Summary of Contents for DAS SOLAR DAS-LOCP-320
- Page 1 Component User Manual Lightweight Module User Manual DAS-LOCP-320 DAS-LOJP-420 DAS-LH132PA-470 www.das-solar.com...
-
Page 2: Table Of Contents
Connectors ........................26 Bypass Diodes........................26 Grounding Module grounding......................27 DAS-LOCP-320 DAS-LOJP-420 DAS-LH132PA-470 Grounding of other materials..................27 Operation and maintenance Cleaning..........................28 Modules appearance inspection ................... 29 Connector and cable inspection ................... 29 Release and Implementation Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 3: Disclaimer
Module. Photovoltaic Modules may generate power energy modules (hereinafter referred to as "Module") manufactured by DAS Solar Co. , Ltd., when directly exposed to light sources, and a photovoltaic array comprised of hereinafter referred to as "Juhe New Energy". -
Page 4: Electrical Performance Safety
PV modules are connected to the system or not. Climbing, stepping, standing, walking or jumping directly on the package or module is prohibited. It is forbidden to place the module on any platform for bracketing the module. Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 5: Precautions For Handling, Storage And Transport
Please operate the spreader at an even speed, and hold the carton gently on a relatively flat position when the lifting is close to the ground. Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 6: Project Site Transport
N2000kgf. Upon loading with the forklift, first steadily place the packing case on the ground, then remove the safety ropes when the tilting risk is negligible. Control the driving speed of the forklift during transport, and slowly withdraw the fork when unloading, so as to prevent tilting. Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 7: Secondary Transport
The tray must be placed within the loading area of the transport vehicle. After the modules are removed from the packing boxes, they must not be leaned against the mount- ing post or placed in an environment where it is not reliably supported or secured. Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 8: Unpacking Safety
If there are rust stains on the installation surface, you need to use steel brush and sandpaper to remove rust first, and the industrial anti-rust paint treatment shall be performed to dry before installation. The following installation methods of Juhe New Energy lightweight modules have passed the 2400 PA test load. Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 9: Mechanical Installation
Color steel tile valley peak to valley bottom height If you need to use the adhesive material approved by Juhe New Energy, please contact Juhe New Energy for supplier information. Color steel tile valley peak to DAS-LH132PA 2148 valley bottom height Copyright©2023 DAS SOLAR www.das-solar.com... - Page 10 The overall requirement of the module: no shadow shading, if there is the shadow shading on the The above paste method is applicable to Juhe New Energy lightweight modules DAS-LOCP-320, DAS-LOJP-420 and DAS-LH132- installation surface and other circumstances, the designed space shall be reserved according to the PA-470.
-
Page 11: Glass Plane Installation
3 pieces of adhesive* are glued immediately adjacent to the outer edge of the tape, the length of which is equal to the length and width of the module respectively, and the width*height of the adhesive type ≥ 6*2mm; Arrangement spacing ≥10mm Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 12: Glazed Tile, Cylinder Tile Surface Installation
* Module gluing area (Outside & middle) EPS-1985*50*50mm side full coating The length of gluing is equal to the height ≥ 6 * 2MM; length of the module *4 strips Double-sided adhesive pasting area Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 13: Eps Installation On Cement Flat Roof
If the number of parallel connections is greater than or equal to 2 strings, there must be an overcurrent protection device on each string of modules, as shown in Figure 1. Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 14: Cable And Connecting Wires
Solar. Attempts to open the module's junction box on your own are strictly prohibited. The minimum bending radius of the cable shall be 41.5MM. 41.5MM Minimum bending radius Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 15: Module Grounding
Chloride or salt content: 0 - 3,000 mg/L Turbidity: 0-30 NTU Electrical conductivity: 1500~3000 μs/cm Total dissolved solid:≤1000 mg/L Water hardness:0-40 mg/L The non-alkaline water must be used, and when the conditions are met, the softened water shall be used. Copyright©2023 DAS SOLAR www.das-solar.com... -
Page 16: Modules Appearance Inspection
It is recommended to check the electrical, grounding and mechanical connection parts every 6 months to make sure they are clean, safe, undamaged and rust-free, that the mountings are properly tightened and that all cables are checked to make sure the connectors are tight. Copyright©2023 DAS SOLAR www.das-solar.com...
