- Page 1 Vacuum Filtration System Lafil 300 - LF 30 / SF 10 Lafil 400 - LF 30 / SF 10 / LF 5a - 500 Lafil 300C - VF 12 Lafil 200 - VF 17...
-
Page 3: Table Of Contents
Table of Contents Important Notice ..............................1 Unpacking ................................3 Main Part Diagram .............................. 6 Vacuum Pump ................................. 6 Parts Material List ..............................7 Installation and Operation ..........................8 Installation ................................. 8 Operation ................................... 9 Maintenance ............................... 10 Troubleshooting ............................... 11... -
Page 4: Important Notice
1. Important Notice This instrument is designed for laboratory usage only. Please read this manual carefully before installing and operating. The instrument shall not be modified in any way. Any modification will void the warranty and may result in potential hazard. We are not responsible for any injury or damage caused by any non-intended purposes and modifying the instrument without authorization. - Page 5 13. Operating condition (a) Ambient temperature: 5 ~ 40°C (b) Relative humidity: 80% RH Max. (c) Power supply: 100-120V~, 50/60Hz or 200-240V~, 50/60Hz (d) Altitude: up to 2000 m (e) Pollution degree: II (f) Indoor use * Before operation, check the compatibility of pump (including pump head, valve plates, piston seal, and diaphragm) and filtration apparatus materials with used medium.
-
Page 6: Unpacking
2. Unpacking Please check if the package is complete without any damage before unpacking. When unpacking, please make sure you have all accessories that indicated on the list. If there is any problem, please keep the serial number along with packing case and contact your local distributor immediately for assistance. - Page 7 Lafil 400 - LF 5a - 500 Lafil 300C - VF 12 Model Standard Package Includes: Lafil 400, Oil Free Vacuum Pump LF 5a, Spin-Lock Filter Holder (500 mL) Laboratory Glass Bottle, 500 mL Lafil 400 - LF 5a - 500 Silicone Adaptor Silicone Tube Power Cord...
- Page 8 Lafil 200 - VF 17 Model Standard Package Includes: Lafil 200, Oil Free Vacuum Pump VF 17, Glass Filtration Set Lafil 200 - VF 17 Silicone Tube Power Adaptor Instruction Manual...
-
Page 9: Main Part Diagram
3. Main Part Diagram Vacuum Pump Lafil 200 Lafil 300 / 300C / 400 Item Designation Item Designation Power Switch PE Muffler Inlet Ventilation Outlet Vacuum Regulator DC Socket Handle AC Socket Vacuum Gauge Fuse Holder Washer... -
Page 10: Parts Material List
Parts Material List Vacuum Pump Material Model Pump head Valve plates Piston seal Diaphragm Lafil 200 EPDM EPDM Lafil 300 / 400 PTFE complex Aluminum alloy Lafil 300C PTFE coated PTFE coated Filtration Apparatus Material contacts with filtrates Model Filter Holder Receiver Bottle... -
Page 11: Installation And Operation
4. Installation and Operation Installation Assemble the filtration apparatus as shown below. Filtration Apparatus Installation LF 30 SF 10 LF 5a - 500 VF 12 / VF 17 Support Base Overflow Protection LF 30 LF 5a Included in Filtration Apparatus: LF 30, SF 10... -
Page 12: Operation
Operation A. Turn on the pump, block the inlet (2), and regulate the desired vacuum by vacuum regulator (3). B. Put the filtration apparatus in fence-like platform of Lafil vacuum pump. Insert a silicone adaptor onto the bottom of laboratory glass bottle of LF 5a - 500 or VF 12 before installation to stabilize the filtration apparatus. -
Page 13: Maintenance
5. Maintenance 1. The vacuum pump is not autoclavable. Please clean the surface by pure water or 75% ethanol. 2. After finishing the experiment, please keep pumping the air for at least 2 minutes to withdraw the residual steam. 3. Filtration apparatus and accessories are autoclavable (121°C, 1 bar, 20 min). Please make sure to rinse the apparatus with pure water and separate each part before autoclave. -
Page 14: Troubleshooting
6. Troubleshooting Problem Reason and Solution Loose plug Reconnect plug to power supply. Wrong voltage Reconnect to power specified on name plate. Faulty power adaptor Replace a new oner from manufacture. Failed to start ... -
Page 15: Ordering Information
Ordering information 197200-01(02) Lafil 200, Oil Free Vacuum Pump with AC100-240V adaptor, US plug (EU plug) 197300-11(22) Lafil 300, Oil Free Vacuum Pump, AC110V, 60Hz (AC220V, 50Hz) 197400-11(22) Lafil 400, Oil Free Vacuum Pump, AC110V, 60Hz (AC220V, 50Hz) 197330-11(22) Lafil 300C, PTFE Coated Chemical Resistant Vacuum Pump, AC110V, 60Hz (AC220V, 50Hz) 197400-45 PE Muffler (1/8 PT) of Lafil 300 / 400 / 300C... - Page 16 Rocker Scientific Co., Ltd. Tel: +886-2-26033311 Fax: +886-2-26036622 E-mail: export@rocker.com.tw https://www.rocker.com.tw...
