KP2
PRO INSTALLATION GUIDE
KP2
VERSION 8
|
LAST UPDATED 3/25/2025
User Guide
Version 4 |
Last updated 7/7/2023
Please read this entire guide and refer to our
installation materials before using your KP2.
INSIGHTS
xirgo.com
Please read this entire guide
and refer to our installation
materials before using your KP2.
VIDEO TELEMATICS
sensatainsights.com
Advertisement
Table of Contents
Related Manuals for Xirgo KP2
Summary of Contents for Xirgo KP2
- Page 1 KP2. VERSION 8 LAST UPDATED 3/25/2025 User Guide Version 4 | Last updated 7/7/2023 Please read this entire guide and refer to our installation materials before using your KP2. sensatainsights.com INSIGHTS xirgo.com...
-
Page 2: Table Of Contents
Optional accessories ............4 How to calibrate your G-sensor ........KP2 feature reference ............5 How to configure KP2 settings ........How to install your KP2 ............7 Complete your installation/support ......Prepare your KP2 ...............7 Not an installer? ............... Attach your camera to the windshield ......8 LED &... -
Page 3: Package Contents
XIRGO KP2 PRO INSTALLATION GUIDE PACKAGE CONTENTS KP2 VEHICLE RECORDER Mounting bracket & attached power cable Removable wedge block (Connects to adapter cables) (Driver-facing camera ordered separately) Torx wrench ® 8" 3-wire adapter cable • 64GB microSD card (pre-installed) (Connects to bracket cable) Square adhesive cable clips (x5) •... -
Page 4: Optional Accessories
XIRGO KP2 PRO INSTALLATION GUIDE OPTIONAL ACCESSORIES At Xirgo, we give our partners multiple options when selecting their preferred power application and camera configuration. The items mentioned below are compatible with the KP2 and offer different benefits or trade-offs when employed with your device. -
Page 5: Kp2 Feature Reference
XIRGO KP2 PRO INSTALLATION GUIDE KP2 FEATURE REFERENCE FRONT Panic button Bluetooth pairing & G-sensor calibration button LED types: Warning LED (RED) Record LED (BLUE) Network LED (GREEN) SIDE COVER OPEN Optional Driver-Facing Camera (Model: KP2-DFC-S) Release tab Nano SIM slot (4FF) - Page 6 KP2 PRO INSTALLATION GUIDE KP2 FEATURE REFERENCE BACK SIDE Lens angle Road-facing lock camera lens Unscrew the right-side bracket. Remove the KP2 from the bracket to adjust camera angle or insert/remove SIM/micro SD card. Windshield bracket Applied screws for design purpose only.
-
Page 7: How To Install Your Kp2
5. Remove the protective decals from each lens. 6. Use the Torx wrench to tighten the top screw on the KP2 and lock the road-facing camera’s position. Once you’ve secured the road-facing camera, proceed to Attach your camera to the windshield. -
Page 8: Attach Your Camera To The Windshield
Momentarily apply pressure where the camera doesn’t connect to the glass (if necessary). Once the device is correctly attached to the windshield, continue to Connect the KP2 to your vehicle’s power source. Watch KP2 Installation Video... -
Page 9: Connect The Kp2 To Your Vehicle's Power Source
A firmware upgrade may have been queued in SmartAPI prior to your KP2’s installation. This means that shortly after first powering up, KP2 will download and install new firmware, a process that may take several minutes. If a firmware upgrade occurs, you’ll see the Blue... -
Page 10: How To Test Your Installation
• A blinking light, then there is an SD card error or corruption. Contact your partner or support@xirgo.com to repair or replace your SD card. • A solid light, then your device isn’t receiving acceptable power from the host vehicle. -
Page 11: How To Calibrate Your G-Sensor
You’ll hear a beep. Some devices running on newer firmwares may not provide an audible alert. The KP2 LED light will blink briefly to indicate that the G-sensor calibration has registered. You’ve completed the first steps of your KP2 calibration. To adjust your settings, continue to... -
Page 12: How To Configure Kp2 Settings
XIRGO KP2 PRO INSTALLATION GUIDE HOW TO CONFIGURE KP2 SETTINGS Access To finalize your installation and onboard your device, scan the the KP2 QR code. Download and open the app. Scan your device’s Installation IMEI label, and follow the walk-through featured below. -
Page 13: Complete Your Installation/Support
NORTH AMERICA, SOUTH AMERICA, APAC +1 (312) 981-8774 EMEA +44 (0) 1483 397005 NOT AN INSTALLER? Once you complete the training (about a 30-minute webinar), Xirgo will provide you with login credentials for the SmartOPS portal. -
Page 14: Led & Buzzer Specifications
XIRGO KP2 PRO INSTALLATION GUIDE LED & BUZZER SPECIFICATIONS Warning Record Communication Status/Step Blue Green Sound Booting step 1 Startup & power off Booting step 2 On and off Booting step 3 On and off Booting finished Power off Fast simultaneous on and off Beep no. -
Page 15: Technical Specifications
XIRGO KP2 PRO INSTALLATION GUIDE TECHNICAL SPECIFICATIONS MECHANICAL Dimensions 82mm W x 126mm H x 64mm D/3.2" W x 5.0" H x 2.5" D Weight 232.4 g (including 2nd camera, excluding power cable) Image Sensor 2 Megapixel CMOS Sensor Main, Road-Facing Camera (forward-facing): 140° (115°(H), 60°(V)) Angle of View Optional Driver-Facing Camera: 130°... - Page 16 © 2025 Xirgo Technologies. All Rights Reserved. xir4582-0425...
