- Page 1 1 / 18 CORTADObin (GTI-MT510)- Quick Start Guide CORTADObin (GTI-MT510) Quick Start Guide -Rev 03 Revision History Date Revision Board Rev Description Sep 20, 2024 Rev 01 V1-0-0 Preliminary Dec 22, 2024 Rev 02 V1-0-0 Add B.Appearance Mar 04, 2025...
- Page 2 2 / 18 CORTADObin (GTI-MT510)- Quick Start Guide Index Specifications ............................ 3 Appearance (183mm*175mm*46mm) ................... 4 Block diagram ........................... 6 PCBA (170mm*170mm) ........................7 D-1. Top of PCBA ..........................7 D-2. Back of PCBA ..........................8 D-2-1. Module specifications ..........................9 D-3.
-
Page 3: Specifications
3 / 18 CORTADObin (GTI-MT510)- Quick Start Guide A. Specifications Dual-core Arm® Cortex®-A78 processor Media MT8370 @2.0 GHz Plus Quad-core Arm Cortex-A55 processor LPDDR4X Memory eMMC 64GB RJ45 1Gb Ethernet RJ45 2.5Gb Wi-Fi 802.11 a/b/g/n/ac/ax 2T/2R Wireless Bluetooth 5.4 USB 2.0 type-A... - Page 4 4 / 18 CORTADObin (GTI-MT510)- Quick Start Guide B. Appearance (183mm*175mm*46mm) 4 / 18...
- Page 5 5 / 18 CORTADObin (GTI-MT510)- Quick Start Guide 5 / 18...
-
Page 6: Block Diagram
6 / 18 CORTADObin (GTI-MT510)- Quick Start Guide C. Block diagram Carrier board SOM module 314-pin SMARC gold fingers 314-pin SMARC slot 6 / 18... - Page 7 7 / 18 CORTADObin (GTI-MT510)- Quick Start Guide D. PCBA (170mm*170mm) D-1. Top of PCBA Carrier board SOM module 7 / 18...
- Page 8 8 / 18 CORTADObin (GTI-MT510)- Quick Start Guide D-2. Back of PCBA 1(LCM) 2(Camera module) 8 / 18...
- Page 9 9 / 18 CORTADObin (GTI-MT510)- Quick Start Guide D-2-1. Module specifications I/O # module Specifications 7.02” TFT LCD, 94.5mm (H)* 151.2mm (V) Capacitance touch panel 1200x1920 pixels, 16.7M colors I2C interface Camera Diagonal 5.867mm module ...
- Page 10 10 / 18 CORTADObin (GTI-MT510)- Quick Start Guide D-3. SOM (System On Module) board (82mm*50mm) ANT_WiFi #1 ANT_WiFi #2 5G/2.4G 5G/2.4G ANT_BT Dual band Dual band WiFi+BT module (802.11 a/b/g/n/ac/ax 2T/2R) (Bluetooth 5.4) eMMC 314-pin SMARC gold fingers LPDDR4...
- Page 11 11 / 18 CORTADObin (GTI-MT510)- Quick Start Guide E. I/O connectors 10(CON1) 12 (CN1) 9 (J1) 7 (J34) 5(LD2) 13 (J35 SOM module) 11 (J5) 6 (J32) 4 (LD1) 14 (LED2) 3 (J11) 8 (CON2) (on the bottom side)
- Page 12 12 / 18 CORTADObin (GTI-MT510)- Quick Start Guide E-1. I/O connector description I/O # Location Description 1 Description 2 Remark USB 2.0 type-A USB 3.0 type-A USB 3.0 type-C GPIO3 OUT LOW active optional USB link optional RJ45 Ethernet 2.5Gb RJ45 Ethernet 1.0Gb...
- Page 13 13 / 18 CORTADObin (GTI-MT510)- Quick Start Guide I/O # Location Description 1 Description 2 Remark UART2_RXD selection See D-1-6 UART2_TXD selection See D-1-6 Raspberry Pi connector See D-1-7 5G module M.2 NGFF KEY B connector I2C_2 I/O See D-1-8...
- Page 14 14 / 18 CORTADObin (GTI-MT510)- Quick Start Guide E-1-3. CN4- UART1 on SMARC (SOM) E-1-4. J6A- RS485 I/O ,J6B- CAN bus I/O 14 / 18...
- Page 15 15 / 18 CORTADObin (GTI-MT510)- Quick Start Guide E-1-5. RS485 termination resistor E-1-6. J19- UART2_RXD selection/ J20- UART2_TXD selection Note: 1. RasPi_URXD2_3V3 comes from SOM UART2_RXD(1.8V) via a 3.3V level shifter. 2. As default with pin 1-2 short in J19, J20, UART2 RX/TX will be sent to 485-RX/TX.
- Page 16 16 / 18 CORTADObin (GTI-MT510)- Quick Start Guide E-1-7. J17- Raspberry P1 connector E-1-8. J7- I2C_2 I/O 16 / 18...
- Page 17 17 / 18 CORTADObin (GTI-MT510)- Quick Start Guide E-1-9. J9- Supply power VSYS to VSYS_5G 17 / 18...
-
Page 18: Contact Information
18 / 18 CORTADObin (GTI-MT510)- Quick Start Guide F. Contact Information Sales@globalscaletechnologies.com Globalscale Technologies, Inc. 1200 N. Van Buren Street Anaheim, CA 92807 U.S.A. Office: (714) 632 9239 Fax: (714) 632 7550 18 / 18...
