- Page 1 Module User Manual...
- Page 2 User Manual of DAS Solar Modules Applicable product list Product type Product model WH108PA Single glass product WH144PA DH96NE DH108PA DH108NA DH108ND Double glass product DH108NE DH120ND DH144PA DH144NA DH144ND DH132NE DH156PA DH156NA DH132NC DAS-MP-023-A01-V11-2025.01...
-
Page 3: Table Of Contents
User Manual of DAS Solar Modules Table of Contents Introduction to user manual ............ -
Page 4: Introduction To User Manual
(hereinafter referred to as "Module") manufactured by DAS Solar Co., Ltd. . DAS Solar Co., Ltd. is hereinafter referred to as "DAS Solar". Any violation of these safety instructions may lead to casualties or property loss. -
Page 5: Precautionary Safety Measures
User Manual of DAS Solar Modules 2. Precautionary safety measures 2.1 Warning Please read and understand all safety rules prior to installation, wiring, operation or maintenance of the Module. Photovoltaic Modules may generate power energy when directly exposed to light sources, and a photovol- taic array comprised of multiple Modules may create dangers critical electric shock or burning, thus any person without authorization and related training shall not contact the photovoltaic Module and its wiring terminals, etc. -
Page 6: Conventional Safety
User Manual of DAS Solar Modules 2.3 Conventional safety • Do not stand, tread, sit, walk or jump on the Module or Module packing. • Keep children or unauthorized persons from approaching the installation area or storage area of the Module. -
Page 7: Operating Safety
User Manual of DAS Solar Modules 2.4 Operating safety • Do not privately repair the Module if the front glass is damaged. • Do not dismantle the Module or remove any part of the Module. • Avoid any articles from directly dropping onto or colliding with the Module. -
Page 8: Precautions For Handling, Storage And Transport
User Manual of DAS Solar Modules 3. Precautions for handling, storage and transport 3.1 Turnover precautions • Please use forklift to unload the Module from the truck (up to two trays of Modules at one time), and place the Module on the level ground.. -
Page 9: Unloading Mode And Precautions
Module model and quantity indicated on the outer packing case is identical with the delivery note, and immediately contact the logistical personnel and DAS Solar's sales personnel in case that any abnormality is found. The packing construction is as follows:... - Page 10 User Manual of DAS Solar Modules Outer box With timber support (model 48/54/60/66/72/78) Inner packing Outer packing Stacking tray Outer box without wooden support (model 48/54/60/66/72/78) Inner packing Outer packing Stacking tray...
- Page 11 User Manual of DAS Solar Modules Hoisting and handling: When unloading with hoist, please use specialized tooling, and adopt hoisting tools with sufficient tension ac- cording to the weight and size of the Module. During hoisting, please timely adjust the sling and keep the Module's gravity center steady.
-
Page 12: Project Site Transport
User Manual of DAS Solar Modules General warehousing forklift： Please used forklift with appropriate lifting capacity, according to the weight of the Module. The depth of the fork sticking into the tray shall not be less than three fourths of the tray length (length of fork not less than LN3/4 of tray length)。... - Page 13 User Manual of DAS Solar Modules Fork length (L) shall be N1.0m, and fork interval (W2) shall be adjusted to approach the two corners of the tray to the greatest extent. Gantry height (H) shall be N1.5m or gantry width (W1) shall be N2.5m.
-
Page 14: Secondary Transport
User Manual of DAS Solar Modules 3.5 Secondary transport Packaged Modules can be transported through land transportation, seal shipping or air transportation. During the transport: Please securely fix the packing case onto the transport platform, and make sure it will not be tilting or shifting. -
Page 15: Unpacking Mode
User Manual of DAS Solar Modules 4. Unpacking mode First place the packing on the level, dray and flattened ground, then successively remove the wrapping film, packing strap, upper cover, and carton. If you need to stack the Modules, please place the try on the level ground, and the Modules must keep stacked on the tray;... - Page 16 User Manual of DAS Solar Modules • Upon unpacking, the unpacking operation must be performed by 2 or more persons simultaneously. Opera- tors shall wear protective insulating gloves when handling the Modules to avoid injury and prevent leaving finger- prints on the glass surface.
- Page 17 User Manual of DAS Solar Modules • In windy weather conditions, please do not handle the Modules, and properly secure and fixe any unpacked Modules. •Do not move the leaning posts during the unpacking process, so as to prevent tilting of the Modules.
-
Page 18: Introduction To Installation Method
The installation location of the module should be > 50 meters from the coastline. For photovoltaic projects with a distance of less than 50 meters from the coastline, please contact the DAS solar sales staff to confirm the product plan and installation plan separately . -
Page 19: Module Tilting Angle
Clamp, or snap-in system. Module installation must be in line with the installation requirements. If the Module is to be installed in a way inconsistent with the instructions declared by DAS Solar, please consult the local technical support or after-sales personnel of DAS Solar and obtain the consent of DAS Solar, otherwise, the Module may be damaged and the product warranty will be invalidated. -
Page 20: Bolt Installation
• Check whether the serial number of the Module is correct. • The front side of the DAS Solar Modules can bear a maximum stress of 5400Pa (only limited to the Module models described in this manual), and 2400Pa for the rear side. The maximum design stress bearable by the front side is 3600Pa, and 1600Pa for the rear side. - Page 21 User Manual of DAS Solar Modules Bolt installation Installation requirements beam parallel to the beam vertical to the long frame long frame Outer quad hole Inner quad hole Outer quad hole Module frame high Type model (mm) (1400mm) (1600mm) (990mm)
-
Page 22: Clamp Installation
There are 4~6 pairs of 9*14mm mounting holes on the frames of each Module, which can be used to ideally fix the Module to the supporting structure to optimize its load bearing capacity. In order to extend the lifespan of the installation to the greatest extent, DAS Solar strongly recommends that anti-corrosive (stainless steel) fastenings should be used. - Page 23 User Manual of DAS Solar Modules Clamp installation Installation requirements 350≤D≤450 460≤D≤560 495≤D≤615 250≤E≤300 Module beam vertical to beam vertical to beam vertical to beam vertical to frame high Type model (mm) the long frame the long frame the long frame the short frame ﹢5400，-2400...
- Page 24 Module can bear the pressure. •DAS Solar has tested the Modules with different Clamps of varied manufacturers, and recommends that M8/M6 (full thread preferred) fastenings shall be used in line with local environment. The material and type selec- tion of fastenings shall be dependent on local environment.
-
Page 25: Single-Axis Installation
User Manual of DAS Solar Modules 5.5 Single-Axis installation 400mm 790mm Mounting rails run perpendicular to the long side frame. Distance between mounting holes is 400 mm/790mm Single-Axis installation Installation requirements 400mm 790mm Module frame high Mounting rails run perpendicular to... -
Page 26: Other Mounting Options
User Manual of DAS Solar Modules 5.6 Other mounting options Guide rails mounted parallel to long side bolts Guide rails mounted parallel to long side bolts Distance between mounting holes on the same side 1400mm DH108NA ﹢2600，-2400 DH96NE DH108NE... - Page 27 User Manual of DAS Solar Modules Shared Beam Fixture Installation Installation 1 Installation 2 Shared Beam Fixture Installation Installation requirements Installation 1 Installation 2 Module frame high L=（40mm-100mm） L=（350mm-500mm） Type model (mm) DH108NA ﹢2400，-2400 ﹢2400，-2400 Double DH96NE ﹢2000，-1800 ﹢2400，-2400 glass ﹢1800，-1400...
- Page 28 User Manual of DAS Solar Modules Six-Point Briquetting Installation Parallel to three beams on the long side of the assembly (250mm-350mm) Installation Six-point briquette mounting requirements Parallel to the three beams on the long side of the assembly (250 mm - 350 mm)
-
Page 29: Module Wiring
User Manual of DAS Solar Modules 6. Module wiring 6.1 Wiring requirements • The electrical performance parameters of the Module are derived from tests under standard test conditions, that is, solar radiation intensity 1000W/m², AM1.5 and ambient temperature 25°C. Under certain circumstances, the Module may generate a voltage or current value which is higher or lower than the rated value. - Page 30 • DAS Solar Modules adopt specialized ultraviolet-proof photovoltaic cables with the cross-sectional area greater than or equal to 4mm². All other cables connected to the DC system shall be with similar (or higher) specification. DAS Solar recom- mends that all cables shall be laid in appropriate pipes or troughs and kept away from any place that is prone to ponding. Volt- age of series connection shall not be higher than the maximum voltage bearable by the system and the maximum input voltage of the inverters and other electrical devices installed in the system.
-
Page 31: Wiring Method
User Manual of DAS Solar Modules 6.2 Wiring method Recommended wiring method for triple wiring box (vertical: Standard cable length (Note: Cable extension required for the single-row terminal)). Vertical installation of Modules: Select the standard stub cable Stub cable natural... -
Page 32: Grounding Connection
User Manual of DAS Solar Modules 6.3 Grounding connection Modules must be grounded (Modules have been certified with the safety grade II), and make sure that the grounding method complies with the local electrical instructions and regulations. Qualified electrical personnel shall be engaged to perform the grounding connection operation. -
Page 33: Module Maintenance
• Screw on the fastening bolt of grounding lead and complete the installation. Other third-party grounding device: DAS Solar Module can be grounded through third-party ground devices, provided that the grounding is proved to be reliable and the grounding device is installed according to the require- ments of the manufacturer. -
Page 34: Connector And Cable Inspection
In order to reduce potential electric shock or burning, DAS Solar recommends that the cleaning work of photo- voltaic Modules shall be preferably performed when the solar radiation is weak (e.g. in early morning or at dusk), especially in areas with high temperature. -
Page 35: Cleaning Method
User Manual of DAS Solar Modules 7.4 Cleaning method Method A: High-pressure water cleaning •Water quality requirement; PH: 5~7; •Chloride or salinity content: 0-3,000mg/L •Turbidity: 0-30NTU Water Anhydrous ethanol •Electrical conductivity: 1500~3000μs/cm •Total dissolved solid: ≤1000mg/L •Water hardness 0-40mg/L • Non-alkaline water shall be used. When... -
Page 36: Post-Cleaning Inspection
If the Module malfunctions after installation, please immediately notify the installation provider. 8. Release and execution This manual is subject to centralized management of the DAS Solar technical platform, and the final exe- cution and interpretation of this manual shall be the responsibility of the technical platform. - Page 37 User Manual of DAS Solar Modules Copyright©2023 DAS SOLAR www.das-solar.com...
