KP2
USER GUIDE
KP2
VERSION 5
|
LAST UPDATED 3/25/2025
User Guide
Version 4 |
Last updated 7/7/2023
Please read this entire guide and refer to our
installation materials before using your KP2.
INSIGHTS
xirgo.com
Please read this entire guide
and refer to our installation
materials before using your KP2.
VIDEO TELEMATICS
sensatainsights.com
Advertisement
Table of Contents
Related Manuals for Xirgo KP2
Summary of Contents for Xirgo KP2
- Page 1 VERSION 5 LAST UPDATED 3/25/2025 materials before using your KP2. User Guide Version 4 | Last updated 7/7/2023 Please read this entire guide and refer to our installation materials before using your KP2. sensatainsights.com INSIGHTS xirgo.com...
-
Page 2: Table Of Contents
...........8 Configuration tool ............. ® Enable pairing ..............8 SD viewer software ............How to pair with the KP2 ..........8 Technical support & warranty ........Supercapacitor (emergency power) ......8 Safety advice & FCC regulations ......... ADAS functions ..............9 KP2 ADAS disclaimer ............ -
Page 3: Package Contents
XIRGO KP2 USER GUIDE XIRGO KP2 USER GUIDE PACKAGE CONTENTS KP2 VEHICLE RECORDER Mounting bracket & attached power cable Removable wedge block (Connects to adapter cables) (Driver-facing camera ordered separately) Torx wrench ® 8" 3-wire adapter cable • 64GB microSD card (pre-installed) -
Page 4: Optional Accessories
XIRGO KP2 USER GUIDE OPTIONAL ACCESSORIES At Xirgo, we give our partners multiple options when selecting their preferred power application and camera configuration. The items mentioned below are compatible with the KP2 and offer different benefits or trade-offs when employed with your device. -
Page 5: Get To Know The Kp2
XIRGO KP2 USER GUIDE GET TO KNOW THE KP2 FRONT Panic button Bluetooth pairing & G-sensor calibration button LED types: Warning LED (RED) Record LED (BLUE) Network LED (GREEN) SIDE COVER OPEN Optional Driver-Facing Camera (Model: KP2-DFC-S) Release tab Nano SIM slot (4FF) - Page 6 GET TO KNOW THE KP2 BACK SIDE Lens angle Road-facing lock camera lens Unscrew the right-side bracket. Remove the KP2 from the bracket to adjust camera angle or insert/remove SIM/micro SD card. Windshield bracket Applied screws for design purpose only.
-
Page 7: Key Functions
CONTINUOUS RECORD This is the default mode for recording. Your KP2 begins recording after booting up and continues to record the entire time the device is on. In this mode, the SD card storage may fill up quicker and overwrite your oldest recordings when it’s full. -
Page 8: Bluetooth ® Panic Button
3. Bluetooth panic button ® Please get in touch with Xirgo or your supplier to buy a Bluetooth panic button for your KP2. ENABLE PAIRING To enable Bluetooth pairing for your panic button, change the following KP2 Configuration Tool settings in Info >... -
Page 9: Adas Functions
During your KP2 settings calibration, remember that Camera Height is integral to proper ADAS functionality. Therefore, when you input your measurements, please abide by the guidance in the KP2 Installer App. ADAS functionality is not a substitute for an alert, trained and engaged driver. ADAS functionality will be impaired by many things, including but not limited to device malfunction, obstruction of the device’s image... -
Page 10: Dms Functions
XIRGO KP2 USER GUIDE DMS FUNCTIONS Your KP2’s Driver Monitoring System (DMS) functions allow drivers to receive audible alerts for driver distraction and fatigue. The following DMS events are configurable in your KP2: DRIVER DISTRACTION WARNING (DDW) PHONE AT EAR DETECTION (PED) Driver’s head faces away from the road... -
Page 11: Driver Safety Warnings
(including poor lane markings, construction zones, alcohol. Whether or not the KP2 is in use, it is always dirt roads, heavy or complicated traffic, and curvy the driver’s responsibility to take appropriate corrective and winding roads), your KP2 may have limited to action. -
Page 12: Gps Reception
IMPROVE YOUR SIGNAL RECEPTION MAY BE IMPAIRED: 1. Activate your KP2 in an area 1. If there is an object at the end of the GPS antenna. without large buildings. 2. If your vehicle has metallic elements on the windshields. -
Page 13: Led & Buzzer Specifications
XIRGO KP2 USER GUIDE LED & BUZZER SPECIFICATIONS Warning Record Communication STATUS/STEP Blue Green Sound Booting step 1 Startup & power Booting step 2 On and off Booting step 3 On and off Booting finished Power off Fast simultaneous on and off Beep no. -
Page 14: Technical Specifications
XIRGO KP2 USER GUIDE TECHNICAL SPECIFICATIONS MECHANICAL Dimensions 82mm W x 126mm H x 64mm D/3.2" W x 5.0" H x 2.5" D Weight 232.4 g (including 2nd camera, excluding power cable) Image Sensor 2 Megapixel CMOS Sensor Main, Road-Facing Camera (forward-facing): 140° (115°(H), 60°(V)) Angle of View Optional Driver-Facing Camera: 130°... -
Page 15: Installation Resources
> > > > Note: When using DMS with KP2-INTCAM-REM, review KP2 configuration to ensure accurate event generation. 10. Turn on vehicle. Check that blue 10. Turn on vehicle. Check that blue 11. Scan the QR code above, and 11. Scan the QR code above, and 12. -
Page 16: Configuration Tool
CONFIGURATION TOOL KP2 CONFIGURATION TOOL The KP2 Configuration Tool allows you to further customize your KP2 device settings. If you wish to make specific calibration changes, please follow this link to download the software and gain access to supplemental documentation. -
Page 17: Sd Viewer Software
XIRGO KP2 USER GUIDE SD VIEWER SOFTWARE SD VIEWER SOFTWARE Xirgo’ SD Viewer Software gives you access to enhanced video playback, editing and review. Please follow this link to download the software and gain access to supplemental documentation. PC REQUIREMENTS... -
Page 18: Technical Support & Warranty
TECHNICAL SUPPORT For technical support, please contact your local distributor or visit our Support Portal and submit a support ticket. You can also email us at support@xirgo.com or call our support team: NORTH AMERICA, SOUTH AMERICA, APAC +1 (312) 981-8774... -
Page 19: Safety Advice & Fcc Regulations
In the case of an accident, the sensor may not recognize the shock when the impact is light, and as a result, it may not begin recording automatically. CAUTION Please make sure you follow the safety advice/instructions given in KP2 instruction materials. -
Page 20: Kp2 Adas Disclaimer
GPS signal “dead zones” like parking garages and highway tunnels, loss of ADAS function is expected. If you enable ADAS features on a KP2, you assume full responsibility and indemnify Xirgo for any incidents directly correlated with ADAS efficacy, malfunction... - Page 21 © 2025 Xirgo Technologies. All Rights Reserved. xir4582-0425...
