DADISICK OX-R1 Series User Manual

OX-R1
User Manual
Adopts radio frequency induction coding technology,
with higher security and con dentiality;
Strong anti-inte erence, safe and reliable；
Universal coding type and single coding type optional；
Prevents abnormal human triggering；
Sensors can be activated from 3 sides；
Suppo s up to 30 sensors cascaded；
Standard size actuators and at actuators optional.
Model Speci cations
Safety standards ISO13849-1, IEC/EN60947-5-1, IEC/EN60947-5-3
Safety classi cation Class 4 switch with IS0 13849-1/suitable for PLe/PLd
Ce i cation CE
Horizontal distance Conduction, min: 10mm
Ve ical distance Conduction, min: 8mm
Operating voltage 24V DC±15%
Operating current 30mA
Output current 150mA
Response time 60ms
Protection level IP65, IP67 (customized)\IP68 (customized)
Operating frequency 1Hz
Operating temperature -10 ~ +55°C
Relative humidity 5 ~ 95%
Material Anti- ame retardant thermoplastic
Note 1: Universal coded sensors and actuators can be randomly paired for use;
Note 2: When the unique coded type is used for the rst time, the sensor will record
the actuator code for pairing. After pairing is completed, the sensor can only
recognize the current actuator. If you need to re-pair the actuator, please contact
our technical suppo .
Dimensions
(Unit: mm)
Actuators
Sensors
Model Rules
Selection example: OX-R1-EN-S-P1
OX-R1 E N S
Note* The default cable length is 2m.
If you need other lengths, please contact customer se ice.
Model Description
Model
OX-R1-FN-S-P1
4-core direct outlet dual-channel NPN output 2M line
OX-R1-FP-S-P1
4-core direct wiring dual PNP output 2M line
OX-R1-EN-S-P1
6-core direct wiring dual NPN output with cascade 2M line
OX-R1-EP-S-P1
6-core direct wiring dual PNP output with cascade 2M line
4-core direct wiring dual NPN output 2M line
OX-R1-FN-D-P1
Actuator with unique code
4-core direct wiring dual PNP output 2M line
OX-R1-FP-D-P1
Actuator with unique code
6-core direct wiring dual NPN output with cascade 2M line
OX-R1-EN-D-P1
Actuator with unique code
6-core direct wiring dual PNP output with cascade 2M line
OX-R1-EP-D-P1
Actuator with unique code
Indicator status
Signal Status
Led Display
Input
Red light always on Yes/No
Red light on for 1 second
and then ashes 2 times Yes/No
(alternatingly)
Yes
Red light ashes at 4Hz
No
Green light ashes at 1Hz
Yes
Green light always on
Red and green lights ash
Yes
alternately
Note: When the unique code is used for the rst time, the sensor will record the code of
the actuator for pairing. After the safety switch is installed and the door is closed and
powered on for 5 seconds, the green light on the safety switch will be on, indicating
successful pairing.
P1
Actuator Speci cations
P1: Complete Set
P2: Actuator
P3: Sensor
Coding type
S: Universal code
D: Unique code
Output type
N: Dual NPN output
P: Dual PNP output
Cascade Type
E: Suppo cascade
F: Do not suppo cascade
Product Series
Speci cations
Status Description
Output
No actuator or not fully aligned
Disconnect
(universal encoding)
No actuator or not fully aligned
Disconnect
(unique encoding)
Output overload
Disconnect
No input signal
Disconnect
(dual output not applicable)
Sensing normal
Connect
Tag not registered
Disconnect
