integrated Sensor and Tilemount Sensor assignment for open loop control is contingent on the use of WAC2 (Gen 2) minimum version 10.0.x.x and updated device firmware. Partitioning requires the use of WAC2 (Gen 2) minimum version 14.1.x.x software.
Page 17 • Select Enable Discover Devices. The blue 802.15.4 LED on the WaveLinx Area Controller and the green LAN LED will blink at a rate of one blink per second to indicate the WaveLinx Area Controller is in pairing mode. The WaveLinx Area Controller pairing mode automatically times-out after 60 minutes or can be manually exited by pressing and releasing (1 second press) the PAIR button or by disabling Device Pairing from the WaveLinx App.
Page 18 WaveLinx User Manual (Version 16.0) WaveLinx Area Controller 2 (Gen 2) continued WaveLinx Area Controller Pushbutton Functions The WaveLinx Area Controller 2 has two pushbuttons that allow for several administrative functions. These functions should be used with caution! Function Button...
Page 19 Step 1: Connect to the WaveLinx Area Controller 2 Webpage The steps in this section assume that the WaveLinx Area Controller 2 has not been connected to a building network and is still in its factory default state for wireless name and username/password.
Page 20 CONNECTIONS TO THE WI-FI ACCESS POINT ON THIS WAVELINX AREA CONTROLLER. Enter the new Network Key then select SUBMIT 8: The WaveLinx Area Controller will automatically reboot. Close the web browser window. The WAC will automatically reboot Wait until the reboot is complete. The Power/Health LED, 802.15.4 LED and Wi-Fi LED will be ON indicating it is...
Page 21 Step 2: Set the WaveLinx Area Controller Clock The WaveLinx Area Controller clock settings need to be set for the site. This includes the location, time, date, and time zone settings. These settings are found within the system webpage. In the event of a power loss, the time and date will be retained for up to 48 hours. If power is lost for longer than a 48-hour period, the settings will need to be refreshed once power is restored.
Page 22 PM). Click the time zone drop down and select the proper time zone. • Use NTP: If the WaveLinx Area Controller is connected to a building network that uses a network time protocol (NTP) server, enable the Use NTP slider and fill in the NTP server address details.
Page 23 Features WaveLinx CAT buses can operate independently or may be connected to an Area Hub to operate as part of a system. • Distributed Mode: The WaveLinx CAT devices connected to the same WaveLinx CAT bus operate together and control •...
Page 24 Main Status LED Flashes green for 1s, OFF The WaveLinx Area Hub is not connected with a WaveLinx Area Controller and does not have an IP Address for 1s. Repeats (either DHCP or Static IP) assigned. 3 minutes after power is applied, if no DHCP server is found or statically assigned IP, the default IP address will be assigned, and the LED will stop flashing.
Page 25 WaveLinx User Manual (Version 16.0) WaveLinx Area Hub continued WaveLinx Area Hub Pushbutton Functions The WaveLinx Area Hub has two pushbuttons that allow for several administrative functions. These functions should be used with caution! Function Button Press Length LED feedback...
Page 26 If not setting a static IP address or changing the default Area Hub name, no further Area Hub configuration is necessary. Follow the steps below to prepare to connect to and discover the Area Hub IP addresses, login to the Area Hub configurator, change the name of each WaveLinx Area Hub, and set a static IP address for each Area Hub Ethernet port.
Page 27 WaveLinx Area Controller’s initial configuration and join the network 3: Open the web browser and enter the Wi-Fi IP address of the WaveLinx Area Controller in the address bar. (The default Wi-Fi IP address is 192.168.100.1) Launch the web...
Page 28 Area Hub IP addresses but the WaveLinx Area Controller IP address is known, follow the steps described below to discover the Area Hubs to display the IP addresses in the WaveLinx Lighting App. The laptop being used for configuration must connect to the same network for access and the DHCP given IP address for the WaveLinx Area Controller used instead of the addresses discussed.
Page 29 WaveLinx User Manual (Version 16.0) WaveLinx Area Hub continued Step 3: (continued) 5: Wait for the search to be completed and then review the Area Hub list to determine the IP addresses. Make note of the IP addresses, matching them to the MAC Review discovered addresses noted earlier.
Page 30 LOGIN Step 5: Update the Area Hub Name (Optional) a maximum 16 alphanumeric characters (hyphen character is allowed) 1: If needed, login to the WaveLinx Area Hub Configurator webpage and select system. System 2: In the General section, select EDIT EDIT 3: Enter the new Area Hub name and select SAVE.
Page 31 WaveLinx Area Hub continued Step 6: Set a New Static IP Address for the Area Hub The WaveLinx CAT Area Hub is set to use DHCP by default. If using a DHCP server, no further IP address settings are needed.
Page 32 • 0-10V Dimmers: Networked Relay Panel is added to the WaveLinx Area Controller manually by the IP address given to the relay panel. When the panel is added, all configured relays and dimmers will be available in the WaveLinx Area Controller.
Page 33 Blink to Identify Blink to Identify is not available for relays within the relay panel. Tap on the relay in the WaveLinx App and use the App’s ON/OFF switch to manually toggle the relay state to aid in the identification of relays or use Blink to Identify with the load’s dimmer instead. Blink to Identify is available for relay panel dimmer channels. Select a device row to place the dimmer in Blink to Identify mode.
Page 34 Initial Configuration Steps for the WaveLinx Networked Relay Panel WaveLinx Networked Relay Panel continued Initial Configuration Steps Perform these steps before adding the WaveLinx Networked Relay Panel to the WaveLinx Area Controller. Use this section to: • Step 1: Verify Relay Panel Installation •...
Page 35 If the panel does not have any Dimming Modules, skip to the next step. If the WaveLinx Networked Relay Panels have panel mounted or remote mounted Dimming Modules, each Dimming Module attached to the same panel must have a unique address.
Page 36 WaveLinx User Manual (Version 16.0) WaveLinx Networked Relay Panel continued Step 4: (continued) 6: When prompted, press CONTINUE. Wait for the factory reset to complete. When prompted, tap EXIT. Step 5: Configure Relay Poles Relays are set for single pole relay configuration by default. If two or three pole relays are being used, they must be configured using the onboard display.
Page 37 The WaveLinx Networked Relay Panel communicates with the WaveLinx Area Controller over the building LAN. Before the relay panel can be added to the WaveLinx Area Controller, it must be configured with a unique IP address within the same network range as the WaveLinx Area Controller. By default, the Ethernet port on the relay panel is disabled.
Page 38 WaveLinx User Manual (Version 16.0) WaveLinx Networked Relay Panel continued Step 6: (continued) 5: From the MENU press NETWORK. 6: Press NETWORK SETTINGS. 7: Select either DHCP or STATIC mode. To use DHCP: 8: After selecting DHCP MODE, press APPLY.
Page 39 Step 7: Review the Networked Status/Note the IP Address To connect the WaveLinx Networked Relay Panel to the WaveLinx Area Controller, note the IP address of the panel. If DHCP was used, review the network status to see the assigned IP address.
Page 40 NFPA 101 Life Safety Code or other local building codes and standards. For best results, do not pair more than 140 low-voltage devices to a WaveLinx Area Controller 2 (Gen 2). Low-Voltage Fixture with Integrated Sensor: fixture + sensor = 1 device.
Page 41 WaveLinx Area Controller. Identify If pressed, the status LED will flash blue for 15 seconds. In the WaveLinx App’s Device menu, the icon for the Low-Voltage Power Module will appear to pulse, identifying the device in the WaveLinx App. Test Press and release to place the Low-Voltage Power Module into test mode.
Page 42 WaveLinx Low-Voltage Power Module is set to obtain an IP address automatically using DHCP. Alternatively, the IP address can be statically assigned. IMPORTANT NOTE: If using DHCP to assign the IP address, reserve the IP on the DHCP server. If the IP addresses of the WaveLinx Area Controller or WaveLinx Low- Voltage Power Module changes after the devices are paired, they will lose communication and the Low-Voltage Lighting will be offline until the connection is repaired (see “Reconnecting after IP Address Changes”...
Page 43 Enter Low-Voltage Power Module IP Address 2: Open a web browser. In the address bar, enter the IP address of the WaveLinx Low-Voltage Power Module (default 192.168.1.254). The browser may display a warning regarding site security. The display and wording of this message may differ. Locate the option Bypass security warning to bypass the warning and proceed to the site.
Page 44 Mobile App 7: Click on Save. The WaveLinx Low-Voltage Power Module will automatically reboot if the IP address settings other than the WAC IP Address have been changed. If the web browser has been left open, it will be disconnected. A Low-Voltage Power Module reboot takes approximately 1 ½ minutes to complete.
Page 45 The touchscreen automatically populates the screens based on the programming in the WaveLinx Area Controller. Partitioned area control is limited to the scenes and zones of the combined area. Sub area and sub zone control is not currently available.
Page 46 WaveLinx PRO Ambient Integrated Sensor The WaveLinx PRO Ambient Integrated Sensor provides wireless control within the light fixture to reduce wiring, design, and installation time. The sensor provides both occupancy and daylight control that can be easily configured using the WaveLinx App.
Page 47 Standing beneath the sensor, point the remote at the sensor, and then press and release the designated button. If the sensor has been paired with a WaveLinx Area Controller, this will trigger identification mode for that device. The sensor LED will briefly flash blue and then will flash magenta for 15 seconds as the device will appear to flash on the WaveLinx Mobile App screen.
Page 48 This removes pairing for ALL devices of this type on the circuit. After a brief period, the device should exhibit out-of-the-box behavior and may be paired as a new device. The ACC-P-RT IR Remote may also be used to factory reset devices. Please refer to the WaveLinx PRO IR Remote User Guide for details on using the IR factory reset command.
Page 49 RTLS capability may require additional license or firmware purchase. WIK & WIM WaveLinx Lite sensor models may be updated through firmware to allow operate with a standard WaveLinx PRO system. Older firmware devices may go to 75% output when occupied out-of-the-box, take up to 1 hour and flash the LED green 100ms, once every 3 seconds to indicate entering loss of communication operation.
Page 50 3-4 seconds. The timing needs to be precise for the identification mode to respond. The LED in the sensor window will flash magenta for 15 seconds as the device will appear to flash on the WaveLinx Mobile App screen.
Page 51 This removes pairing for ALL devices of this type on the circuit. After a brief period, the device should exhibit out-of-the-box behavior and may be paired as a new device. The ACC-P-RT IR Remote may also be used to factory reset devices. Please refer to the WaveLinx PRO IR Remote User Guide for details on using the IR factory reset command.
Page 52 RTLS capability may require additional license or firmware purchase. WOB & WOF WaveLinx Lite sensor models may be updated through firmware to allow operate with a standard WaveLinx PRO system. Older firmware devices may go to 75% output when occupied out-of-the-box, take up to 1 hour and flash the LED green 100ms, once every 3 seconds to indicate entering loss of communication operation.
Page 53 3-4 seconds. The timing needs to be precise for the identification mode to respond. The LED in the sensor window will flash magenta for 15 seconds as the device will appear to flash on the WaveLinx Mobile App screen.
Page 54 Operation upon Return of Power Upon return of power, the fixture will resume its last known light level. If not able to communicate with the WaveLinx Area Controller for more than approx. 15 minutes, loss of communications operation will begin.
Page 55 WaveLinx PRO Outdoor Sensor Extender/Multiplier The WaveLinx PRO Outdoor Sensor Extender/Multiplier can be used to extend WaveLinx wireless signal outdoors or to add WaveLinx control from motion and daylight switching to non-WaveLinx luminaires. The device mounts to a pole or wall mounted junction box, allowing it to be located wherever it is necessary.
Page 56 3-4 seconds. The timing needs to be precise for the identification mode to respond. The LED in the sensor window will flash magenta for 15 seconds as the device will appear to flash on the WaveLinx Mobile App screen.
Page 57 This removes pairing for ALL devices of this type on the circuit. After a brief period, the device should exhibit out-of-the-box behavior and may be paired as a new device. The ACC-P-RT IR Remote may also be used to factory reset devices. Please refer to the WaveLinx PRO IR Remote User Guide for details on using the IR factory reset command.
Page 58 WaveLinx PRO Tilemount Sensor Reference Sheet WaveLinx PRO Tilemount Sensor When connected to a WaveLinx PRO Tilemount Sensor Control Module the WaveLinx PRO Tilemount Sensor provides occupancy sensing, daylight dimming and wireless control for connected 0-10V luminaires that do not support WaveLinx Integrated Sensors.
Page 59 3-4 seconds. The timing needs to be precise for the identification mode to respond. The LED in the sensor window will flash magenta for 15 seconds as the device will appear to flash on the WaveLinx Mobile App screen.
Page 60 This removes pairing for ALL devices of this type on the circuit. After a brief period, the device should exhibit out-of-the-box behavior and may be paired as a new device. The ACC-P-RT IR Remote may also be used to factory reset devices. Please refer to the WaveLinx PRO IR Remote User Guide for details on using the IR factory reset command.
Page 61 See next recommendation). • To verify pairing, make sure to EXIT the WaveLinx Area Controller pairing mode. Then, place the WaveLinx Area Controller back in pairing mode. All Outdoor Lighting Control Modules paired with the WaveLinx Area Controller will dim to 10%.
Page 62 WaveLinx PRO Outdoor Lighting Control Module continued Loss of Communications Operation If the device has not communicated with the WaveLinx Area Controller for longer than approx.15 minutes, it will revert to its out-of-the-box behavior until communications are re-established. Operation upon Return of Power Upon return of power, the fixture will turn ON to 100% until communications are re-established with the WaveLinx Area Controller after which the lighting state is re-evaluated.
Page 63 • 1 white tuning The WaveLinx PRO Node Single Channel device can be changed from dimming to white tuning control. In this rare application, the single channel adapter will show a CCT icon instead of the dimmable load icon shown and will display white tuning configuration screens.
Page 64 • Create the white tuning zone(s) needed for the area. (p. 153) • Identify each dual channel WaveLinx PRO Node and when adding them, select the dimming zone for the intensity channel and the white tuning zone for the white tuning channel.
Page 65 LED will blink for 10 seconds to indicate the device has entered pairing mode. The device will stay in pairing mode for 60 minutes and then time out automatically if a connection with WaveLinx Area Controller is not made. Only unpaired devices will enter pairing mode with these methods.
Page 66 Operation upon Return of Power Upon return of power, the device will resume its last known light level. If not able to communicate with the WaveLinx Area Controller for more than approx. 15 minutes, loss of communications operation will begin.
Page 67 LED will blink for 10 seconds to indicate the device has entered pairing mode. The device will stay in pairing mode for 60 minutes and then time out automatically if a connection with WaveLinx Area Controller is not made. Only unpaired devices will enter pairing mode with these methods.
Page 68 Emergency Mode Operation NOTE: For proper operation, use the WaveLinx App to configure an Emergency Set that has at least one Normal Power Sense device (NPS device) assigned to generate the beacon signal that the WaveLinx PRO Emergency Dimming Switchpack(s) requires. Up to three WaveLinx PRO devices can be assigned as NPS devices to generate the beacon signal to the defined Emergency Set.
Page 69 WaveLinx PRO Universal Voltage Dimming Switchpack with Dry Contact Input Use the WaveLinx PRO Universal Voltage Dimming Switchpack with Dry Contact Input to wirelessly control a zone of switched loads or 0-10V dimmable lighting loads. It can also be used to connect an external maintained dry-contact closure or to Greengate low-voltage occupancy sensor(s) (max.
Page 70 Greengate sensors not approved for use with WaveLinx or not directly connected for power from the WaveLinx Universal Voltage Dimming Switchpack may not exhibit the described behavior. Wall Status Toggle will only show in WAC2 (Gen 2) version 14.1.x.x firmware and higher. This option is for use with Partitioned Areas.
Page 71 WaveLinx User Manual (Version 16.0) WaveLinx PRO Universal Dimming Switchpack with Dry Contact Input continued Contact Closure Details The WSP-CA-010 model WaveLinx Universal Voltage Dimming Switchpacks supports connection to an external contact closure or a Greengate Occupancy Sensor. Contact Closure Input...
Page 72 WaveLinx PRO Receptacle Reference Sheet WaveLinx PRO Receptacle The WaveLinx PRO Receptacle enables energy savings by turning OFF the top outlet when the area is unoccupied or with other programmed actions, simplifying plug load control requirements. The bottom outlet remains constantly powered.
Page 73 Loss of Communications Operation If communication is lost with WaveLinx Area Controller, the controlled outlet will remain in the last commanded state. The manual pushbutton may be used to toggle the controlled outlet ON and OFF until communications are re-established.
Page 74 If paired, the device will be visible in the WaveLinx App. The LED may flash slowly two times (3 seconds ON, 3 seconds OFF) as the device pairs with the WaveLinx Area Controller. Motion activity may also trigger PAIR mode although this method is not reliable.
Page 75 In the daylight set’s Calibrate screen, adjust the slider bar to change the light level to the desired light level, then tap the back button to save the change. Loss of Communications Operation Not applicable for this device type. If communication is lost with WaveLinx Area Controller, the sensor will not control the assigned loads until communications are re- established.
Page 76 Wall Status Toggle will only show in WAC2 (Gen 2) version 14.1.x.x firmware and higher. This option is for use with Partitioned Areas. Network Action will only show in WAC2 (Gen 2) version 10.0.x.x firmware and higher. WAC must be a configured part of a WaveLinx CORE platform to perform supported network actions. When programmed for this action type, the button LED will not change when the button is used.
Page 77 If a button with an LED indicator is pressed, the LED will flash quickly for 5 seconds to indicate its offline status. Operation upon Return of Power Upon return of power and connection to the WaveLinx Area Controller, the wallstation will wait for a button press before issuing commands. Factory Reset Instructions CAUTION: The factory reset will set the device back to factory settings (out-of-the-box behavior) removing pairing and programmed settings.
Page 78 Wall Status Toggle will only show in WAC2 (Gen 2) version 14.1.x.x firmware and higher. This option is for use with Partitioned Areas. Network Action will only show in WAC2 (Gen 2) version 10.0.x.x firmware and higher. WAC must be a configured part of a WaveLinx CORE platform to perform supported network actions.
Page 79 Operation upon Return of Power Upon return of power and connection to the WaveLinx Area Controller, the wallstation will wait for a button press before issuing commands. The LED behavior will resume its normal operation based on the wallstation’s paired or unpaired state, and, if paired, the area it has been assigned to (Construction Area or a created area).
Page 80 Wall Status Toggle will only show in WAC2 (Gen 2) version 14.1.x.x firmware and higher. This option is for use with Partitioned Areas. Network Action will only show in WAC2 (Gen 2) version 10.0.x.x firmware and higher. WAC must be a configured part of a WaveLinx CORE platform to perform supported network actions.
Page 81 If communication is lost with WaveLinx Area Controller, the wallstation will not control the assigned loads until communications are re-established. The red LED below the bottom button may illuminate for about 3 seconds if a button is pressed as the station tries to communicate with the WaveLinx Area Controller.
Page 82 Wall Status Toggle will only show in WAC2 (Gen 2) version 14.1.x.x firmware and higher. This option is for use with Partitioned Areas. Network Action will only show in WAC2 (Gen 2) version 10.0.x.x firmware and higher. WAC must be a configured part of a WaveLinx CORE platform to perform supported network actions.
Page 83 Press any button on the wallstation to verify pairing. If the wallstation is paired, the wallstation LED should blink white and then flash magenta for approximately 15 seconds to indicate that the wallstation is paired and is assigned to the Construction Area. Any WaveLinx lighting devices or receptacles paired and in the Construction Area will respond to the button command.
Page 84 Momentary contact closures can be used for limited scene and zone function commands. • Sensor Input Mode: Use this mode to allow one external occupancy sensor to be used in a WaveLinx Occupancy Set. The sensor or sensor’s switchpack must connect using the sensor or switchpack’s Form C relay (BAS signal contact).
Page 85 Contact Closure Terminology • Alert Mode: Alert Mode is a high priority command that triggers all dimmable, non-dimmable, and receptacle zones in the WaveLinx Area Controller to go to 100% and prevents operation of lighting from other devices until Alert Mode is deactivated. Once the Alert Mode contact is cancelled, lighting will blink one time to warn that lighting is being released to normal operation in 5 minutes.
Page 86 WaveLinx User Manual (Version 16.0) WaveLinx PRO Contact Closure Input Module continued Pushbutton Contact Closure Input Module Pushbutton Functions The WaveLinx PRO Contact Closure Input Module has a pushbutton that allows for device reset. Function Press Length LED feedback Device outcome...
Page 87 Refer to the device reference sheet to determine if the device supports the use of the ACC-P-RT IR Remote. WaveLinx PRO IR Remote Overview For further details, please refer to the WaveLinx PRO IR Remote User Guide for a list of supported devices and specific instructions on using the remote.
Page 88 The reset button has been pressed for less than 1 second or greater than 10 press seconds. No reset occurs. While in Distributed Mode, device programming can be changed from defaults to other behavior using the WaveLinx CAT Bluetooth Programming Interface Module and the WaveLinx CAT Mobile App. www.cooperlighting.com...
Page 89 Operation upon Return of Power Upon return of power, the device will resume its last known light level and operate in Distributed Mode until the Area Hub communications with the WaveLinx Area Controller are restored. Once communicating with the WaveLinx Area Controller, the device will begin normal operation in Networked Mode.
Page 90 The reset button has been pressed for less than 1 second or greater than 10 press seconds. No reset occurs. While in Distributed Mode, device programming can be changed from defaults to other behavior using the WaveLinx CAT Bluetooth Programming Interface Module and the WaveLinx CAT Mobile App. www.cooperlighting.com...
Page 91 If the WaveLinx CAT Emergency Dimming Switchpack loses power, once power returns it will turn ON/100% in Emergency Mode until it receives its assigned NPS device signal to revert to normal operation. It will also look to the restoration of the Area Hub communications with the WaveLinx Area Controller to begin normal operation in Networked Mode.
Page 92 The reset button has been pressed for less than 1 second or greater than 10 press seconds. No reset occurs. While in Distributed Mode, device programming can be changed from defaults to other behavior using the WaveLinx CAT Bluetooth Programming Interface Module and the WaveLinx CAT Mobile App. www.cooperlighting.com...
Page 93 Factory Reset Instructions Although the device contains an onboard button for factory reset, if the device is connected to a WaveLinx Area Hub/WaveLinx Area Controller, the device will continue to operate with the programming in the WaveLinx Area Controller after the factory reset is performed.
Page 94 The reset button has been pressed for less than 1 second or greater than 10 seconds. No reset occurs. While in Distributed Mode, device programming can be changed from defaults to other behavior using the WaveLinx CAT Bluetooth Programming Interface Module and the WaveLinx CAT Mobile App. www.cooperlighting.com...
Page 95 Factory Reset Instructions Although the device contains an onboard button for factory reset, if the device is connected to a WaveLinx Area Hub/WaveLinx Area Controller, the device will continue to operate with the programming in the WaveLinx Area Controller after the factory reset is performed.
Page 96 Wall Status Toggle will only show in WAC2 (Gen 2) version 14.1.x.x firmware and higher. This option is for use with Partitioned Areas. Network Action will only show in WAC2 (Gen 2) version 10.0.x.x firmware and higher. WAC must be a configured part of a WaveLinx CORE platform to perform supported network actions.
Page 97 Factory Reset Instructions Although the device contains an onboard button for factory reset, if the device is connected to a WaveLinx Area Hub/WaveLinx Area Controller, the device will continue to operate with the programming in the WaveLinx Area Controller after the factory reset is performed.
Page 98 Scene and Zone Toggle functions will only be available for momentary device types. While in Distributed Mode, device programming can be changed from defaults to other behavior using the WaveLinx CAT Bluetooth Programming Interface Module and the WaveLinx CAT Mobile App.
Page 99 Factory Reset Instructions Although the device contains an onboard button for factory reset, if the device is connected to a WaveLinx Area Hub/WaveLinx Area Controller, the device will continue to operate with the programming in the WaveLinx Area Controller after the factory reset is performed.
Page 100 The reset button has been pressed for less than 1 second or greater than 10 press seconds. No reset occurs. While in Distributed Mode, device programming can be changed from defaults to other behavior using the WaveLinx CAT Bluetooth Programming Interface Module and the WaveLinx CAT Mobile App. www.cooperlighting.com...
Page 101 Factory Reset Instructions Although the device contains an onboard button for factory reset, if the device is connected to a WaveLinx Area Hub/WaveLinx Area Controller, the device will continue to operate with the programming in the WaveLinx Area Controller after the factory reset is performed.
Page 102 The Low-Voltage Fixture with Integrated Sensor will automatically pair when its WaveLinx Low-Voltage Power Module is paired with the WaveLinx Area Controller. If a Low-Voltage device is attached after the initial pairing was completed (always power down before the connection) or a Low-Voltage device is deleted in error from the WaveLinx App, manually refresh the pairing.
Page 103 To factory reset a single Low-Voltage Fixture with Integrated Sensor, use the WaveLinx App to delete the device from the app. The device should then display out-of-the- box behavior and may be paired as a new device. Note: All devices connected to the same Low-Voltage Power Module must be paired with the same WaveLinx Area Controller.
Page 104 Factory Reset Instructions To factory reset a single Low-Voltage Fixture, use the WaveLinx App to delete the device from the app. The device should then display out-of-the-box behavior and may be paired as a new device. Note: All devices connected to the same Low-Voltage Power Module must be paired with the same WaveLinx Area Controller.
Page 105 Refer to the device reference sheet to determine if the device supports the use of the ISHH-01. Only the power button on the ISHH-01 remote will be used in the WaveLinx system. • If a supported device is not paired with a WaveLinx Area Controller, press to place the device into pairing mode.
Page 106 WaveLinx User Manual (Version 16.0) WaveLinx Device Archive This section contains information for products that are no longer sold. These devices may be unsupported in the version 16.0 architecture or may not support all the features. www.cooperlighting.com...
Page 107 • Select Enable Discover Devices. The blue 802.15.4 LED on the WaveLinx Area Controller will blink at a rate of one blink per second to indicate the WaveLinx Area Controller is in pairing mode.
Page 108 The WaveLinx Area Controller may be running a firmware update, may be running firmware updates on connected devices, or may be processing a factory reset. WAN LED Normal condition in stand-alone use. If used in a WaveLinx CORE system, the WAC has lost its connection to WaveLinx CORE. Solid GREEN The WaveLinx Area Controller is connected to a WaveLinx CORE, OpenADR or a Third-Party system.
Page 109 • Clearing programming including area and zone designations • Resetting WAC name to default The WaveLinx Area Controller Reset button issues a soft reset to the WaveLinx Area Controller. A soft reset will not impact the WaveLinx Area Controller’s settings. www.cooperlighting.com...
Page 110 Step 1: Connect to the WaveLinx Area Controller Webpage The steps in this section assume that the WaveLinx Area Controller has not been connected to a building network and is still in its factory default state for wireless name and username/password. If the WaveLinx Area Controller is connected to the building network, or the wireless name and password has been changed from the default, please refer to the network administrator for access information.
Page 111 Step 2: Set the WaveLinx Area Controller Clock The WaveLinx Area Controller clock settings need to be set for the site. This includes the location, time, date, and time zone settings. These settings are found within the system webpage. In the event of a power loss, the time and date will be retained for up to 48 hours. If power is lost for longer than a 48-hour period, the settings will need to be refreshed once power is restored.
Page 112 PM). Click the time zone drop down and select the proper time zone. • Use NTP: If the WaveLinx Area Controller is connected to a building network that uses a network time protocol (NTP) server, enable the Use NTP slider and fill in the NTP server address details.
Page 113 LED will blink for 10 seconds to indicate the device has entered pairing mode. The device will stay in pairing mode for 60 minutes and then time out automatically if a connection with WaveLinx Area Controller is not made. Only unpaired devices will enter pairing mode with these methods.
Page 114 • The WSP-UV-010-EM MUST be wired to an emergency circuit • The paired WaveLinx Area Controller MUST be powered from a normal circuit. Do not place the WaveLinx Area Controller on a UPS backup or other emergency backup power supply.
Page 115 Operation upon Return of Power Upon return of power, the fixture will resume its last known light level. If not able to communicate with the WaveLinx Area Controller for more than approx. 15 minutes, loss of communications operation will begin.
Page 116 WaveLinx PRO, WaveLinx CAT, and WaveLinx LV devices. This section discusses the basics of preparing to use either the WaveLinx Mobile App or the WaveLinx WAC Lighting App to administer the WaveLinx system.
Page 117 3: Enter a valid email address, select options for electronic messages, and enter the desired password (This password is for the MyApps Account and is different from the password assigned to a WaveLinx Area Controller). Tap CONTINUE. Enter a valid email...
Page 118 2: The first time the app opens, grant permission to allow network access and notifications to ensure that the app functions properly. 3: The application is now logged in and ready for use with the WaveLinx system with the List of Controllers screen displayed. The app will remain logged in, even if closed, unless the user logs out of the application.
Page 119 Menu options Menu options The List of Controllers is used to open a WaveLinx Area Controller for programming. Multiple WaveLinx Area Controllers may appear if the site has multiple connected to same network that the mobile device is accessing. To display the programming for the WaveLinx Area Controller, tap on the WaveLinx Area Controller in the list and then enter the login credentials.
Page 120 Entering Demonstration Mode To place the WaveLinx Mobile App in Demonstration Mode: 1: Open the Mobile App but do not login to a WaveLinx Area Controller (If already logged in to a WaveLinx Area Controller, tap the menu and select WAC Logout).
Page 121 Login as the administrator Username: WclAdmin Password: wclAdmin The demo may require changing the default WaveLinx Area Controller password. Once the password is changed, login with the new credentials to open the database and begin configuring the demonstration site. Resetting the Demonstration Database After using the demonstration mode, if demo devices have been reorganized, reprogrammed, or deleted, they can be restored by resetting the demonstration database.
Page 122 1: If in the demo and logged into a WaveLinx Area Controller, select EXIT DEMO. Select EXIT DEMO 1: Open the Mobile App but do not login to a WaveLinx Area Controller (If already logged in to a WaveLinx Area Controller, tap menu and select WAC Logout).
Page 123 3: Tap on the WaveLinx icon to launch the Mobile App. 4: Once the app opens, the WaveLinx Area Controller should display. Tap on the WaveLinx Area Controller to open the connection. Depending on the controller version, follow the appropriate steps listed below.
Page 124 WAC Gen 2 Version 14.1.x.x and Lower For a WAC Gen 2 model with 14.1.x.x or lower versions software, the WaveLinx Mobile App will display a warning indicating that there is a version incompatibility and that the WAC should be updated.
Page 125 Make necessary changes Note: The Mobile App will not be the active app displayed when logging out of a browser connected WaveLinx WAC. Tap on the WaveLinx Mobile App to access additional WaveLinx Area Controllers. Verifying Mobile App Connection Reliability: Real-time Data Unavailable Before proceeding on, ensure that the Mobile App has a reliable communications connection.
Page 126 WaveLinx User Manual (Version 16.0) If the communication signal between the Mobile App and the WaveLinx Area Controller becomes unreliable, the Mobile App will display a special icon over the menu icon and the message Realtime data unavailable at the bottom of the menu. Although real-time data is affected, commands and programming changes may continue to process properly.
Page 127 Logout of the Mobile App Once logged in to the Mobile App, it is not necessary to log out. The WaveLinx Mobile App can be used without need of an external internet connection if the user account remains logged in.
Page 128 Before logging in to the WAC WaveLinx Web App, perform the initial setup of the WaveLinx Area Controller recommended in “Initial Configuration Steps for the WaveLinx Area Controller 2 (Gen 2)” on page 19. Once these steps are completed, the WAC Lighting App is ready for use.
Page 129 WaveLinx User Manual (Version 16.0) 4: Open the web browser and enter the IP address of the WaveLinx Area Controller in the address bar. (The default IP address if connecting through the onboard wireless access point is 192.168.100.1.) The first time the WaveLinx Area Controller is accessed, the browser may display message windows regarding the site security certificate.
Page 130 Select LOGIN 8: The WAC Lighting App will allow administration and programming of the devices that are paired with this WaveLinx Area Controller. When logging in, if the message WAC CENTRALIZED displays, the WaveLinx Area Controller has been added to WaveLinx CORE for administration.
Page 131 WaveLinx User Manual (Version 16.0) Close and Logout of the WaveLinx WAC Lighting App To logout and close out of the WaveLinx WAC Lighting App follow the instructions below: 1: In the top right of the Lighting App page, click on the App icon and then select Admin from the drop down.
Page 132 This feature requires the use of a WAC2 (Gen 2) WaveLinx Area Controller with the minimum software version 11.x.x.x. The use of partitioned areas requires the use of a WAC2 (Gen 2) WaveLinx Area Controller with the minimum software version 14.1.x.x.
Page 133 • In a partitioned area, a zone that is shared between multiple spaces will be split into sub zones to allow for independent operation when the partition walls are closed. The WaveLinx App creates at least one dimmable zone by default for each area. Additional zones may be added manually as needed. The type of zone is indicated by each zone’s icon.
Page 134 A Device is a WaveLinx PRO, LV, and CAT component that can be controlled and configured for control by the WaveLinx Area Controller. A Device may also be a relay or dimmer channel from a WaveLinx Networked Relay Panel. Devices will be assigned to areas. It is possible to use a mixture of device families within the same area if the application calls for it.
Page 135 Notifications may be issued with new releases or other Cooper Lighting Solutions communications. If app notifications are allowed, notifications will display on the mobile device. New notification alerts will also be indicated by a symbol over the WaveLinx App icon and the app menu.
Page 136 Using the Schedule Screen The schedule screen will display the scheduled events in this WaveLinx Area Controller. An active event will display in blue while inactive events display in gray. Tap an event to review the event details. For more information on using schedule events, see “Adding Schedules to the Control Strategy”...
Page 137 1: On the site floorplan, locate the WaveLinx Area Controller and identify each WaveLinx PRO and LV device that should be paired with it. Sites designed to use multiple WaveLinx Area Controllers should identify the devices that belong to each controller so that they can be correctly paired with the appropriate WaveLinx Area Controller according to the design plan.
Page 138 1: On the site floorplan, locate the WaveLinx Area Controller and identify each WaveLinx PRO and LV device that should be paired with it. The WaveLinx App can also be used to place a WaveLinx Area Controller into pairing mode or to exit pairing mode if the WaveLinx Area Controller is not in an easily accessible location.
Page 139 2: Launch the WaveLinx Mobile App or WaveLinx WAC Lighting App • To use the Mobile App, open the app and login to the WaveLinx Area Controller as the administrator. See “Login to the WaveLinx Mobile App” on page 118 for login details.
Page 140 ON until no occupancy is detected throughout the entire area. Once occupancy ceases, after 20 minutes, controlled loads will turn OFF. The WaveLinx App can also be used to place a WaveLinx Area Controller into pairing mode or to exit pairing mode if the WaveLinx Area Controller is not in an easily accessible location. www.cooperlighting.com...
Page 141 Part 1: Perform the Initial Configuration Steps for WaveLinx with CAT Devices Steps in this section will refer to the WaveLinx Device Reference Sheets or other manual sections. Refer to the reference sheets for the devices being used on the site as well as the other manual sections.
Page 142 Part 3: Discover the WaveLinx CAT Area Hub and Add CAT Devices To be able to modify settings of the WaveLinx CAT Devices in the WaveLinx Mobile App or WaveLinx WAC Lighting App, the Area Hub must first be discovered and then the devices added. This process is done using Ethernet communications. Ensure that the Area Hub and WaveLinx Area Controller can be accessed in the same IP Subnet.
Page 143 WaveLinx User Manual (Version 16.0) 5: Wait for the search to be completed (may take several minutes) and then review that the active ports and device quantities are accurate. Tap ADD TO WAC. Wait for search to complete Verify accuracy of...
Page 144 Skip this section. If WaveLinx CAT devices need to be reassigned to an area other than the port area they are assigned to, they can be moved from the port area to the Construction Area where they can be assigned like any other WaveLinx device.
Page 145 Repeat this process for other WaveLinx CAT areas and devices as needed. View the WaveLinx CAT Areas and Devices To view the automatically created Area Hub port areas and WaveLinx CAT devices: 1: Open the WaveLinx Mobile App and Login to the WaveLinx Area Controller.
Page 146 Area Hub port will be assigned to that port’s area. • If WaveLinx CAT devices have not been programmed and are still in their factory default state when the Area Hub is connected the WAC, the expected operation is: •...
Page 147 4: Ensure that the WaveLinx Networked Relay Panel is powered and connected to the Ethernet. 5: Make sure to note the IP address for each WaveLinx Networked Relay Panel. This will be needed when adding the panel to the WaveLinx Area Controller.
Page 148 Part 3: Add the WaveLinx Networked Relay Panel To be able to modify the settings of the Networked Relay Panel’s relays and optional 0-10V dimmer channels in the WaveLinx Mobile App or WaveLinx WAC Lighting App, the WaveLinx Networked Relay Panel must be added to the WAC. This process is done using IP based Ethernet communications.
Page 149 WaveLinx User Manual (Version 16.0) 4: Enter the IP Address that has been assigned to the WaveLinx Networked Relay Panel and tap ADD. 5: Wait for the panel import to complete. Enter Panel’s IP Address Tap ADD Panel added Repeat these steps to add additional Relay Panels to the WaveLinx Area Controller (maximum of 400 devices).
Page 150 Operation of WaveLinx Networked Relay Panel Devices within the Construction Area As part of the construction area, WaveLinx Networked Relay Panels will operate with basic default operation. For details on a specific device’s expected behavior, refer to the device reference sheet for that device. Note that WaveLinx Networked Relay Panels rely on WaveLinx PRO or WaveLinx CAT devices to operate the relays and dimmers as there are no input devices connected to a relay panel.
Page 151 To open the WaveLinx Mobile App or the WaveLinx WAC Lighting App: 1: If the WaveLinx Mobile App was not used to add the WaveLinx devices, make sure to perform the initial setup of the WaveLinx Area Controller recommended in “Initial Configuration Steps for the WaveLinx Area Controller 2 (Gen 2)” on page 19.
Page 152 This step will walk through the process of creating the standard areas. 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the Areas option, tap + to create a new area. Areas...
Page 153 WaveLinx PRO Node channel, or to a Universal Voltage Dimming Switchpack should be placed in a white tuning control zone. 2: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the All Areas list, tap the area name.
Page 154 WaveLinx User Manual (Version 16.0) Once the zone is created, the new zone should appear in the area’s zone list. Tablet or Phone Landscape View/WAC Lighting App View Phone Portrait View New Zone(s) New Zone(s) 5: Repeat to add additional zones as needed.
Page 155 WaveLinx User Manual (Version 16.0) Step 3: Create Additional Standard Areas/Use the Copy Area Function Repeat steps 1 and 2 in this section to create additional standard areas OR use the Copy Area function. For sites that have multiple rooms with the same lighting layout and zones, one area can be copied to act as a template for other areas being created.
Page 156 3: Repeat these steps until all standard areas are created in the WaveLinx Area Controller. Once the new area is created, assign the devices to the new area see “Organizing WaveLinx Devices into Areas and Zones” on page 164. Part 3: Create Partitioned Areas and Assign Zones An Area can be either a standard area or a partitioned area.
Page 157 • A wallstation button from any WaveLinx PRO or WaveLinx CAT wallstation • A contact closure into a compatible WaveLinx device such as the WaveLinx PRO Universal Voltage Dimming Switchpack with Dry Contact Input (WSP-CA-010), the WaveLinx PRO Contact Closure Input Module (CCI-P-V), or the WaveLinx CAT Contact Closure Input Module (CCI-C-V) •...
Page 158 Wall 10 none 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the Areas option, tap + to create a new area. Areas Tap the plus icon to create a new area...
Page 159 WaveLinx User Manual (Version 16.0) 2: Enter a descriptive name for the partitioned area and then select the Partitioned Area Type. 3: Enter the number of partition walls and number of sub areas in the partitioned area and then select any additional necessary options “Understanding and Modifying Area Settings”...
Page 160 WaveLinx User Manual (Version 16.0) 6: Perform the Device Configuration to select the input that will indicate that each wall is open or closed. Tap a wall. Compatible input devices will be displayed in the Select Device(s) list. Once the correct device is located, check the input that will be associated with this wall.
Page 161 2: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the All Areas list, tap the partitioned area name.
Page 162 WaveLinx User Manual (Version 16.0) 5: Assign the Zone to the Sub Areas (sub zone) that will have devices operating in it. Tap Select All or individually select the sub areas if the zone will not be used in some sub areas. For instance, if each sub area contains general lighting fixtures that will need to operate together when the room is joined, use Select All to assign the sub zone.
Page 163 Step 4: Create an Additional Partitioned Area/Use the Copy Area Function The WaveLinx Area Controller allows up to two (2) partitioned areas. Repeat steps 1 through 3 in this section to create one additional partitioned area OR use the Copy Area function if the other partitioned area will match the same layout as the original partitioned area.
Page 164 Organizing WaveLinx Devices into Areas and Zones Once devices are added to the WaveLinx Area Controller, they will automatically show in the WaveLinx App. For a quick overview the devices and to view a total device count, open the WaveLinx App and login to the WaveLinx Area Controller.
Page 165 1: Stand in the space (area or sub area) where the area’s devices are accessible or visible. 2: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. Access the area’s Unassigned Device list per the instructions on page 165.
Page 166 Assignment” on page 167 for more information on using this feature). For WaveLinx Networked Relay Panels, there will not be an option to Blink to Identify. Tap the device to open it and use the app to manually turn ON and OFF the relay until the load is located.
Page 167 WaveLinx User Manual (Version 16.0) Using Multi-Select During Device Assignment The WaveLinx App allows for multiple devices to be selected and added to the area at the same time. Use multi-select with caution to avoid adding devices to the area that should not belong.
Page 168 Skip this step if the site does not have any partitioned areas. During the partition area setup, devices were configured to provide the signal to the WaveLinx system that the partition wall(s) are open or closed. This step will move the configured devices into one or more of the subareas so that they are removed from the Construction Area and easily found in the WaveLinx App.
Page 169 While considered a single device, each channel can be configured separately and assigned to a unique zone. The default out-of-the box configuration for the dual channel WaveLinx PRO Node is for channel 1 to perform dimming, and channel 2 to perform white tuning. This configuration can be adjusted if needed.
Page 170 WaveLinx User Manual (Version 16.0) 3: Expand the WL Pro Adapter-2C category (dual channel WaveLinx PRO Node), or WaveLinx Node (WPA IS Pro CCT) devices and tap place a device into Blink to Identify mode. The connected fixture should flash lighting ON/OFF (or Cool/Warm if controlling White Tuning).
Page 171 WaveLinx User Manual (Version 16.0) Changing Dual Channel WaveLinx PRO Node Configuration The dual channel WaveLinx PRO Node defaults to Channel 1 Dimmable, Channel 2 White Tuning (CCT range 3000-5000K). If the channel type OR default white tuning range (3000-5000K) is NOT correct: 1: When assigning the device to the area, use the drop down for both channel 1 and channel 2 and select the AREA for both channels.
Page 172 Light and then change back to Tunable White entering the correct range. The channels of the WaveLinx PRO Node are now ready to be assigned to the correct zone(s). If a channel is defined as White Tuning, make certain that there is a white tuning zone set up before proceeding.
Page 173 Like other WaveLinx devices, the dual channel WaveLinx PRO Node and the Advanced Integrated Sensor (WPA IS Pro CCT) allow for multi- select during the initial setup. If more than one dual channel WaveLinx PRO Node should belong to the same area, select both devices.
Page 174 WaveLinx User Manual (Version 16.0) 1: In a standard area or partitioned sub area, locate the device in the Devices in Area or Devices in Sub Area section and then tap the Switchpack to open it. White tuning control switchpack, appears in...
Page 175 Skip this step if the site does not have contact closure devices connected to WaveLinx Universal Voltage Dimming Switchpacks. This section walks through the process of assigning contact closure devices that are connected to a WaveLinx Universal Voltage Dimming Switchpacks (WSP-CA-010 model only) to the created area.
Page 176 WaveLinx User Manual (Version 16.0) To configure a switchpack that is using the contact closure: 1: In a standard area or partitioned sub area, locate the device in the Devices in Area or Devices in Sub Area section and then tap the Switchpack to open it (the default name will appear as Relay Switchpack CCI).
Page 177 The WaveLinx PRO Contact Closure Input Module will default to operating in Contact Closure Mode. If the device should operate in this mode, the type of contact and action will need to be defined for each input. If the WaveLinx PRO Contact Closure Input Module is connected to an occupancy sensor, perform the steps in this section to change the operation to Sensor Interface Mode.
Page 178 WaveLinx User Manual (Version 16.0) To configure the WaveLinx PRO Contact Closure Input Module: 1: In a standard area or partitioned sub area, locate the device in the Devices in Area or Devices in Sub Area section and then tap the Contact Closure Input Module to open it (the default name will appear as PRO Contact Closure Input).
Page 179 • Contact Closure Mode: the inputs will not operate until actions are configured. For each wired contact, select the type of input and assign the desired actions and then tap the back button to exit the screen. See “Configuring the Contact Input Actions for a WaveLinx PRO Contact Closure Input Module (model CCI-P-V)”...
Page 180 See the answer on page 414. • There is a device in the space that is not showing in the WaveLinx App. How do I get the device to appear so that I can assign it? See the answer on page 413.
Page 181 Area Hub Emergency Set. WaveLinx Networked Relay Panels can be ordered for Emergency Mode. These devices handle UL924 emergency mode internal to the cabinet. It is not necessary to configure any additional settings through the WaveLinx Application. Refer to the installation instructions for the panel or to the item reference sheets in this user guide for details on the emergency panel operation.
Page 182 2: Open the Emergency Mode screen: • For tablet users in landscape view, In the Devices list, locate and select the WaveLinx Area Controller. Tap the Emergency Mode tab. • For smaller devices in portrait view, at the top of the device list tap .
Page 183 2: Open the Emergency Mode screen: • For tablet users in landscape view, In the Devices list, locate and select the WaveLinx Area Controller. Tap the Emergency Mode tab. • For smaller devices in portrait view, at the top of the device list tap .
Page 184 7: Once the NPS and EM devices are assigned, tap SAVE. The WaveLinx Area Controller will send the NPS and EM device settings to all the assigned devices. This may take some time to process depending on the number of devices in the Emergency Set. Wait for the process to be completed successfully.
Page 185 Understanding the Emergency Set Color Indicator The WaveLinx Wireless Emergency Sets and Area Hub Emergency Sets have a colored indicator bar at the beginning of the Emergency Set Row. The colored indicator bar can be gray, red, or green. These colors can indicate different conditions:...
Page 186 Receptacles must be assigned to a receptacle zone to respond to default operation. If the contact closure input of a switchpack is connected to a Greengate sensor, set the Greengate sensor onboard configuration switches to a 5-minute hold time to prevent interference with WaveLinx hold-time settings.
Page 187 Receptacles must be assigned to a receptacle zone to respond to default operation. If the contact closure input of a switchpack is connected to a Greengate sensor, set the Greengate sensor onboard configuration switches to a 5-minute hold time to prevent interference with WaveLinx hold-time settings.
Page 188 Once all devices are assigned to areas, if there are unassigned devices still in the Construction Area: • If this is the only WaveLinx Area Controller in the facility, a device has been missed or has been added that was not shown on the plans.
Page 189 To add a standard area: 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the Areas option, tap + to create a new area. Areas Tap + to create a new area www.cooperlighting.com...
Page 190 • Relays controlling the same portion of a space may be grouped in a non-dimmable zone for easy group control. • Controlled WaveLinx PRO Receptacles or receptacles operated from WaveLinx PRO or CAT Switchpacks are placed in a receptacle zone to allow easy control capability.
Page 191 WaveLinx User Manual (Version 16.0) 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the All Areas list, tap the area name. 2: In the zone section, review the current zones/zone types. Tap + to create a new zone if necessary.
Page 192 Add Devices to a Zone In Unassigned Devices select the device(s) to add In Unassigned Devices select the device(s) to add The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 193 Select the device(s) to Select the device(s) to remove remove REMOVE Select to move device(s) REMOVE to the area or the construction area The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 194 Tap the name field and type a unique name for the item (no more than 20 characters). Select SAVE to apply the change. Select EDIT icon Enter the new name The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 195 Areas, zones, and devices can be deleted at any time. • A device that is deleted will return to its out-of-the-box, unpaired state. If it is a WaveLinx PRO or WaveLinx LV device, it will need to be paired as a new device. If it is a WaveLinx CAT device, it will need to be re-added through the Area Hub’s device details page by running a rescan.
Page 196 Modifying Partitioned Areas and their Zones and Devices The WaveLinx Area Controller version 16.0 allows creation of two partitioned areas per WaveLinx Area Controller. A partitioned area is a space within the facility that may have moveable divider walls to allow creation of one large space or several smaller spaces called sub areas. Devices in the space may need to operate independently for a single sub area when divider walls are closed or may need to operate a combination of sub areas when walls are opened.
Page 197 WaveLinx User Manual (Version 16.0) At the bottom of the main area screen are the area’s sub areas. Expand any sub area to view the devices that are assigned directly to the sub area (typically wallstations, ceiling sensors and other input devices) and the quantity of sub zones, devices and occupancy sets that are assigned to that sub area.
Page 198 EDIT WALLS to open the main wall dashboard. This screen allows you to view the current open or closed wall status or issue the open and closed command from the WaveLinx App to simulate the wall closure input (The onscreen button to simulate wall closure will not operate if a CAT Contact Closure Module input is being used for wall open and close signal). It also allows quick identification of the device currently mapped to each wall to provide the wall signal to the WaveLinx system.
Page 199 WaveLinx User Manual (Version 16.0) Adding a Partitioned Area 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the Areas option, tap + to create a new area. Areas Tap the plus icon to create a new area 2: Enter a descriptive name for the partitioned area and then select the Partitioned Area Type.
Page 200 WaveLinx User Manual (Version 16.0) 5: Perform the Wall Configuration. Tap any Wall Name to change the default name and then use the drop down to select the sub areas that the wall joins. Repeat until all wall names and sub areas are defined. Tap NEXT to move on to the next step.
Page 201 To add zones to a partitioned area and assign the zone to sub areas (sub zone): 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the All Areas list, tap the partitioned area name.
Page 202 To add or remove a sub zone assignment from a partitioned area: 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the All Areas list, tap the partitioned area name. 2: In the All Sub Area section, tap EDIT SUB AREAS.
Page 203 Adding Devices to a Sub Area or Sub Zone in a Partitioned Area 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. 2: In the All Areas list, select the partitioned area created for this space and then tap on EDIT SUB AREAS.
Page 204 Remove Devices from a Sub Area or Sub Zone 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. 2: In the All Areas list, select the partitioned area created for this space and then tap on EDIT SUB AREAS.
Page 205 To modify the name of a partitioned area or zone in the partitioned area: 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. 2: In the All Areas list, select the partitioned area.
Page 206 To modify the name of a sub area: 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. 2: In the All Areas list, select the partitioned area created for this space and then tap on EDIT SUB AREAS.
Page 207 To modify the name of a partition wall: 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. 2: In the All Areas list, select the partitioned area created for this space and then tap on EDIT WALLS.
Page 208 To delete device in a partitioned area: A device that is deleted will return to its out-of-the-box, unpaired state. If it is a WaveLinx PRO or WaveLinx LV device, it will need to be paired as a new device. If it is a WaveLinx CAT device, it will need to be re-added through the Area Hub’s device details page by running a rescan.
Page 209 To make modifications to the sub areas that a partition wall joins: 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. 2: In the All Areas list, select the partitioned area created for this space and then tap on EDIT WALLS.
Page 210 To make modifications to the input that issues the wall open/close signal: 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. 2: In the All Areas list, select the partitioned area created for this space and then tap on EDIT WALLS.
Page 211 If the manual override timer feature is activated, any manual action to the area (wallstation button press, manual command from the WaveLinx Mobile App, WaveLinx WAC Lighting App or WaveLinx CORE system) will begin the duration timer countdown. When the countdown expires, any lighting in zones that are not controlled by occupancy sensors will blink warn (if selected) and then turn OFF.
Page 212 • The manual override timer can be ignored during specified times of day by using Enable/Disable Manual Timer schedule events. If the manual override timer is disabled, the WaveLinx Application will display a clock icon in the area list and a message in the area display. The icon and message will clear once an enable manual override timer event occurs.
Page 213 When After Hours Occupancy Mode is deactivated, the unoccupied command will return to what is programmed in the area’s occupancy set. After Hours Occupancy Mode is activated and deactivated from a WaveLinx Time Schedule action or from an external time clock closure into a WaveLinx CAT Contact Closure Module or WaveLinx PRO Contact Closure Input Module.
Page 214 Color temperature values shown are approximate. Color temperature may differ dependent on the type of fixture and supported range for the tunable white lighting. The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher.
Page 215 0-10V fixtures. By default, the WaveLinx system starts with all dimmable zones set to a minimum level of 0% and a maximum level of 90%. These settings may be changed at any time by the administrator user.
Page 216 Adjustment of the operational mode affects only the switched load assigned to the dimmable zone. The dimmable loads in the zone will not be affected by the change in operation mode. The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher.
Page 217 Modifying Scene Settings and Response The WaveLinx system allows for sixteen programmable scenes per standard area and thirty-two programmable scenes per partitioned area. These scenes are labeled scene 0 through scene 15 (standard) or 0 through scene 31 (partitioned). Each scene is pre-programmed for light levels, ON/OFF responses, or white tuning levels to allow for functionality from occupancy sensors and wallstations once devices have been paired in the construction group or assigned to an area.
Page 218 It may be helpful to rename scenes to allow tenant users to identify scene functionality more easily. If WaveLinx Touchscreens are used in the system, hidden scenes will not be displayed. The scene names that appear on the touchscreen will be the names defined for the scenes in the WaveLinx App.
Page 219 6: Select the back button at the top of the screen to navigate back to the scene list or area. Modify additional scenes as needed. Back button Modifying Wallstation Button Response Once assigned to their controlled area, WaveLinx Wallstations operate with default functionality. See the device reference sheets for details on default operation. • “WaveLinx PRO W-Series Wallstation Reference Sheet” on page 76 •...
Page 220 OR tap See All Devices and select the device in the Devices list. 3: For WaveLinx PRO W-Series Wallstations only: Make sure that the faceplate configuration on the screen matches the installed wallstation. If necessary, select the correct configuration from the drop-down. W-Series Wallstation...
Page 221 WaveLinx User Manual (Version 16.0) Other wallstation types will automatically show the correct configuration and will not have the drop down. WW-Series Wallstation WWB-Series Wallstation WB-Series Wallstation CAT Wallstation 5: (Optional), Tap EDIT and rename the wallstation. 6. Make certain that the wallstation is enabled.
Page 222 Wall Status Toggle will only show in WAC2 (Gen 2) version 14.1.x.x firmware and higher. Network Action will only show in WAC2 (Gen 2) version 10.0.x.x firmware and higher. WAC must be a configured part of a WaveLinx CORE platform to perform supported network actions.
Page 223 Disabled Enabled The WaveLinx WB-Series Battery Powered Wallstation models WB2L, WB3L, WB5 and WB6, will not display the described LED behavior. The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 224 To copy wallstation programming: • The wallstations must be the same type and have the same faceplate configuration, i.e., if the original wallstation is a WaveLinx W-Series 4 small button with raise/lower, then the destination wallstation must be a WaveLinx W-Series 4 small button with raise/lower.
Page 225 Devices list. 3: Tap EDIT and then select COPY FROM WALLSTATION. Select EDIT Tap COPY FROM WALLSTATION The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 226 “Modifying Occupancy Sensor Response” on page 233. • The WaveLinx CAT Contact Closure Input Module supports connection of up to four external maintained or momentary contact closure devices. Note: It can also be placed in a special Sensor Interface Mode to connect to an external occupancy sensor. For details on adjusting occupancy sensor programming, see “Modifying Occupancy Sensor Response”...
Page 227 Set to Enabled The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. If the Maintained CCI tab is not displayed, make sure that the optional input is set for either the Dimmable + Contact Closure Input or Contact Closure Input type.
Page 228 Quick Links for Common Questions • I am using the WaveLinx Universal Voltage Dimming Switchpack’s contact closure input. My dimming switchpack does not have the Optional Input or Maintained CCI tab and I do not see the option to set the input type. Why is this happening? See the answer on page 416.
Page 229 Contact Closure Mode. has been identified, assigned to the area, and set for the contact closure input type. Refer to the instructions in “Step 2: Identify and Assign Devices to the Areas and Zones” on page 165 and “Step 7: Configure the WaveLinx PRO Contact Closure Input Module Mode”...
Page 230 Actions for Scene or Zone Actions Zone Toggle Level 5: Repeat for any additional inputs wired to the Contact Closure Input Module. This function available for maintained input type only. WaveLinx Networked Relay Panels: Relays will not blink when exiting Alert Mode. www.cooperlighting.com...
Page 231 Most functions are supported when a maintained contact closure is used. Momentary contact closures may be used for limited functions such as scene and zone commands. The WaveLinx CAT Contact Closure Input Module is supported in WAC Gen 2 Version 14.x.x.x and higher.
Page 232 Actions for Scene or Zone Actions Zone Toggle Level 5: Repeat for any additional inputs wired to the Contact Closure Input Module. This function available for maintained input type only. WaveLinx Networked Relay Panels: Relays will not blink when exiting Alert Mode. www.cooperlighting.com...
Page 233 When a standard or partitioned area is created, any occupancy sensor assigned to the area (sub area in a partitioned area) is automatically grouped into a default occupancy set to control the loads in the area (sub area). This includes fixture WaveLinx PRO and LV Integrated Sensors, WaveLinx PRO and CAT Ceiling Sensors, and external occupancy sensors connected to the contact input of WaveLinx PRO Universal Voltage Dimming Switchpacks, a WaveLinx PRO Contact Closure Input Module, or to a WaveLinx CAT Sensor Input Module.
Page 234 The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. External sensors connected to WaveLinx CAT Sensor Input Modules or WaveLinx PRO Contact Closure Input Modules will automatically open to the Occupancy view. Greengate sensors connected to WaveLinx PRO Universal Voltage Dimming Switchpacks will automatically open to the Occupancy tab if the input type is set for Occupancy Sensor only.
Page 235 If more than one occupancy sensor reports to the occupancy set, use test mode at the occupancy set level to limit interference from other sensors in the area. For sensors that support the use of the WaveLinx PRO IR Remote, use the occupancy sensor Occ Test function to reliably test an individual sensor’s function. Refer to the WaveLinx PRO IR Remote User Guide for details on using this feature.
Page 236 WaveLinx User Manual (Version 16.0) WaveLinx PRO Ceiling Sensor Settings The WaveLinx PRO Ceiling Sensors will display the following details. See the chart below for details on the available settings. Setting Default Description Current Status Displays the status of the sensor, either occupied or unoccupied.
Page 237 Sensor Interface Mode. See “Step 7: Configure the WaveLinx PRO Contact Closure Input Module Mode” on page 177 for details. The WaveLinx PRO Contact Closure Input Module will display the following details. See the chart below for details on the available settings. Setting...
Page 238 Switchpack’s programming. See “Replacing WaveLinx Devices” on page 394 for further information. Greengate sensors not approved for use with WaveLinx or not directly connected for power from the WaveLinx Universal Voltage Dimming Switchpack may not exhibit the described behavior. www.cooperlighting.com...
Page 239 If more than one occupancy sensor reports to the occupancy set, use test mode at the occupancy set level to limit interference from other sensors in the area. For sensors that support the use of the WaveLinx PRO IR Remote, use the occupancy sensor Occ Test function to reliably test an individual sensor’s function. Refer to the WaveLinx PRO IR Remote User Guide for details on using this feature.
Page 240 If more than one occupancy sensor reports to the occupancy set, use test mode at the occupancy set level to limit interference from other sensors in the area. For sensors that support the use of the WaveLinx PRO IR Remote, use the occupancy sensor Occ Test function to reliably test an individual sensor’s function. Refer to the WaveLinx PRO IR Remote User Guide for details on using this feature.
Page 241 WaveLinx User Manual (Version 16.0) WaveLinx CAT Sensor Input Module Connected to a Greengate Sensor The WaveLinx CAT Sensor Input Module connected to a Greengate Sensor will display the following details. See the chart below for details on the available settings.
Page 242 The occupancy set programming defines the response for all sensors within that set. When assigned to an area or sub area in a partitioned area, all occupancy sensor type WaveLinx PRO, LV or CAT devices are automatically assigned to the area’s default occupancy set.
Page 243 Not all sensors support vacancy mode. WaveLinx Outdoor Integrated Sensors will continue to operate in occupancy mode if vacancy mode is set. For occupancy sets that contain WaveLinx Universal Voltage Dimming Switchpacks connected to a Greengate Occupancy Sensor, please see page 241 for information on how hold time operates with these sensors.
Page 244 • The WaveLinx system has been designed such that when the external sensor is connected through a WaveLinx PRO Contact Closure Input Module (in sensor input mode) or a WaveLinx CAT Sensor Input Module, the occupancy set begins its hold time count down after the external sensor’s own hold-time has expired (i.e.
Page 245 The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. White tuning zones can be assigned to an occupancy set to have tunable white devices respond to specified color temperatures when occupancy command occur. If not included in an occupancy set, white tuning zones color temperature will not be affected by occupancy sensor commands.
Page 246 Adjusting Occupancy Set Assigned Sensors Any occupancy sensors assigned to the area including WaveLinx PRO and LV Integrated Sensors, PRO Tilemount Sensors, PRO and CAT Ceiling Sensors and external occupancy sensors connected to WaveLinx Universal Voltage Dimming Switchpacks, WaveLinx PRO Contact Closure Input Modules, or CAT Sensor Interface Modules will automatically be assigned to the occupancy set.
Page 247 The schedule event action Enable/Disable Occupancy Detection is available on WAC2 (Gen 2) minimum software version 12.x.x.x and higher. Test mode at the occupancy set will place all sensors in the occupancy set into test mode. If needed, for sensors that support the use of the WaveLinx PRO IR Remote, use the occupancy sensor Occ Test function to reliably test an individual sensor’s function.
Page 248 • I am using a WaveLinx Universal Voltage Dimming Switchpack’s contact closure input. My dimming switchpack does not have the additional icon showing in the Devices in Area section of the WaveLinx App or I do not see the option to set the input type. Why is this icon/input type not showing? See the answer on page 416.
Page 249 Tablet or Phone Landscape View/WAC Lighting App View Phone Portrait View Tap OCCUPANCY Tap + to add an occupancy set Tap OCCUPANCY Select area The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 250 8: Next, tap the sensors icon. Verify that the displayed assigned sensors are correct. If the assigned zones consist of fixtures with Integrated Sensors, the sensors from the controlled zone will automatically be displayed. WaveLinx PRO and CAT Ceiling Sensors and external occupancy sensors connected to WaveLinx PRO Universal Switchpacks, WaveLinx PRO Contact Closure Input Modules, and WaveLinx CAT Sensor Input Modules may need to be manually assigned.
Page 251 3: Next, tap + to add an occupancy set. Tablet or Phone Landscape View/WAC Lighting App View Tap OCCUPANCY Tap + to add an occupancy set Select area The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 252 8: Next, tap the sensors icon. Verify that the displayed assigned sensors are correct. If the assigned zones consist of fixtures with Integrated Sensors, the sensors from the controlled zone will automatically be displayed. WaveLinx PRO and CAT Ceiling Sensors and external occupancy sensors connected to WaveLinx PRO Universal Switchpacks, WaveLinx PRO Contact Closure Input Modules, and WaveLinx CAT Sensor Input Modules may need to be manually assigned.
Page 253 To make sure that used occupancy sets are assigned to the sub areas: 1: Open the WaveLinx App and login to the WaveLinx Area Controller as the administrator. In the All Areas list, tap the partitioned area name. 2: In the All Sub Area section, tap EDIT SUB AREAS.
Page 254 5: Select the area and then select the occupancy set that should pass commands to this one. For instance, if zone D/occupancy set D needs to respond to commands from occupancy set A, select occupancy set A. Select the desired area and occupancy The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 255 WaveLinx User Manual (Version 16.0) 6: Choose the desired Associated Occupancy Light Level settings. The Associated Occupancy Light Level is the light level that the controlled zone(s) should go to when triggered from an associated occupancy set. For instance, in this example we have associated occupancy set A to occupancy set D.
Page 256 9.x.x.x may be updated. If the WAC Gen 2 v9.x.x.x was using associated occupancy sets prior to the update, the associated occupancy light level will need to be programmed after the update is complete. The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 257 WaveLinx User Manual (Version 16.0) 4: Open the SENSOR tab and review and note the currently associated sensors. Once noted, delete one of the occupancy set associations. Tap SENSOR Select delete to remove one the associated Review list and note...
Page 258 WaveLinx User Manual (Version 16.0) Application Example 1: Open Office In this example, an open office has been segmented into distinct occupancy control zones. The walkway path has also been placed in a unique control zone. The walkway path zone should turn ON if anyone enters or remains in the walkway path. If the walkway path is not actively occupied but there are occupants in any zone A, B or C, the walkway path zone should remain ON but dim to a 20% light level.
Page 259 WaveLinx User Manual (Version 16.0) With this programming, as an occupant enters the walkway zone D, only zone D will initially respond to its occupied command. As the occupant enters cubicle zone A, the lighting will respond in zone A. If the occupant remains in zone A and zone D is no longer sensing occupancy, zone A will remain in its occupied light level while zone D will dim to the Associated Occupancy Light Level of 20%.
Page 260 Tablet or Phone Landscape View/WAC Lighting App View Phone Portrait View Tap OCCUPANCY Tap OCCUPANCY Select the occupancy set Select area The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 261 Tablet or Phone Landscape View/WAC Lighting App View Phone Portrait View Tap OCCUPANCY Tap delete Select area Tap OCCUPANCY Confirm DELETE The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 262 50% of the calibrated gain for longer than 30 seconds. For WaveLinx Outdoor Lighting Control Modules, Lighting will turn OFF if the light level has exceeded 65 lux for a period of 180 seconds (3 minutes). Lighting will turn ON if the light level falls below 16 lux for a period of 30 seconds.
Page 263 Modifying Closed Loop Daylighting Control This section focusses on the use of closed loop sensor control for WaveLinx PRO Ambient, Industrial, and Outdoor Integrated Sensors, WaveLinx LV Fixture Integrated Sensors, and WaveLinx PRO Tilemount Sensors. This includes details on how to: •...
Page 264 Tap DAYLIGHT The WaveLinx PRO IR Remote can also be used for adjusting this feature. Refer to the WaveLinx PRO IR Remote User Guide for details on using this feature. The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher.
Page 265 In the WaveLinx system, WaveLinx PRO Ambient, Industrial, and Outdoor Integrated Sensors, WaveLinx LV Fixture Integrated Sensors, and WaveLinx PRO Tilemount Sensors can use closed loop daylighting to directly control the physically connected load. Each daylight sensor is automatically assigned to a unique daylight set.
Page 266 Tap CALIBRATE ALL The WaveLinx PRO IR Remote can also be used for adjusting this feature. Refer to the WaveLinx PRO IR Remote User Guide for details on using this feature. The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher.
Page 267 The WaveLinx PRO IR Remote can also be used for adjusting this feature. Refer to the WaveLinx PRO IR Remote User Guide for details on using this feature. The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher.
Page 268 4: Next, enter the light meter’s average surface reading into the Work Surface field, changing the units to lux or foot-candles (fc) as needed. This allows the WaveLinx App’s displayed sensor reading to more closely approximate the values that would be read at the work surface. If desired, enable or disable the daylight set to DIM to OFF (see “Enabling/Disabling DIM to OFF Capability for Closed Loop Daylight Sets”...
Page 269 Tap to enable or disable DIM to OFF Tap back to exit screen DIM to OFF Enabled DIM to OFF Disabled The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 270 Tap the daylight set to open it WaveLinx Integrated Sensor and Tilemount Sensor assignment for open loop control is contingent on the use of WAC2 (Gen 2) v10.0.x.x and updated device firmware. Low-Voltage Integrated Sensors do not support this feature.
Page 271 To remove an assigned zone or output, in the Assigned Outputs section, tap on remove The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. If more than one zone is assigned to the same daylight set, the assigned zones will daylight dim in the same manner. Zones defined with the white tuning type and their associated devices will not appear in this screen to prevent unintentional assignment.
Page 272 The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. WaveLinx Integrated Sensor and Tilemount Sensor assignment for open loop control is contingent on the use of WAC2 (Gen 2) v10.0.x.x and higher updated device firmware. Low-Voltage Integrated Sensors do not support this feature.
Page 273 6: The next screens and steps will vary depending on the type of sensor selected: • WaveLinx PRO and CAT Ceiling Sensor or WaveLinx PRO Outdoor Control Module: When prompted, select YES to continue and confirm that the sensor is successfully assigned.
Page 274 WaveLinx Integrated Sensor and Tilemount Sensor assignment for open loop control is contingent on the use of WAC2 (Gen 2) v10.0.x.x and higher updated device firmware. Low-Voltage Integrated Sensors do not support this feature. www.cooperlighting.com...
Page 275 Tap DAYLIGHT The WaveLinx Outdoor Lighting Control Module does not require calibration. It is hardcoded for ON at dusk / OFF at dawn operation based on optimal performance factors for outdoor application. Lighting will turn OFF if the light level has exceeded 65 lux for a period of 180 seconds (3 minutes). Lighting will turn ON if the light level falls below 16 lux for a period of 30 seconds. The calibration screen for this sensor will not allow modification.
Page 276 50% of the calibrated gain for longer than 30 seconds. For WaveLinx Outdoor Lighting Control Modules, Lighting will turn OFF if the light level has exceeded 65 lux for a period of 180 seconds (3 minutes). Lighting will turn ON if the light level falls below 16 lux for a period of 30 seconds.
Page 277 Tap to enable or disable DIM to OFF Tap back to exit screen DIM to OFF Enabled DIM to OFF Disabled The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 278 Test Mode enable/disable The WaveLinx Outdoor Lighting Control Module will not allow test mode to be enabled as its settings are hardcoded for ON at dusk / OFF at dawn operation based on optimal performance factors for outdoor application. Lighting will turn OFF if the light level has exceeded 65 lux for a period of 180 seconds (3 minutes). Lighting will turn ON if the light level falls below 16 lux for a period of 30 seconds.
Page 279 Zone A Same Integrated Sensor WaveLinx Integrated Sensor and Tilemount Sensor assignment for open loop control is contingent on the use of WAC2 (Gen 2) v10.0.x.x and higher updated device firmware. Low-Voltage Integrated Sensors do not support this feature. www.cooperlighting.com...
Page 280 Schedule events through the WaveLinx App are automatically set to recur every week on the day(s) selected. From the WaveLinx App, the schedule allows for up to 16 timed events to be added. Each event can be assigned multiple actions. For instance, an event at 06:00 may need to issue scene commands to multiple areas of the facility.
Page 281 WaveLinx User Manual (Version 16.0) Adding a Schedule Event Before using Schedule Events, set the WaveLinx Area Controller clock if it was not set during the initial setup. See “Setting the System Location, Time, Date and Time Zone” on page 332 for this procedure.
Page 282 WaveLinx User Manual (Version 16.0) 5: IMPORTANT: Enable the event. Tap the disable/enable button to enable the schedule event and then tap + to add an action. Enable the event Tap + 6: Select the desired action type and parameters based on the action type chosen. Tap SAVE.
Page 283 • For partitioned areas: Scene and zone level commands will issue to the entire area independent of wall position. • For manual overrides: If wallstations or manual commands from the WaveLinx App are used, lighting will respond to the command manual commands or schedule event commands in the order that they are received (last command received is the commanded light level).
Page 284 The WaveLinx Application will indicate the occupancy set is disabled by displaying a clock icon in the occupancy set list and a banner message in the occupancy set screen. LEDs on the sensors will also indicate when they are disabled, flashing white for 1 sec. / OFF for 1 sec. repeatedly until the sensors are enabled.
Page 285 Hours Occupancy event action at the time when the occupancy set’s unoccupied command should revert to the normal occupancy set programmed level. When After Hours Occupancy Mode is activated, an After Hours Occupancy On message will be displayed at the top of the WaveLinx App. After Hours Occupancy Mode is active For details on setting the After Hours Mode for the area(s), see “After Hours Occupancy Mode”...
Page 286 Remember to set an Enable Wallstation event at the time when the wallstation(s) should become operable. The WaveLinx Application will indicate a wallstation is disabled by displaying a clock icon in the Devices in Area device list and a banner message in the wallstation’s screen.
Page 287 When the manual override timer is enabled and lighting is ON, the defined timer will restart so that lighting will automatically shut off once the timer expires. The WaveLinx Application will indicate when the manual override timer is disabled by displaying a clock icon in the area list and banner messages in the main and edit area screens.
Page 288 To modify an existing schedule event action, tap the desired action and then select EDIT . Make the necessary modifications and then tap SAVE. Tap EDIT Make the desired changes Tap the action Tap SAVE The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 289 Deleting a Schedule Event The WaveLinx schedule accessible by the WaveLinx App is hardcoded with 16 events. It is not possible to delete or add events. If an event should no longer function, disable the event, or delete the scheduled actions.
Page 290 Once devices are paired with the WaveLinx Area Controller the WaveLinx system operates with default demand response functionality. Upon receipt of the demand response signal (from either an external system through WaveLinx CORE or from a contact input closure to a WaveLinx CAT Contact Input Module), all dimmable zones will reduce their light level by 20%.
Page 291 Testing Demand Response The WaveLinx App contains a built-in test feature for verifying that demand response levels are set correctly. When activated, ALL areas in that WaveLinx Area Controller will respond with the defined zone reductions. To test demand response: 1: Using the WaveLinx Mobile App or the WaveLinx WAC Lighting App , login to the WaveLinx Area Controller as the administrator user.
Page 292 WaveLinx User Manual (Version 16.0) During test mode or during an active demand response signal, the WaveLinx App will show a demand response indicator at the top of the screen. All areas in the WaveLinx Area Controller will respond with the defined demand response behavior limiting commands from other controls to the reduced range.
Page 293 WaveLinx CAT Dimming Switchpack. Additional WaveLinx CAT Dimming Switchpacks control the Power and 0-10V wiring of the zoned fixtures. When using WaveLinx Switchpacks (WSP-MV-010 or WSP-CA-010), installation should be on a junction box and NOT installed on fixture wiring compartment. www.cooperlighting.com...
Page 294 • WaveLinx allows commands to be issued to lighting zones with zone level, zone raise, and zone lower commands. Zone commands can be issued to a specific zone, to ALL zones in an area, or to AFFECTED zones in the area. If a zone command is issued to ALL or AFFECTED zones, white tuning zones automatically ignore the command and will remain at the previous color temperature.
Page 295 White tuning is controlled from a different manual wallstation that allows the occupant to adjust to the color temperature to meet their needs. This is a common application in classrooms and conference rooms. Here is a sample of how this might be programmed in the WaveLinx system: Zones: •...
Page 296 Sensors in an Area” on page 265 for detailed setup instructions. WaveLinx Integrated Sensor and Tilemount Sensor assignment for open loop control is contingent on the use of WAC2 (Gen 2) v10.0.x.x and higher updated device firmware. Low-Voltage Integrated Sensors do not support this feature.
Page 297 Here is a sample of how this might be programmed in the WaveLinx system: Zones: •...
Page 298 WaveLinx User Manual (Version 16.0) Items Programming Assigned General user scenes • Scenes are programmed for each of the intensity levels issued by the general user wallstation and the exam lighting wallstation. • For the general user wallstation scenes, Scene Programming ignore zone 3 exam lighting.
Page 299 Quickly change the levels of each zone and save them to scenes using either the WaveLinx App, or with wallstations zone raise and lower commands and save scene commands. This type of control is ideal in environments such as a retail space where lighting needs to be changed frequently to display products in the best possible light.
Page 300 WaveLinx command control. WaveLinx Networked Relay Panels can be ordered for Emergency Mode. These devices handle UL924 emergency mode internal to the cabinet. It is not necessary to configure any additional settings through the WaveLinx Application. Refer to the installation instructions for the panel or to the item reference sheets in this user guide for details on the emergency panel operation.
Page 301 Emergency Sets are not limited by user defined areas and zones. There are limits by the hardware category, i.e., Wireless Emergency Sets (WaveLinx PRO) and Area Hub Emergency Sets (WaveLinx CAT). See the rules for each hardware category as outlined below:...
Page 302 WaveLinx User Manual (Version 16.0) The WaveLinx Wireless Emergency Sets and Area Hub Emergency Sets have a colored indicator bar at the beginning of the Emergency Set Row. The colored indicator bar can be gray, red, or green. These colors can indicate different conditions:...
Page 303 2: Open the Emergency Mode screen: • For tablet users in landscape view, In the Devices list, locate and select the WaveLinx Area Controller. Tap the Emergency Mode tab. • For smaller devices in portrait view, at the top of the device list tap .
Page 304 Emergency Set 3: Once all changes are done, tap SAVE. The WaveLinx Area Controller will send the NPS and EM device settings to all the assigned devices. This may take a bit of time to process depending on the number of devices involved. Wait for the process to be completed successfully.
Page 305 (max 3 devices) 3: Once all changes are done, tap SAVE. The WaveLinx Area Controller will send the NPS and EM device settings to all the assigned devices. This may take a bit of time to process depending on the number of devices involved. Wait for the process to be completed successfully.
Page 306 3: Once all changes are done, tap SAVE. The WaveLinx Area Controller will send the NPS and EM device settings to all the assigned devices. This may take a bit of time to process depending on the number of devices involved. Wait for the process to be completed successfully.
Page 307 2: Open the Emergency Mode screen. • For tablet users in landscape view, In the Devices list, locate and select the WaveLinx Area Controller. Tap the Emergency Mode tab. • For smaller devices in portrait view, at the top of the device list tap .
Page 308 Tap START TEST When the test is started, all EM Devices from the selected Emergency Sets will turn ON/100% and will not respond to other WaveLinx Device commands. WaveLinx wallstations can be used to verify proper response. If wallstations are used, the normal lighting will respond but the EM devices will remain ON/100%.
Page 309 WaveLinx User Manual (Version 16.0) During the test, the Mobile App will display an Emergency Test Mode ON banner. In the Emergency Mode screen, all Emergency Sets under test will display a red indicator on the row and have a flashing egress icon to indicate the set is in Test Mode.
Page 310 WaveLinx User Manual (Version 16.0) Viewing NPS and EM Device Details Devices that are capable of being NPS devices and WaveLinx PRO and CAT Emergency devices will have an additional tab in the Device Details screen. To view the additional tab: 1: Locate the device in its assigned area and zone and then tap the device to open the details.
Page 311 Connect the WaveLinx Mobile App to a WaveLinx Area Controller as a Personal Control User The use of Personal Control Users is geared toward the WaveLinx Mobile Application use. While it is possible to login as a personal control user (tenant) account using the WaveLinx WAC Lighting App, initial access to the WAC webpage to launch the lighting app requires the use of the administrator login and password.
Page 312 1: On the user’s mobile device, open the WaveLinx Mobile App and establish a connection with the WaveLinx Area Controller as the personal control user. 2: In the list of areas locate the desired area, and then tap favorite . The next time the user logs in to the WaveLinx Area Controller, the application will open to the favorite area.
Page 313 WaveLinx User Manual (Version 16.0) Raise and Lower the Light Level of all Controlled Zones in an Area Touch and hold or tap to RAISE and LOWER levels of all controlled To raise or lower levels for all area zones: loads within the area Use the raise and lower controls located on the area screen.
Page 314 WaveLinx User Manual (Version 16.0) Adjust the Light Level of Individual Zones in an Area To adjust the light level of individual zones in an area: • Touch and drag the slider for dimmable zones and white tuning zones to adjust the levels.
Page 315 WaveLinx User Manual (Version 16.0) Issue a Temporary Command to a Specific Control Device Only administrator users can issue a command to a specific device. To issue commands to a specific device (administrators only): High priority overrides will bypass demand response or photosensor daylight dimming to allow the device to respond to the commanded level.
Page 316 Tap CONFIRM Tap ACCEPT To determine touchscreen version, enter the passcode to open the touchscreen but do not login the touchscreen to a WaveLinx Area Controller. The version will display at the bottom of the Select a Controller screen. For security, it is recommended that default passcode be changed once the initial touchscreen configuration is complete. Refer to “Changing the Administrator Passcode” on page 327 for step-by-step instructions.
Page 317 IP 5: Once it has an IP address, the touchscreen will search for and then display any WaveLinx Area Controllers that it has found on the network. If the site has more than one WaveLinx Area Controller, multiple WaveLinx Area Controllers may be listed. Select the WaveLinx Area Controller that is programmed for the area(s) that the touchscreen should operate.
Page 318 Configuring the Area(s) that the Touchscreen Displays Once the connection between the Touchscreen and the WaveLinx Area Controller is made, the touchscreen will display all areas that are programmed into the connected WaveLinx Area Controller. It is possible to limit the touchscreen to display a specific area, multiple selected areas, and default to opening a favorite area.
Page 319 Quick Links for Common Questions • How do I change the area name(s) that is displayed? The area names are stored in the WaveLinx Area Controller. For information on changing an area name, see “Renaming Standard Areas, Zones, and Devices” on page 194.
Page 320 WaveLinx User Manual (Version 16.0) Selecting the Presets/Scenes that the Touchscreen Displays The touchscreen defaults to displaying all presets/scenes except for scenes that have been hidden through the WaveLinx App. It is possible to limit the touchscreen further to display only specific presets/scenes.
Page 321 Quick Links for Common Questions • How do I change the preset name(s) that is displayed? The preset or scene name is defined and stored in the WaveLinx Area Controller. For information on changing a scene name, see “Modifying Scene Settings and Response” on page 217.
Page 322 Under normal conditions, the touchscreen will maintain the connection to the WaveLinx Area Controller it has been connected to. If the connection to the WaveLinx Area Controller is lost or the touchscreen goes through a power cycle, the touchscreen should exhibit the following...
Page 323 If a touchscreen has been powered down, once power is restored, the touchscreen boots and attempts to reconnect to the previously connected WaveLinx Area Controller. Once the connection is made, the touchscreen will login with the previously defined user credentials and then will display either the All Areas list or the preset page of the favorite area if a favorite area has been defined.
Page 324 WaveLinx User Manual (Version 16.0) 3: To connect to a different WaveLinx Area Controller, scroll to the bottom of the display and select the option to CHANGE CONTROLLER. Select the correct WaveLinx Area Controller from the list. Tap CHANGE CONTROLLER...
Page 325 To change the touchscreen’s IP address, from the settings menu, select the option for Controllers, Areas & Users, and then select CHANGE CONTROLLER. Define the new settings and then tap the correct WaveLinx Area Controller to reconnect. Select the Controller, Areas &...
Page 326 WaveLinx User Manual (Version 16.0) Viewing the End User License Agreement (EULA) To view the touchscreen End User License Agreement (EULA): 1: From the Settings screen, select the End User License Agreement (EULA) link at the bottom of the screen.
Page 327 WaveLinx User Manual (Version 16.0) Changing the Administrator Passcode For security reasons, it is recommended that the default administrator passcode be changed. To change the admin passcode: 1: From the Settings screen, tap the Passcode option. 2: Enter the new passcode desired (must be 6 digits) and then enter the same passcode in the second field. Tap CONFIRM.
Page 328 1: Make sure that the computer being used has wireless connectivity and has a current web browser installed. 2: If there is more than one WaveLinx Area Controller in the facility, on the top of the WaveLinx Area Controller, locate the label with the MAC ID.
Page 329 Verify connection 4: Open the web browser and enter the IP address of the WaveLinx Area Controller in the address bar. (The default IP address if connecting through the onboard wireless access point is 192.168.100.1.) The first time the WaveLinx Area Controller is accessed, the browser may display message windows regarding the site security certificate.
Page 330 If this is not the first login for the WaveLinx Area Controller, the system page will display in the web browser. No further steps are necessary. If this is the first login to this WaveLinx Area Controller, continue with the following steps: 6: If this is the first login, the system will force a password change.
Page 331 Close the browser window The WAC will automatically reboot 9: Re-connect to the WaveLinx Area Controller’s Wi-Fi Access Point, entering the new Network Key assigned. Then navigate to and login to the WaveLinx Area Controller using the new credentials. Reconnect to the Wi-Fi...
Page 332 Setting the System Location, Time, Date and Time Zone To ensure schedule event accuracy, set the location, time, date, and time zone in the WaveLinx Area Controller. These settings are found within the system webpage. The location setting is used for calculating the astronomic clock sunset and sunrise times. In the event of power loss, the time and date are retained for up to 48 hours.
Page 333 AM from PM). Click the time zone drop down and select the proper time zone. • Use NTP: If the WaveLinx Area Controller is connected to a building network that uses a network time protocol (NTP) server, enable the Use NTP slider and fill in the NTP server address details.
Page 334 Adding a New User Account To create a new user account: 1: Establish a connection from the computer to the WaveLinx Area Controller as the administrator user. 2: Select the Users page, and then select the option to add a user.
Page 335 To administer changes to the username, role, and passwords of existing user accounts: 1: Establish a connection from the computer to the WaveLinx Area Controller as the system administrator user. 2: Select the Users page and then locate and select the pencil icon in the desired username row to open the edit form.
Page 336 WaveLinx User Manual (Version 16.0) Deleting a User Account 1: Establish a connection between the computer and the WaveLinx Area Controller as the system administrator user. 2: Select the Users page and then select delete in the desired username row.
Page 337 To restore the user accounts from a backup: 1: Establish a connection from the computer to the WaveLinx Area Controller as the system administrator user. 2: Select the Users page and then scroll down the page to select the choose file option.
Page 338 WaveLinx User Manual (Version 16.0) 3: Navigate to and then select and open the user backup file. Select the user backup file 4: Click UPLOAD. After a short delay, a successful upload message should be displayed. Select UPLOAD 5: Next, click RESTORE USERS FROM BACKUP. Once complete, a success message will be displayed. Refresh the webpage to view the restored user accounts.
Page 339 WaveLinx User Manual (Version 16.0) Renaming the WaveLinx Area Controller Each WaveLinx Area Controller has a default name that will appear in the WaveLinx Mobile App or WaveLinx WAC Lighting App . It is possible to change this name through the internal webpages.
Page 340 • Before updating WaveLinx Area Controller or device firmware (recommended) • After updating WaveLinx Area Controller or device firmware (recommended) The system may be restored from the backup if programmed changes do not operate as intended or if replacing the WaveLinx Area Controller in the event of a failure.
Page 341 • If WaveLinx Area Controller A2 also fails, it can be replaced by a new WaveLinx Area Controller A3. • If a WaveLinx Area Controller in another area of the facility fails (B1), and the B WaveLinx Area Controller is deemed more critical than the A WaveLinx Area Controller, WaveLinx Area Controller A2 cannot be moved to replace WaveLinx Area Controller B1 (A2’s ID was previously...
Page 342 Select the user backup file If a different IP address is being used for the replacement WaveLinx Area Controller and WaveLinx Touchscreens or WaveLinx Power Modules connected to Low-Voltage Lighting are being used in the system, it will be necessary to remap the WaveLinx Touchscreens and WaveLinx Power Module to the new IP address. For information on remapping Touchscreens, see “Changing the Touchscreen User or WaveLinx Area Controller”...
Page 343 • I am replacing a failed WaveLinx Area Controller with a replacement WaveLinx Area Controller. Do I need to go through the construction grouping process to pair the devices with the new WaveLinx Area Controller or is this part of the restore function? See the answer on page 415.
Page 344 WaveLinx App. Once logged in, select Support and Services, and then select Firmware. Filter for WaveLinx Wireless firmware updates. Select download to save any updates to the computer. The WaveLinx update file typically contains the WaveLinx Area Controller updates as well as any updates for specific WaveLinx devices.
Page 345 5: Next, scroll down to the WAC Update section, to review the available updates for the WaveLinx Area Controller. If an update is available, select the UPDATE WAC button to proceed.
Page 346 WaveLinx Area Controller can also be updated through the WaveLinx Area Controller webpages. Note: WaveLinx Networked Relay Panels do not typically require updates and are not updated through the WaveLinx Area Controller. If an update becomes necessary, files and instructions will be provided.
Page 347 Once one device finishes, the WaveLinx Area Controller will move on to the next device and will continue until all devices are updated. If the WaveLinx Area Controller is in a location that is visible, the power/health LED or other LEDs may flash during the firmware update process.
Page 348 WaveLinx Area Controller. • At any other time, if the firmware of a paired device is found to be older than what is in the WaveLinx Area Controller, the firmware of the device(s) will be updated at the user defined time after the discrepancy is detected.
Page 349 Changing Wi-Fi Access Point Settings The WaveLinx Area Controller may be used as an access point for the WaveLinx Mobile App or WaveLinx WAC Lighting App communications. By default, the wireless access point is enabled and uses the unit’s MAC ID plus one for its SSID. To update the Wi-Fi access point settings, select the Network page, and then click on the pencil icon in the Wi-Fi AP section.
Page 350 Changing Ethernet Settings If the WaveLinx Area Controller is installed into the facility’s building LAN, by default, it is set for obtaining an IP address automatically through DHCP. It is possible to assign a static IP by changing the selection to use a defined IP address, and then typing in the desired IP address, subnet mask and default gateway.
Page 351 Changing DNS Settings If not using DHCP, it is possible to hardcode the domain name server settings into the WaveLinx Area Controller. Select the Network page, then click the pencil icon within the DNS screen. To manually enter the DNS, turn off the Auto DNS option and then type the IP addresses of the desired domain name servers.
Page 352 Removing Devices in the Construction Area Using the Debug Page If multiple devices have paired with the wrong WaveLinx Area Controller, a four second press of the PAIR button will remove all devices that are still in the Construction Area, easily setting the devices back to factory default with a single action. For sites where access to the WaveLinx Area Controller is limited, the WaveLinx Area Controller’s debug page may be used to perform this function, easily removing devices that are still in...
Page 353 To remove devices from the WaveLinx Area Controller’s Construction Area using the debug page: 1: Establish a connection from the computer to the WaveLinx Area Controller as the administrator user. 2: Select the menu icon, then scroll to the bottom of the menu. Position the mouse arrow below the Logout button and copyright info. A gray highlight will appear over the white space.
Page 354 WaveLinx User Manual (Version 16.0) Rebooting the WaveLinx Area Controller It is possible to reboot the WaveLinx Area Controller from the internal webpages or from the WaveLinx App. During changes to network settings, the system may prompt for a reboot.
Page 355 This feature requires a WAC2 with minimum software version 11.x.x.x. The WaveLinx WAC Lighting App will have the same appearance and functionality as the WaveLinx Mobile App when logged in to a WaveLinx Area Controller. The WAC Lighting App will not require user registration or have the notification or demonstration mode features of the WaveLinx Mobile App.
Page 356 WaveLinx User Manual (Version 16.0) For further details on accessing the WAC Lighting App, see “Preparing to use the WaveLinx WAC Lighting App” on page 128. www.cooperlighting.com...
Page 357 IP address of the Area Hub. Refer to page 26 to connect to and then discover the Area Hub which will display the IP address in the WaveLinx Mobile App. The laptop being used for configuration must connect to the same network and be given an IP address on the same subnet as the Area Hub and WaveLinx Area Controller for access.
Page 358 The default name of an area hub is AH-XXXX where X is the last four characters of the Area Hub’s MAC address. If there are multiple Area Hubs, update the name for easy identification in the WaveLinx Mobile Application. Area Hub names should be unique. Avoid duplication.
Page 359 SAVE Note: If an Area Hub name is changed AFTER the Area Hub has been discovered and added to the WaveLinx Area Controller, the new name will not automatically appear. To read the new name, run an Area Hub discovery command. The name will be updated.
Page 360 Changing Ethernet Settings The WaveLinx CAT Area Hub is set to use DHCP by default. If using a DHCP server, no further IP address settings are needed. If not using DHCP, the WaveLinx CAT Area Hub is set up to automatically configure an initial IP address in the range of 192.168.1.100 through 192.168.1.255 to allow for initial operation and configuration.
Page 361 While this webpage also supports the option of updating Area Hub firmware, this function should be done through the WaveLinx Area Controller. For details on updating firmware, see “Updating the Firmware of WaveLinx Devices” on page 346.
Page 362 • Viewing Disclaimer and License Agreements Changing the Area Hub Password To perform a factory reset: 1: If needed, login to the WaveLinx Area Hub Configurator webpage. 2: Select the menu and then select Change Password. 3: Enter the current password and then the new desired password. Select SUBMIT.
Page 363 Logging Out of the WaveLinx CAT Area Hub Webpages The WaveLinx CAT Area Hub Webpage contains a manual Logout option to exit the webpage. The Area Hub will also automatically log the user out if the webpage is manually closed without logout or if the webpage is open for longer than 15 minutes with no activity.
Page 364 1: Power down the existing Area Hub and label each port connection before disconnecting the ports. 2: Configure the new Area Hub as instructed in “Initial Configuration Steps for the WaveLinx Area Hub” on page 26. Note: the new area hub does not need to have the same IP address as the previous one but does need to be addressed in the same subnet.
Page 365 Deleting an Area Hub from the WaveLinx Area Controller If an Area Hub has been added to the incorrect WaveLinx Area Controller, the Area Hub can be deleted. If replacing an Area Hub, DO NOT use this method. Refer to “Replacing a WaveLinx CAT Area Hub” on page 364 for replacement procedures.
Page 366 WaveLinx User Manual (Version 16.0) 4: Select DELETE again when asked to confirm. DELETE The WaveLinx CAT Area Hub will return to factory defaults, ready to be added to another WaveLinx Area Controller. Any connected CAT devices will return to distributed operation. www.cooperlighting.com...
Page 367 Using the Onboard Display The WaveLinx Networked Relay Panel has an onboard display used for initial configuration in preparation for connection to the WaveLinx Area Controller. The onboard display also allows for manual overrides to the relays and dimmer channels connected to that relay cabinet. This section will describe the onboard control functions.
Page 368 Commanding Individual Relays When possible, use the WaveLinx Mobile App or WaveLinx devices to command the relays. Before the panel is connected to the WAC, or if necessary, after WAC connection, individual relays can be commanded from the onboard display. The command will remain in effect until the next command from the display or WaveLinx system occurs.
Page 369 Once power returns and the relays go to their programmed power-on state, they will remain in that state until the next command is received from the onboard display or WaveLinx system. If the power-up state differs from the last relay state, the WaveLinx App will not reflect the correct status for the relay.
Page 370 AND the physical lock switch on the relay must be engaged for the relay to be in a locked state. • If the relay lock switch is disabled and the physical LOCK switch on the relay is engaged, the panel will process WaveLinx commands to that relay in the order they are received.
Page 371 Viewing and Commanding Dimmers If the relay panel has been ordered with the optional panel mount or remote mount WaveLinx Panel Dimming Module, use the main display to view status and adjust the light level of the dimmers real-time. The adjusted light level will remain in effect until the next command is received.
Page 372 Use the display to change the power-on level. Once power returns and the dimmers go to their programmed power-on level, they will remain at that level until the next command is received from the onboard display or WaveLinx system. If the power-on level differs from the last level issued, the WaveLinx App will not reflect the correct status for the dimmer.
Page 373 WaveLinx User Manual (Version 16.0) To configure Network Settings: From the HOME screen: 1: Make sure that the relay panel Ethernet port is connected to the Building LAN. 2: Press SETTINGS. 3: Press NETWORK. 4: Press NETWORK SETTINGS 5: Select either MODE: DHCP or MODE: STATIC.
Page 374 6: Review the IP ADDRESS and then press NEXT. (continued next page) STATE: Indicates if the Ethernet port is IP ADDRESS: Displays the current IP ready for connection to a WaveLinx Area address. Controller. • The IP address that has been statically •...
Page 375 In most cases, the panel will prompt for reboot if network changes are made. If it is necessary to reboot the network, it can be done at any time. Rebooting the network will temporarily disconnect the panel from the WaveLinx Area Controller until the reboot is complete.
Page 376 If it is necessary to replace the WaveLinx Networked Relay Panel controller card, first, follow the instructions provided for the replacement. Once the controller card is replaced, follow the steps 4 through 7 in the setup instructions “Initial Configuration Steps for the WaveLinx Networked Relay Panel”...
Page 377 Controller will lose connection and control of the relays/dimmers in the relay panel. To fix this, the IP address must be refreshed in the Mobile App. Use this same process if the WaveLinx Area Controller IP is changed to a different subnet and the IP address of the relay panel is updated.
Page 378 WaveLinx User Manual (Version 16.0) Rebooting the WaveLinx Networked Relay Panel Reboot the WaveLinx Networked Relay Panel from the WaveLinx Mobile App. A reboot is a soft reset which restarts the software in the WaveLinx Networked Relay Panel without affecting configured settings.
Page 379 Expand Relay Panel Tap the icon Tap Delete Tap Delete DETAILS Devices 5: Tap DELETE when prompted to confirm. Tap DELETE The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 380 WaveLinx User Manual (Version 16.0) WaveLinx Low-Voltage Power Module Administration This section is dedicated to administrator tasks as they pertain to the WaveLinx Low-Voltage Power Module and Low-Voltage Fixtures. This section will discuss: • Using the Internal Webpages of the WaveLinx Low-Voltage Power Module •...
Page 381 WaveLinx User Manual (Version 16.0) 2: Open a current web browser. In the address bar, enter the IP address of the Low-Voltage Power Module (default 192.168.1.254). The browser may display a warning regarding site security. The display and wording of this message may differ. Locate the option to bypass the warning and proceed to the site.
Page 382 • Factory Reset: Use with extreme caution. This will cause all settings to be removed, resetting the unit to factory defaults. Pairing information will be lost if the unit has been previously paired with a WaveLinx Area Controller. • Select Test Mode: All lights connected to the Low-Voltage Power Module will cycle between OFF and ON for 15 seconds.
Page 383 Gateway IP. For best results, enter the WaveLinx Area Controller’s IP address that should pair with this Low-Voltage Power Module. This ensures that during pairing, the Low-Voltage Power Module connects to the correct WaveLinx Area Controller. If the WAC IP is not entered, once the Low-Voltage Power Module is paired with a WaveLinx Area Controller, the WaveLinx Area Controller’s IP will automatically populate in this field.
Page 384 WaveLinx User Manual (Version 16.0) User Settings Administration For security purposes, change the default password. Users should set a complex password when changing passwords. Use the User Settings tab to change the password for the administrator login. Select Edit, then select the line for the Administrator User.
Page 385 Although it is possible to update the firmware of the Low-Voltage Power Module and connected Low-Voltage devices through the firmware tab, it is recommended to perform this procedure using the WaveLinx Area Controller Webpages. Please see “Updating the Firmware of WaveLinx Devices”...
Page 386 The WaveLinx Area Controller and Low-Voltage Power Module rely on their connection through the Ethernet to communicate information back and forth to the connected WaveLinx LV devices. During the initial pairing process, the IP addresses are stored for connection purposes. If the IP address of either device changes, the connection between them will be lost.
Page 387 IP address. Once configuration is complete, be sure to connect the Low-Voltage Power Module to the Building LAN. 5: Press and release (1 second press) the PAIR button located on the side or rear panel of the WaveLinx Area Controller to start pairing mode.
Page 388 WaveLinx User Manual (Version 16.0) Unpairing a Low-Voltage Power Module from the WaveLinx Area Controller If a Low-Voltage Power Module has paired to the incorrect WaveLinx Area Controller, the Low-Voltage Power Module can be removed using one of two methods.
Page 389 WaveLinx User Manual (Version 16.0) Rebooting the Low-Voltage Power Module Reboot the Low-Voltage Power Module from the onboard pushbuttons or from the Low-Voltage Power Module’s internal webpages. A reboot is a soft reset which restarts the software in the Low-Voltage Power Module without affecting configured settings. Once started, the reboot will take approximately 1 ½...
Page 390 Adding a WaveLinx CAT Device If a new WaveLinx CAT device is added to the system or a new room of devices is connected to an unused Area Hub port, follow the steps below to bring the device into the WaveLinx mobile app: 1: Power down the Area Hub and connect the new device or port of devices.
Page 391 WaveLinx User Manual (Version 16.0) 5: In Device Details, tap MANAGE and then tap RESCAN. MANAGE RESCAN 6: Wait for the scan to complete (may take several minutes.) Locate the row with the new item indicator and then tap it to open the details.
Page 392 WaveLinx Area Hub RESCAN command. • With a WaveLinx Networked Relay Panel relay or dimmer, the device will be deleted. If the device is still attached to the same relay panel, it can be readded through the WaveLinx Relay Panel REIMPORT command.
Page 393 DELETE Adding a Deleted Device If a WaveLinx device has been deleted in error, it is easy to re-add the device. The device will need to be reconfigured once added back to the WAC. Pairing a Deleted WaveLinx PRO Device If a WaveLinx PRO device is deleted in error, pair the device as if it is a new device.
Page 394 5: Wait a few minutes to give the system enough time to find the device. The device may display a message briefly on the WaveLinx App when it joins the paired construction group. The device will also be shown in the construction group and in the Unassigned Devices.
Page 395 8: Locate the original device in the WaveLinx App. For load devices, open the appropriate control zone. For wallstations or WaveLinx Ceiling Sensors, locate the device in the Devices in Area section. Note that the online indicator for the device may be gray or red indicating that the device has lost communication.
Page 396 Do not adjust programming for the devices within the suggested time. Replacing WaveLinx LV Devices If it becomes necessary to replace a Low-Voltage Fixture or Low-Voltage Fixture with Integrated Sensor, the WaveLinx App can be used to sync the previous device’s settings to the new device.
Page 397 4: Locate the original device in the WaveLinx App. For Low-Voltage Fixtures or Low-Voltage Fixtures with Integrated Sensors, open the appropriate control zone. Note that the online indicator for the device may be gray or red indicating that the device has lost communication.
Page 398 Tap ADD DEVICES. The device will be added to the WAC. Found new device Tap ADD DEVICES The WaveLinx WAC Lighting App can be used with WAC2 (Gen 2) minimum software version 11.x.x.x and higher. www.cooperlighting.com...
Page 399 WaveLinx User Manual (Version 16.0) 7: Locate the new device in the area created for the Area Hub port. WaveLinx CAT Switchpacks will show in the Zone while other devices will show in the Devices in Area section. Once found, tap to remove the device from the area and move it to the Construction Area.
Page 400 Performing a Factory Reset All WaveLinx devices have a method of restoring the device to factory defaults. This command should be used with caution as settings will be lost when the factory default command is used. Please refer to the device reference sheets starting on page 15 for details on how to perform a factory reset in each device type.
Page 401 Use the WaveLinx Mobile App to view the current application version. 1: On the user’s mobile device, open the WaveLinx Mobile App. The Mobile App does not need to be connected to the WaveLinx Area Controller to view the version information.
Page 402 • WAN LED will be ON if there is an active connection from a third-party device or WaveLinx CORE system. • LAN LED will be ON if the WaveLinx Area Controller has a defined IP address (DHCP/static) and is on the building network. It will blink when the WAC2 is in pairing mode.
Page 403 The sensor has been previously paired with a WaveLinx Area Controller. blinks white with motion • Method 1: If there is more than one WaveLinx Area Controller at the facility, instead of green. Device identify which WaveLinx Area Controller is paired by successively placing the...
Page 404 WaveLinx User Manual (Version 16.0) Device Unexpected Condition Resolution Steps WaveLinx PRO The connected fixture is • Verify that the fixture’s power source is connected and powered from the circuit breaker. • WaveLinx PRO Node • Perform a factory reset on the device. Refer to the procedure in the device reference sheet starting on page 15.
Page 405 WaveLinx Area Controller. The wallstation will automatically time-out from this • W-Series Wallstation function after 1 hour. • If the WaveLinx Area Controller has exited pairing mode already, the press of the wallstation button should also cancel the LED flash behavior. When a button is pressed, •...
Page 406 When a button is pressed, • The wallstation has been previously paired and is part of a WaveLinx App the LED flashes white for defined area and has been disabled using a time schedule event or manual 1 sec./OFF for 1 sec.
Page 407 Resolution Steps CONTINUED When a button is pressed, • The wallstation has been previously paired and is part of a WaveLinx App the LED flashes white* (1 defined area and has been disabled using a time schedule event or manual •...
Page 408 • Try to perform the pairing function. If the pairing operation works, the LED may be turned OFF via a software setting. Once the device is paired and accessible in the WaveLinx App, select the device to review the occupancy sensor settings and ensure that the LED function is enabled.
Page 409 • Verify that the WaveLinx Area Controller is powered and operational. to have some response to motion and wallstation • Verify that the IP address of the WaveLinx Area Controller is still in the same presses. The LED on the subnet as the IP address of the Area Hub.
Page 410 • Contact technical support if the problem persists. The LED is Blue and the • The device is operating in Distributed Mode and is not yet added to a WaveLinx device is not responding Area Controller. The device may respond to devices on the same CAT bus when properly in Distributed Mode.
Page 411 • Contact technical support if the problem persists. The LED flashes blue and • The device is operating in Distributed Mode and is not yet added to a WaveLinx the device is not Area Controller. The device may respond to devices on the same CAT bus when controlling lighting in Distributed Mode.
Page 412 Pairing mode timed out before I was done adding my devices or before I confirmed that my devices paired properly. What should I do? Simply press the PAIR button on the WaveLinx Area Controller again to re-establish pairing mode. All paired devices that are in the construction group will respond with the paired behavior and additional devices may be added.
Page 413 I am done assigning my devices to areas, but devices still show in the WaveLinx App’s Unassigned Devices. What should I do? If this is the only WaveLinx Area Controller in the facility: A device may have been added that is not shown on the plans. Connect to the WaveLinx Area Controller Using the WaveLinx Mobile App or the WaveLinx WAC Lighting App .
Page 414 Blink to Identify command as needed. If there are other WaveLinx Area Controllers in the facility: The device may have paired with the incorrect WaveLinx Area Controller. Follow the steps on page 413 to remove the device and to prepare it for pairing to the correct WaveLinx Area Controller.
Page 415 My schedule events are running but they are running at the incorrect time. What could be causing this? The WaveLinx Area Controller may not be on the correct time and date or may be set for the incorrect time zone. Refer to page 332 to set the time, date, and time zone in the WaveLinx Area Controller.
Page 416 I am using a WaveLinx Universal Voltage Dimming Switchpack’s contact closure input. My switchpack does not have the additional icon showing in the Devices in Area section of the WaveLinx App or I do not see the option to set the input type. Why is this icon/input type not showing?
Page 417 • After verifying that the correct switchpack model is being used, make sure that the switchpack firmware is updated to the latest version. Firmware must be version 0x2180560 or later to support the contact closure functionality. Refer to “Updating the Firmware of WaveLinx Devices”...
Page 418 In a large zone, WaveLinx PRO devices that are further away from the WaveLinx Area Controller may have a delay in response to commands. For instance, if the zone is turned ON, lighting devices that are closer to the WaveLinx Area Controller may turn ON earlier than others that are farther away, generating a “popcorn”...
Page 419 WaveLinx User Manual (Version 16.0) • Point Guards can be assigned through the method described in this chapter using the WaveLinx Area Controller webpages or by using the WaveLinx Programming Remote (IR remote works on devices that contain sensors). Using one of these methods, assign more devices to be Point Guards within any zone (max.
Page 420 Verify success Type enable-wlm At this point, the WaveLinx Configurator may automatically sign out the administrator. Continue to the next step. Step 2: Logging in to the /wlm Webpage 1: Establish a connection from the computer to the WaveLinx Area Controller webpage as the administrator user.
Page 421 ON prior to the assignment of Point Guards if the Zone contains these device types. To enable the HBIS DomZone: 1: Establish a connection from the computer to the WaveLinx Area Controller webpage as the administrator user and then login to the /wlm WaveLinx Manager as the darkcapi user.
Page 422 WaveLinx User Manual (Version 16.0) 5: On any listed DomZone endpoint, select Details. Select Details DomZone endpoint 6: Scroll down the DeviceEndpointOutput page until the Linked Objects are shown. Scroll down to Linked Objects 7: Locate and then select the Zone name in the Linked Objects.
Page 423 Back It is easy to lose track of what screen is active due to many screens looking similar in the /wlm WaveLinx Manager. Multiple screens may contain similar buttons. If unsure if the screen is the correct one, return to the Engine menu from the toolbar and then restart these steps.
Page 424 WaveLinx User Manual (Version 16.0) Step 4: Assign the Point Guard(s) Before beginning this step, identify the best device(s) to be Point Guard(s), ideally within 150 feet (approx. 45 meters) of the WaveLinx Area Controller and centrally located in the zone.
Page 425 WaveLinx User Manual (Version 16.0) 5: Scroll down the list of DomZone endpoints in the zone. Each endpoint corresponds with a device in the zone. Click Identify on the first device to place one of the device in Blink to Identify mode. If it is not the desired device, continue to click on Identify until the correct device is located.
Page 426 WaveLinx User Manual (Version 16.0) Step 5: Logout and Close Once the changes are complete, logout and close the WaveLinx Manager and the WaveLinx Area Controller webpages. To logout and close: 1: At the top of the /wlm webpage, select Logout.
Page 427 Skip to “Step 2: Setup Access for the WaveLinx CORE” if the Wi-Fi Access Point is already enabled. The WaveLinx Area Controller’s Wi-Fi Access Point is enabled by default but can be turned off during the controller’s setup process. The Wi-Fi Access Point must be enabled to allow access to the CORE.
Page 428 5: Verify that the words WAC is centralized appear. Tap Network WAC is centralized Note: If the display shows WAC is not centralized, refer to the WaveLinx CORE Lighting System Configuration Guide for details on device discovery, import, and configuration. www.cooperlighting.com...
Page 429 Step 3: Access the CORE Once Step 2 above is completed, the WaveLinx Area Controller will allow access to the CORE for up to 2 hours. To access: 1: In the Network page, locate the WAC Access to CORE section, and then tap LOGIN. A connection will be made to the CORE.
Page 430 Visite www.cooperlighting.com para conocer nuestros términos y condiciones. Cooper Lighting Solutions 1121 Highway 74 South Peachtree City, GA 30269 P: 770-486-4800 www.cooperlighting.com Cooper Lighting Solutions is a For service or technical assistance: registered trademark. 1-800-553-3879 All other trademarks are property of Canada Sales ©...
