Super Flush pneumatic pulsed flushing unit for air-conditioning
systems
Operating Manual
007936210770
Magneti Marelli Aftermarket Spółka z.o.o.
Plac pod Lipami 5, 40-476 Katowice, Poland
Tel.: + 48 (032) 6036107, Fax: + 48 (032) 603-61-08
e-mail: checkstar@magnetimarelli.com
www.magnetimarelli-checkstar.pl
Advertisement
Table of Contents
Related Manuals for Magneti Marelli Super Flush
Summary of Contents for Magneti Marelli Super Flush
- Page 1 Super Flush pneumatic pulsed flushing unit for air-conditioning systems Operating Manual 007936210770 Magneti Marelli Aftermarket Spółka z.o.o. Plac pod Lipami 5, 40-476 Katowice, Poland Tel.: + 48 (032) 6036107, Fax: + 48 (032) 603-61-08 e-mail: checkstar@magnetimarelli.com www.magnetimarelli-checkstar.pl...
- Page 2 MAGNETI MARELLI Aftermarket shall not be held liable for any damage or injuries resulting from a failure to observe the applicable safety regulations and the following instructions.
-
Page 3: Installation
Assess whether the noise level is within the limits of the country of destination and use. It is therefore recommended, to equip operators with appropriate protective measures (earphones or earplugs) as necessary, if the noise level exceeds the permissible limits. Warnings During transport, handling and storage, the unit should always be disconnected from energy sources and its moving parts should be properly secured. - Page 4 The unit must be set up taking into account access areas for regular and emergency maintenance. The lighting in the room shall be such as to ensure excellent visibility of the flushing unit. Unit positioning The flushing unit can be moved and, to ensure proper use, it should be positioned in a well-lit place in the immediate vicinity of the serviced vehicle.
-
Page 5: Installation And Maintenance
Additionally, a filter with a sight glass is installed on the return line to observe the flushing process and proper cleaning. What is the pulse flushing in the "Super Flush" device? It involves the supply of cleaning fluid in equal intervals alternating with compressed air. - Page 6 Installation Install the filter box (located in the station compartment), screw it to the body. Connect the filter–station connection hoses. Install the connection hoses: - blue hose - red hose Check the air turbine lubrication oil level in the tank, top up with pneumatic systems oil if low.
-
Page 7: Right Side
FRONT A. Flushing liquid tank Vents Pre-filter box Turbine driving air pressure gauge and regulator Ball valve (to open the airflow to the turbine) Flushing liquid pulsation controller Flushing liquid pressure gauge RIGHT SIDE Compressed air/nitrogen connection port Ball valve (to blow out the system without turbine use) Ball valve (liquid drain from the tank) Turbine lubrication oil tanks Turbine lubrication rate adjustment screw... - Page 8 LEFT SIDE N. Ball valve (return connection port close/open) P. Pressure connection...
- Page 9 BACK M. Main filter box O. Ball valve (liquid drain from the filter) ACCESSORIES flexible hoses - 2 pcs. connection adapters - 2 pcs. filter spanner funnel spare filter spare turbine lubrication oil...
- Page 10 Technical specifications: - Tank capacity: 4 l - Pressure :5~7 kg/cm2 - Dimensions: 520 × 520 × 900 - Weight: 23 kg Characteristics: - the unit is completely safe for working with solvents - the unit has no sparking elements - the power supply is provided by a pneumatic motor - the cleaning effect is enhanced by the pressure pulsation energy of the gas bubbles, contaminants and used oil are quickly removed from the system...
-
Page 11: Cleaning Agent
This will allow the substance to evaporate after the flushing procedure. We recommend an agent offered by the manufacturer: Magneti Marelli. The cleaning agent should be fully removed from the system as it may damage the compressor as well as the rubber parts used in the connections of the air conditioning hoses. -
Page 12: Main Procedures
Caution!!!! Throttling nozzles, compressors, expansion valves should not be flushed. ADAPTERS KIT A set of connection adapters for air conditioning components is recommended due to the different connection ports in vehicles with air conditioning systems. The kits are available from the manufacturer Magneti Marelli. - Page 13 WITHDRAWAL FROM SERVICE AND DISPOSAL Withdrawal from service If a decision has been made to cease using the flushing unit, it should be made no longer usable by completely removing the cleaning liquid and disconnecting the compressed air. It is recommended to dispose of elements that may be a source of danger. Disposal ...
-
Page 14: General Provisions
MMAM - Magneti Marelli Aftermarket Parts & Services S.P.A., operating in Poland through Magneti Marelli Aftermarket Sp. z o.o., with its registered office in Katowice (40- 476 Katowice), Plac Pod Lipami 5., tel. +48 32 60 36 107, fax +48 32 60 36 108, e-mail: checkstar@magnetimarelli.com. - Page 15 1. This Guarantee constitutes a general warranty statement by the Guarantor and applies to Products which are not excluded from the terms of this Guarantee in the text of this Guarantee or when sold to the Customer or to the Consumer. If the Products are accompanied by special guarantee conditions, they shall take precedence over the present Guarantee, in particular as regards the duration of the Guarantee and the exclusion of the liability of the Guarantor.
- Page 16 1. At the moment of receiving the Product, the Customer should check whether the Product or its packaging do not have any defects visible to the naked eye. If the Customer notices such defects, they must report them to the carrier or courier at the time of receipt. In the event of defects which are not visible to the naked eye and which may arise during transport, the Customer shall notify MMAM within 5 days of receipt of the Products so that MMAM can make a claim against the carrier or the courier within 7 days from the...
- Page 17 5. The Guarantor's liability for defects of the air conditioning station is excluded in case the Customer did not use Magneti Marelli consumable liquids at the station. 6. The Guarantee does not cover Consumable parts. A defect in a Consumable part may, however, be accepted by the Service if the Service determines that the parts wore unnaturally fast compared to their equivalents.
-
Page 18: Personal Data
The processing of personal data is based on the provisions of the Act of 29 August 1997 on personal data protection. Magneti Marelli Aftermarket Sp. z o.o ……………………………………. signature... - Page 19 Magneti Marelli Aftermarket Spółka z.o.o. Plac pod Lipami 5, 40-476 Katowice, Poland Tel.: + 48 (032) 6036107, Fax: + 48 (032) 603-61-08 e-mail: checkstar@magnetimarelli.com www.magnetimarelli-checkstar.pl...
