MSD Atomic EFI 2910 Installation Instructions Manual

ONLINE PRODUCT REGISTRATION: Register your MSD product online. Registering your product
will help if there is ever a warranty issue with your product and helps the MSD R&D team create
new products that you ask for! Go to www.msdperformance.com/registration.
Thank you for selecting the Atomic TBI Fuel Injection System! MSD's Atomic EFI systems were designed with
two major goals; to simplify EFI and deliver better overall performance to your engine. Simplicity is achieved
through with less wiring to ease installation plus programming is simple with no PC required! Performance is
delivered through advanced control of the fuel and ignition, just as you'd expect from MSD.
As with any performance product, please be sure to read the entire instruction manual before attempting to
install this system on your vehicle. Please contact our Customer Support department if you have any questions
about your Atomic installation at (915) 855-7123. There are also some helpful installation videos available at
www.atomicefi.com.
Parts Included:
1 - Throttle Body w/ECU
1 - TB Harness
1 - Power Module
1 - PM Harness - w/ WBO2
1 - Handheld Monitor
1 - Coolant Temp Sensor
The Atomic Throttle Body EFI system, PN 2900 and PN 2910, have been granted Executive Order number D-722
from the California Air Resources Board. This E.O. number permits the installation of the Atomic TBI system
on 1987 and older GM passenger cars and trucks with a V8 gasoline powered engine originally equipped with
a carburetor. Other vehicles and manufacturers are pending approval.
For emission compliant installation, all of the original control components must be retained including the catalytic
converter, EST distributor, AIR pump, EGR, etc. An addendum outlining specific installation steps and settings
for a CARB compliant installation are included separately with this kit.
WARNING
must be carried out by a qualified automotive technician. Installation of fuel system parts requires handling
of gasoline. Ensure that work is performed in a well ventilated area with an approved fire extinguisher nearby.
Extinguish all open flames, prohibit smoking and eliminate all sources of ignition in the area of the vehicle
before beginning the installation.
When working with fuel systems, eye goggles and other safety apparel should be worn to protect against
debris and sprayed gasoline. The finished work must be thoroughly checked to ensure there are no fuel leaks.
CONTENTS:
Parts Review and System Capabilities . . . . . 2
Fuel System Overview and Requirements . . 3
02 Sensor Installation . . . . . . . . . . . . . . . . . . 5
Throttle Body Installation . . . . . . . . . . . . . . . 6
Power Module Installation and Wiring . . . . . . 9
Throttle Body Wiring . . . . . . . . . . . . . 7, 10-11
System Wiring . . . . . . . . . . . . . . . . . . . . . 9-11
Wiring with Timing Control. . . . . . . . . 16-18
M S D
• W W W . A T O M I C E F I . C O M
Atomic EFI
PN 2910 - Throttle Body Kit
1 - O Sensor
2
1 - O Bung and Plug
2
4 - Rubber Grommet
4 - Eyelet Insert
4 - Mounting Screws
1 - 4G Micro SD Card
Installation of this product requires detailed knowledge of automotive systems and
repair procedures. Installation of fuel system parts and any fuel tank modifications
•
4 ft. CAN Extension
Air Filter Gasket
Intake Manifold Gasket
1 - 6AN Port-to-Male Adapter
Programming
Initial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Advanced . . . . . . . . . . . . . . . . . . . . . . . . . 13
Final Adjustments . . . . . . . . . . . . . . . . . . . . 15
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . 20
( 9 1 5 ) 8 5 5 - 7 1 2 3 • F A X ( 9 1 5 ) 8 5 7 - 3 3 4 4
