- Page 1 MODEL/MODELO/MODÈLE BL096Y25003 User Manual Manual del usuario Manuel d'utilisateur 877-472-4296 www.medalsports.com...
- Page 2 PRÊTS À VOUS AIDER DO NOT RETURN TO STORE NO DEVOLVERLO A LA TIENDA NE PAS RAPPORTER EN MAGASIN Please Contact Por favor Contactar Veuillez contacter MD SPORTS Customer Service Servicio al Cliente Service Clientèle Toll Free Llamada Gratuita Appel Gratuit 877-472-4296 Mon.-Fri.,...
- Page 3 English Español Français TOOLS REQUIRED HERRAMIENTAS NECESARIAS OUTILS REQUIS - Not Included - Non inclus Phillips Screwdriver Destornillador Phillips - No incluido Tournevis cruciforme - Not Included - No incluido - Non inclus Standard (Flat Head Destornillador de Tournevis standard Screwdriver) Cabeza Plana (Tête plate)
- Page 4 English Español Français PARTS IDENTIFIER IDENTIFICADOR DE PIEZAS IDENTIFICATEUR DE PIÈCES PART NUMBER FIG. NUMBER FOR FIG. 14 NÚMERO DE PIEZA NÚMERO DE FIG. NUMÉRO D'ARTICLE NUMÉRO FIG. PART QUANTITY PIEZA CANTIDAD PIÈCE QUANTITÉ NOM DE LA PIÈCE Unidad PART NAME Mainframe Unité...
- Page 5 English Español English Español Français ACCESSORIES ACCESORIOS ACCESSOIRES Ensemble Billiard Ball Bola de billar boules de billard HARDWARE HARDWARE MÉTAUX FOR FIG. 2 FOR FIG. 2, 11 FOR FIG. 2 FOR FIG. 6, 9 Arandela de M8x28mm Perno Boulon M8 Spring Rondelle de 4x15mm Tornillo...
-
Page 6: Montaje
English Español English Español Français BEFORE ASSEMBLY ANTES DE MONTAR AVANT L’ASSEMBLAGE Find a clean, level place to begin Encuentre un lugar limpio y nivelado para Trouvez un endroit propre et plat the assembly of your product. comenzar el ensamblaje del producto. pour commencer à... - Page 7 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 3 Note: Lock them together in the order of 1, 2, 3, 4, 5, 6, 7. You will hear a “CLICK” sound when snapping the Legs together. This will indicate that the Legs are locked firmly in place.
- Page 8 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 4 Note: Lock them together in the order of 1, 2, 3, 4. You will hear a “CLICK” sound when snapping the Legs together. This will indicate that the Legs are locked firmly in place. If you do not hear a “CLICK”sound the legs are NOT LOCKED.
- Page 9 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 5 Note: Lock them together in the order of 1, 2, 3, 4. You will hear a “CLICK” sound when snapping the Legs together. This will indicate that the Legs are locked firmly in place. If you do not hear a “CLICK”sound the legs are NOT LOCKED.
- Page 10 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 6 FIG. 2 Assembly Ensamblaje FIG. 2 FIG. 2 Assemblage FIG. 3 Assembly Ensamblaje FIG. 3 FIG. 3 Assemblage FIG. 5 Assembly Ensamblaje FIG. 5 FIG. 5 Assemblage BL096Y25003 www.medalsports.com...
- Page 11 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 7 Note: Apply the glue (20) onto the grooves of the side and end top boards (17 & 18). Nota: Aplicar el pegamento (20) en las ranuras de las tablas lateraly tablero superior lateral (17 & 18). 17 &...
- Page 12 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 9 FIG. 10 Note: Make sure “FLAPS” on top leg panels are FLUSH AGAINST APRONS before inserting screws. Nota: Asegúrese los protectores “FLAPS” sobre los paneles de la pata superior estén A RAS CONTRA LOS FALDONES antes de insertar los tornillos. Note : Assurez-vous que les “RABATS”...
- Page 13 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 11 Note: After this step, tighten the bolts (A1) (See FIG. 2). Nota: Después de este paso, apretes los pernos (A1) (Vea la Fig. 2). Note : Après cette étape, serrez les boulons (A1) (Voir FIG. 2). FIG.
- Page 14 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 12 Note: Avoid sideways pressure legs when turning over. Nota: Evite la presión lateral sobre las patas cuando dando vueltas. Note : Evitez toute pression latérale sur les pieds en retournant la table. Note: Go back and make sure that all connections are tight.
- Page 15 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 13 Note: P3 on the back. Nota: P3 está en la espalda. Note : P3 au dos. Note: Please note that adjustable bracket (21) and support boards (16) must be parallel with each other. Nota: Favor notar que los corchete regulable (21) y las placas de soporte (16) deben venire enparalelo.
- Page 16 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 14 SIDE VIEW VISTA LATERAL VUE LATÉRALE BL096Y25003 www.medalsports.com...
- Page 17 English Español Français ASSEMBLY MONTAJE ASSEMBLAGE FIG. 15 FIG. 16 NOTE: DO NOT lift the table by the pockets. If you move the table, do not lift it by placing your hands beneath the pockets and do not lean or put pressure on them. Do not lean or sit on the end or side rails as this may damage the table. NOTA: No levante la mesa por las troneras.
- Page 18 English Español Français HOW TO LEVEL YOUR CÓMO NIVELAR SU MESA COMMENT NIVELER TABLE VOTRE TABLE STEP 1 PASO 1 Level (Not included) Nivel (No incluido) ÉTAPE 1 Niveau (Non inclus) STEP 2 Level (Not included) PASO 2 Nivel (No incluido) Niveau (Non inclus)
- Page 19 www.medalsports.com...
