T1BVT4D
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TBV1 Altronix/Brivo backplane
- One (1) Tango1B - PoE Driven Power Supply with
Lithium Battery Backup
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
T1BV3F4SD
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TBV1 Altronix/Brivo backplane
- One (1) eFlow6NB - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
T2BV7F8SD
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TBV2 Altronix/Brivo backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
- One (1) VR6 - Voltage Regulator
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TBVKFD_040323
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
Access & Power Integration
T2BV77F8SD
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TBV2 Altronix/Brivo backplane
- Two (2) eFlow104NB - Power Supply/Chargers
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
- Two (2) VR6 - Voltage Regulators
T3BV77F16SD
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with TBV3 Altronix/Brivo backplane
- Two (2) eFlow104NB - Power Supply/Chargers
- Two (2) ACMS8CB - Dual Input PTC Access Power Controllers
- Two (2) PDS8CB - Dual Input PTC Power Distribution Modules
- Two (2) VR6 - Voltage Regulators
- One (1) RSB2 - Rocker Switch Bracket with
Two (2) Rocker Switches (Not evaluated by UL)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Brivo T1BVT4D
Summary of Contents for Brivo T1BVT4D
- Page 1 8 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1 enclosure with TBV1 Altronix/Brivo backplane - Trove2 enclosure with TBV2 Altronix/Brivo backplane - One (1) Tango1B - PoE Driven Power Supply with - Two (2) eFlow104NB - Power Supply/Chargers...
-
Page 2: Configuration Chart
Overview: Altronix/Brivo Trove kits are pre-assembled and consist of Trove enclosures/backplanes with factory installed Altronix power supply/chargers and sub-assemblies. These kits also accommodate various combinations of Brivo boards for up to sixteen (16) doors in a single enclosure. Configuration Chart:... - Page 3 1. Align the Brivo board on the backplane to match the boards’ mounting holes with corresponding pems. 2. Fasten 4/40 - 5/8” Metal Spacers (provided) to pems that match the hole pattern for Brivo board (Fig. 2, 2a, pg. 3).
- Page 4 1. Align the Brivo board on the backplane to match the boards’ mounting holes with corresponding pems. 2. Fasten 4/40 - 5/8” Metal Spacers (provided) to pems that match the hole pattern for Brivo board (Fig. 3, 3a, pg. 4).
- Page 5 1. Align the Brivo board on the backplane to match the boards’ mounting holes with corresponding pems. 2. Fasten 4/40 - 5/8” Metal Spacers (provided) to pems that match the hole pattern for Brivo board (Fig. 4, 4a, pg. 5).
- Page 6 1. Align the Brivo board on the backplane to match the boards’ mounting holes with corresponding pems. 2. Fasten 4/40 - 5/8” Metal Spacers (provided) to pems that match the hole pattern for Brivo board (Fig. 5, 5a, pg. 6).
- Page 7 1. Align the Brivo board on the backplane to match the boards’ mounting holes with corresponding pems. 2. Fasten 4/40 - 5/8” Metal Spacers (provided) to pems that match the hole pattern for Brivo board (Fig. 6, 6a, pg. 7).
- Page 8 - Programmable via USB or web browser - includes operating software and 6 ft. USB cable. LINQ2 Mounts Inside any Trove Enclosure LINQ2 Module Network Connection: Installation, Programming and Monitoring Altronix eFlow Power Supply - 8 - Trove Brivo PTC Kits Installation Guide...
- Page 9 Notes: - 9 - Trove Brivo PTC Kits Installation Guide...
- Page 10 T1BVT4D and T1BV3F4SD (Trove1) Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5”...
- Page 11 0.885” (22.5mm) 1.5” (38.1mm) 6.25” (158.8mm) 19.80” (502.9mm) 1.25” (31.8mm) 2.00” (50.8mm) 0.85” (21.6mm) 2.00” (50.8mm) 1.00” (25.4mm) 1.25” (31.8mm) 1.25” (31.8mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.4mm) 7.00” (177.8mm) 5.25” (133.4mm) - 11 - Trove Brivo PTC Kits Installation Guide...
- Page 12 8.75” (222.3mm) 8.62” (219mm) 8.75” (222.3mm) 2” (50.8mm) Brivo Inc. is not responsible for any typographical errors. ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 7700 Old Georgetown Rd #300 | Bethesda, MD 20814 USA phone: +1 866.692.7486 | email: customercare@brivo.com | www.brivo.com IITrove Brivo PTC Kits...
