Caution : You must read this before you proceed
CAUTION: This table is NOT a TOY.
Keep your child / children at bay in the process of assembly.
Parts list
Label
A
Noble House Home Furnishings LLC
Noble House Home Furnishings LLC
Assembly Instructions
Expandable Table
Description
Table Top
QTY
1
Page 1 OF 7
Page 1 OF 7
Advertisement
Related Manuals for Noble House Home Furnishings Expandable Table
Summary of Contents for Noble House Home Furnishings Expandable Table
- Page 1 CAUTION: This table is NOT a TOY. Keep your child / children at bay in the process of assembly. Parts list Label Picture Description Table Top Page 1 OF 7 Page 1 OF 7 Noble House Home Furnishings LLC Noble House Home Furnishings LLC...
- Page 2 Label Picture Picture Description Description ① Studs(M8*40mm ） ② Washers(8mm) ③ Spring washers(8mm) ④ Nuts(8mm) ⑤ Nut Caps(8mm) ⑥ Screwdriver ⑦ Spanner Page 2 OF 7 Page 2 OF 7 Noble House Home Furnishings LLC Noble House Home Furnishings LLC...
-
Page 3: Assembly Preparation
Assembly Preparation Before Beginning Assembly: Assembly Step Overview A(Table Top) D(Table Leg) B(Long Leg Support) C(Short Leg Support) FRONT FACING Page 3 OF 7 Noble House Home Furnishings LLC... - Page 4 Unpack and place all parts on a clean soft surface. Step 2 Turn the Table Top upside down on to a clean soft surface. Caution: you may need 2 adults to turn the table top A upside down. Page 4 OF 7 Noble House Home Furnishings LLC...
- Page 5 Do Not Overtighten all nuts. Step 4 Attach four Leg Support to the mounting position with Washers(②),Spring Washers(③),Nuts(④ ) and the Nuts Cap (⑤) by Spanner(⑦). Do Not Overtighten all nuts. Page 5 OF 7 Noble House Home Furnishings LLC...
- Page 6 To shorten the Table, pull the table top apart, then the central panels will go down, and then push the Table Top back to the center until the Table top is flush. Page 6 OF 7 Noble House Home Furnishings LLC...
- Page 7 Page 7 OF 7 Page 7 OF 7 Noble House Home Furnishings LLC Noble House Home Furnishings LLC...
