axing premium-line SZU 99-22 Operating Instructions page 3

Advertisement

Available languages

Available languages

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
EU Declaration of Conformity
Hereby AXING AG declares that the CE marked products comply with the
valid EU guidelines.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Technical improvements, changes in design, printing and other errors reserved.
Page 1 of 2 | AXING-BA_SZU-99-xx_v20250304 | 2025-03-04
Technical data
Type
SZU 99-15
SZU 99-06
SZU 99-09S
General
Output voltage
Output current
2 A
Operation voltage
90 ... 250 VAC / 47 ... 63 Hz
Power consumption
39 W
Power consumption
0,4 W
open-circuit
Connector DC
Protection class
Scope of delivery
SZU 99-09N
1 × Power supply SZU 99-22
1 × MAK 30-80 patch cable
SZU 99-09S
1 × Power supply SZU 99-15
1 × MAK 30-80 patch cable
SZU 99-06
1 × Power supply SZU 99-15
1 × adapter cable F to barrel connector
SZU 99-14
1 × Power supply SZU 99-14
SZU 99-15
1 × Power supply SZU 99-15
SZU 99-22
1 × Power supply SZU 99-22
The following is included with all power supply units:
1 × Operation instructions
1 × Safety instructions
Manufacturer
EEA contact address
AXING AG
Bechler GmbH
Gewerbehaus Moskau
Am Rebberg 44
8262 Ramsen
78239 Rielasingen
www.axing.com
info@axing.com
SZU 99-14
SZU 99-22
SZU 99-09N
SZU 99-22 | SZU 99-14
18 VDC
1,2 A
0,7 A
SZU 99-15 | SZU 99-06
23 W
18 W
0,3 W
0,2 W
SZU 99-09N | SZU 99-09S
F-female
II
premium-line
External power supplies
To be used only as spare parts
Operation instructions
